2. Getting started
2.1. Insert SIM Card
A local SIM card is required to operate the system. Before inserting the SIM card, try it with a mobile phone and:
• Disable PIN code protection
• Send an SMS to a mobile number for testing
After above steps; please open the screws on the back of the item and please insert SIM card into your device.
2.2. Connect Devices on Ports
NO PORT (Port1): Connect two wires of your NO type device output or cable into terminal block 5 & 6.
short-circuit between terminal 5 & 6.
NC PORT (Port2): Connect two wires of your NC type device output or cable into terminal block 7 & 8.
open-circuit between terminal 7 & 8.
Device provides required voltage by itself. Do not apply any external power on these terminal blocks
which might cause damages. Also make sure that your external device does not apply any voltage, or sink
or sank any currents. Your external device should only provide a relay output or short or open circuit.
2.3. Connect Power
Connect 12V DC power adaptor into terminal block numbers 1 and 2. Number 1 is positive voltage and 2 negative
(GND).
Please note power adaptor current should be at least 1500 mA.
Then insert two pieces of CR123A batteries included in the package. (If power adaptor is not used, insert batte-
ries only).
2.4. Register Admin Number
The LED will blink a few times until it is connected to an available network. Please wait for LED becomes solid ON.
Once LED is ON; that means device is connected to a GSM network and ready to work.
