Integral Technologies DVXi TS4 Bedienungsanleitung

Information in this document is subject to change without notice.

MasterControl and Integral Technologies are trademarks of Integral Technologies. Other trademarks

and trade names may be used in this document to refer to either the entities claiming the marks or

names or their products. Integral Technologies disclaims any proprietary interest in trademarks and

trade names other than its own.

Integral Technologies makes no warranty of any kind with regard to this material, including, but not

limited to, the implied warranties of merchantability and fitness for a particular purpose. Integral

Technologies shall not be liable for errors contained herein or for incidental or consequential

damages in connection with the furnishing, performance, or use of this manual.

Integral Technologies

9855 Crosspoint Blvd., Suite 126

Indianapolis, Indiana 46256 U.S.A.

User Manual

DVXi 4.0

April 2003

#3000-40060 Rev. 1

(continued)

TABLE OF CONTENTS

Introduction......................................................................................... 1

About the DVXi Series ..........................................................................................2

What This Manual Covers .....................................................................................3

Precautions...........................................................................................................4

Installation........................................................................................... 5

Installing DVXi TS4 and DVXi TBC4......................................................................6

Installing DVXi TS9 D and DVXi TBC9 D...............................................................8

Installing DVXi TS9 RM/TS16 and DVXi TBC9 RM/TBC16.................................. 10

Installing DVXi XM16 and DVXi XM32.................................................................12

Installing XMUX .................................................................................................. 14

Running the MasterControl Application................................................................ 16

Accessing the MasterControl Database...............................................................17

Changing the SQL Server Password ...................................................................18

Getting Familiar with MasterControl ............................................... 19

Overview of the MasterControl Screen ................................................................ 20

The Function Buttons..........................................................................................21

The Status Bar.................................................................................................... 22

MasterControl Configuration........................................................... 23

About the Setup Page .........................................................................................24

Adjusting the Video Display................................................................................. 25

Configuring Hardware .........................................................................................26

Naming Cameras ................................................................................................29

Configuring Disk Usage....................................................................................... 30

Defining MasterControl Users..............................................................................31

Configuring Motion Detection .............................................................................. 37

Understanding Motion Detection .........................................................................38

Assigning Cameras to Alarms .............................................................................42

Video Outputs and Touring .................................................................................45

Configuring Multi-Camera Output ........................................................................ 47

Configuring Onscreen Display on Video Outputs .................................................48

Archiving.............................................................................................................50

Configuring PTZ Cameras................................................................................... 56

MtCtlO ti 59

MasterControl Operation ................................................................. 59

Viewing Live Video on the Monitor Page .............................................................60

Selecting Recording Modes................................................................................. 66

Setting a Recording Schedule ............................................................................. 67

Searching for Recorded Video ............................................................................ 78

Viewing Recorded Video..................................................................................... 83

Exporting Captured Images and Video ................................................................84

Viewing Disk Usage ............................................................................................85

RemoteView ...................................................................................... 87

Introduction to RemoteView ................................................................................ 88

Connecting the Client and Server........................................................................ 89

Installing the RemoteView Software .................................................................... 89

Configuring a Dial-up Connection........................................................................ 90

Running the RemoteView Software ..................................................................... 93

Important Information About Passwords .............................................................. 94

Overview of the RemoteView Screen ..................................................................95

The Servers Page ...............................................................................................96

The Monitor Page ...............................................................................................98

The Search Page.............................................................................................. 104

The Setup Page ................................................................................................ 109

How RemoteView Admin Changes are Applied ................................................. 109

The Alarms Page .............................................................................................. 112

The Schedule Page........................................................................................... 113

RemoteView Server Settings............................................................................. 114

Appendix A: DVXi Plug-ins ............................................................ 115

Introduction to Plug-ins...................................................................................... 116

DVXMonitor Plug-in .......................................................................................... 117

MotionAlarm Plug-in.......................................................................................... 120

DVXNotify Plug-in ............................................................................................. 123

Appendix B: Synchronizing DVXi Clocks..................................... 129

Appendix C: Technical Support and Warranty Information........ 131

Introduction

Thank you for purchasing a DVXi digital event recorder, a high-tech moni-

toring and recording solution to cover all your security needs.

This chapter introduces you to your DVXi system and the structure of this

manual. Included in this chapter are the following:

•A description of the main parts of your DVXi system

•An outline of the chapters of this manual

Again, thank you for choosing a DVXi digital event recorder for your high-

tech security needs.

ABOUT THE DVXi SERIES

The DVXi digital event recorder is a high-tech monitoring and recording solution

that covers all your security needs. The following products are the heart of the

DVXi package:

•The DVXiTM box captures and compresses video for digital display from

up to 16 cameras for safe storage and easy access.

•MasterControlTM is the user-friendly software that allows you to easily

monitor and record video from multiple cameras. The simple configura-

tion instructions in this manual can help you set up MasterControl for

unattended recording for extended periods.

•Installed with XMUX (included with DVXi XM16 and DVXi XM32),

the DVXi system expands to as many as 32 video inputs.

•RemoteViewTM is an application that allows you to download and view

live and recorded video from DVXi over a network or dial-up connec-

tion. You can also connect to and even configure multiple DVXi systems

remotely.

•The DVXMonitor (optional), MotionAlarm, and DVXNotify plug-ins

are standalone applications that expand the reach of DVXi by recovering

from a system failure or communicating messages externally from the

system.

•XPVPlayer allows you to play back XPV files exported from the DVXi

system on a separate PC.

Introduction

WHAT THIS MANUAL COVERS

This manual takes you through the following topics, complete with illustrations,

step-by-step instructions, and detailed descriptions:

•Installation—includes instructions for installing the DVXi system and

running MasterControl for the first time.

•Getting Familiar with MasterControl—describes the basic setup of the

MasterControl screen. It also offers brief descriptions of each of the

MasterControl functions.

•MasterControl Configuration—helps you set up MasterControl for

everyday use. For example, it includes information on setting up user

permissions, naming cameras, and configuring hardware to your desired

performance level.

•MasterControl Operation—explains the primary functions of

MasterControl. From viewing and capturing video to learning the impor-

tant scheduling feature, this chapter shows you how to actually operate

MasterControl for your daily security needs.

•RemoteView—describes the RemoteView software, including details

about downloading live and recorded video from a remote client PC.

•Appendix A: DVXi Plug-ins—describes the standard and optional

standalone applications available on a DVXi system.

•Appendix B: Synchronizing DVXi Clocks—describes a procedure that

allows you to synchronize the Windows time of multiple DVXi systems

to a master source on a network.

•Appendix C: Technical Support and Warranty Information

If you require further assistance with your DVXi system than this manual offers,

please refer to the technical support information available in Appendix C.

LITHIUM BATTERY—DANGER

The battery should be replaced only by a service technician. The

battery is a non-operator-replaceable cell. There is danger of explo-

sion if the battery is incorrectly replaced. Replace only with the same

or equivalent type recommended by the manufacturer. Dispose of

used batteries according to the manufacturer’s instructions.

Caution

RISK OF ELECTRIC SHOCK—DO NOT OPEN

To reduce risk of electric shock, do not remove the cover or back of

the DVXi system. There are no user-serviceable parts inside. Refer

servicing to qualified personnel only.

Caution

PRECAUTIONS

Installation

The installation of your DVXi system consists of connecting the box to its

peripheral equipment (monitor, mouse, and so on) and XMUX (DVXi XM16

and DVXi XM32 only). This chapter contains specific instructions for the

following:

•Installing DVXi TS4 and DVXi TBC4

•Installing DVXi TS9 D and DVXi TBC9 D

•Installing DVXi TS9 RM/TS 16 and DVXi TBC9 RM/TBC16

•Installing DVXi XM16 and DVXi XM32

•Installing XMUX

•Running the MasterControl application for the first time

•Accessing the MasterControl database and changing the SQL

password

Please pay special attention to the cautions and tips throughout the chapter.

INSTALLING DVXi TS4 and DVXi TBC4

Use Figure 1 to complete the following installation instructions.

1. Plug the power cord into the power connector (A).

2. Plug the mouse into the mouse connector (B).

3. Plug the keyboard into the keyboard connector (C).

4. To provide a network or dial-up connection, connect a network cable to

the network connector (D) or a phone line to the optional modem (H).

5. Plug the monitor into the monitor connector (E) and electrical outlet.

6. (Optional) Wire the alarms to the green trigger block (F). From top to

bottom are board inputs 1–8, an output, and three grounds. On the

MasterControl Alarms tab, the inputs are named Board Alarm 1, Board

Alarm 2, and so on. Connect only to voltages below 42V DC; external

devices connected to the DVXi system should be in a SELV, non-energy

hazardous circuit.

7. Connect up to four cameras to the row of BNC connectors (G). Inputs are

labeled 1 through 4 from bottom to top.

8. (Optional) Connect your PTZ cameras to the RS-422 port (J) as described

in the PTZ installation manual.

9. Plug the power cord into an electrical outlet.

10. To provide power to the DVXi box, use the power switch on the rear

panel (K).

11. To turn on the DVXi system, use the power switches on the front panel of

the box and on the monitor.

Installation

Figure 1

The rear panel of DVXi 4-camera systems. The placement of system components may

vary depending on which options are installed.

KABCE GD

REAR PANEL OF DVXi TS4 and DVXi TBC4

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Integral Technologies Netzwerk-Hardware Handbücher

Integral Technologies

Integral Technologies DS NVR Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
