Insinger 45SA5 Betriebsanleitung

UNDERCOUNTER SCULLERY MACHINE

ELECTRIC or STEAM HEAT

45SA5-F1 (steam)

45SA5-F2 (electric with 9 KW booster)

45SA5-F2D (electric with 18 KW booster)

45SA5-F2NM (electric, non-magnetic, 11.4 kw booster)

STANDARD FEATURES

• Detergent and rinse additive

connection provisions

• Plastic 16" x 16" racks

• Bulk-head mounted NEMA 12

control panel

• Simplified scrap screen design

• Door safety switch

• Standard frame TEFC motor

• 2 tech manuals

• Authorized tech rep in each port

• Exact footprint replacement

• Complies with ASTM

specifications

• Heat:

Electric— 1.5 KW electric

immersion heater and 9 or 18

KW electric booster with low

temp cut-off.

Steam— 1 stainless steel steam

coil and steam booster with low

temp cut-off

• Capillary thermometers for wash

and rinse

• Automatic tank fill

• S/S frame

• Pressure reduction valve and

line strainer

• Manual tank fill

• Low water protection

• Stainless steel level gauges

DESIGN

The Insinger 45SA5 washes 45 racks per hour. It pumps 70 gal/min. of

wash water through stationary wash arms. The rinse cycle consists of

stationary lower rinse arm with 6 nozzles and an upper rinse arm with 4

final rinse nozzles.

The tank, hood and door are all 16 gauge stainless steel.

OPTIONAL ACCESSORY EQUIPMENT

• Non-magnetic pump & booster

Live Tech Service is Available

24 hours/day 7 days/week

800-344-4802

[email protected]

6245 State Road

Philadelphia, PA 19135-2996

215-624-4800

215-624-6966 FAX

800-344-4802

www.insingermachine.com

UNDERCOUNTER SCULLERY MACHINE

Capacity per hour: 45 racks per hour

Wash tank capacity: 9.0 gallons

Wash pump: 1/2 hp 440/3/60 TEFC

Steam Consumption (tank and booster) at 16 psi min: 19 lb/hr average

94lb/hrpeak

Final rinse flow at 20 psig: 4.1 gal/min peak at 140°F min

36 gal/hr average flow

0.8 gal/rack

Exhaust requirements: Not required.

Peak drain flow: 9 gal/min

Weight:

Shipping: 381 lbs.

Operating: Dishwasher: 180

Electrical control panel: 30 lbs.

Current draw on 440/3/60:

45SA5-F1: 1.4 amps (dishwasher and booster)

45SA5-F2: 3.1 amps (dishwasher)

9.9 amps (9 KW booster)

45SA5-F2D: 3.1 amps (dishwasher)

19.8 amps (18 KW booster)

45SA5-F2NM: 3.1 amps (dishwasher)

12.6 amps (11.4 KW booster)
