Document Number: 323874-002

Intel® Pentium® P6000 and U5000

Mobile Processor Series

Specification Update

June 2010

Revision 002

2xxx

Legal Lines and Disclaimers

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED,

BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS

PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER,

AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING

LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY

PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving,

life sustaining, critical control or safety systems, or in nuclear facility applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined.” Intel

reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future

changes to them.

Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family,

not across different processor families. See http://www.intel.com/products/processor_number for details.

The processor may contain design defects or errors known as errata which may cause the product to deviate from published

specifications. Current characterized errata are available on request.Contact your local Intel sales office or your distributor to

obtain the latest specifications and before placing your product order.

Intel, Intel Core, Centrino, Celeron, Pentium, Intel Xeon, Intel SpeedStep and the Intel logo are trademarks or registered

trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.

Specification Update 3

Contents

Preface......................................................................................................................5

Summary Tables of Changes......................................................................................7

Identification Information.......................................................................................15

Errata......................................................................................................................17

Specification Changes..............................................................................................45

Specification Clarifications ......................................................................................46

Documentation Changes.......................................................................................... 47

4Specification Update

Revision History

Revision Description Revision

Date

-001 • Initial release May 2010

-002 • Added P6000 sku information June 2010

Specification Update 5

Preface

This document is an update to the specifications contained in the Affected Documents

table below. This document is a compilation of device and documentation errata,

specification clarifications and changes. It is intended for hardware system

manufacturers and software developers of applications, operating systems, or tools.

Information types defined in Nomenclature are consolidated into the specification

update and are no longer published in other documents. This document may also

contain information that was not previously published.

Affected Documents

Related Documents

NOTES:

1. Documentation changes for the Intel® 64 and IA-32 Architecture Software Developer's Manual Volumes

1, 2A, 2B, 3A, and 3B will be posted in a separate document, the Intel® 64 and IA-32 Architecture

Software Developer's Manual Documentation Changes. Follow the link http://developer.intel.com/

products/processor/manuals/index.htm to access this documentation.

Document Title Document

Number

Location

Intel Pentium P6000 and U5000 Mobile Processor Series Datasheet 323873

Intel® Core™ i7-600, i5-500, i5-400 and i3-300 Mobile Processor Series

Datasheet - Volume 1 and Volume 2 322812,

322813

Document Title Document Number/

Location

AP-485, Intel® Processor Identification and the CPUID

Instruction http://www.intel.com/

design/processor/applnots/

241618.htm
