Intel®InBusiness™

Internet Station

User’s Guide

Intel Corporation

5200 NE Elam Young Parkway

Hillsboro OR 97124-6497

If you have general networking questions or need information about other Intel

products, call our Answers Line at 1-800-538-3373. Locate Customer Support

phone numbers and RMA information in Doing Business with Intel.

“Year 2000 Capable”

An Intel product, when used in accordance with its associated documentation, is

“Year 2000 Capable” when, upon installation, it accurately stores, displays,

processes, provides, and/or receives date data from, into, and between the

twentieth and twenty-first centuries, including leap year calculations, provided that

all other technology used in combination with said product properly exchanges

date data with it.

Intel Corporation assumes no responsibility for errors or omissions in this

publication, nor does Intel make any commitment to update the information

contained herein.

*Other product and corporate names may be trademarks of other companies and

are used only for explanation and to the owners’ benefit, without intent to infringe.

First Edition January 1999 PN 692807-002

Table of Contents

Overview .....................................................................................................5

Features ..........................................................................................5

Compatibility..................................................................................6

New Technologies.................................................................................7

InstantIP technology .......................................................................7

Modem Aggregation .......................................................................8

Modem Pooling ..............................................................................9

Auto Connect/Disconnect...............................................................9

Before You Begin ......................................................................................10

Order an ISP account ..........................................................................10

If you don’t have an ISP account..................................................11

If you already have an ISP account ..............................................11

Order telephone lines ...................................................................11

Order an ISDN line.......................................................................12

Get Connected ...........................................................................................13

Connect your equipment .....................................................................13

Connect the network cable ...........................................................14

Connect your modem or ISDN adapter ........................................14

Connect the power cord................................................................14

Organize your cables ....................................................................14

Front panel LEDs .........................................................................15

Internet Station Installation CD-ROM ................................................15

Use the Internet Station .............................................................................17

Set up workstations to browse ............................................................17

Manual setup .......................................................................................17

To configure a Windows NT 4.0 system ......................................17

To configure a Windows 95 system..............................................18

To configure other systems...........................................................18

Modem Pooling Installation on Workstations.....................................18

To install Modem Pooling ............................................................19

To install modem drivers ..............................................................19

Uninstall Internet Station software...............................................20

Modem Compatibiltiy List..................................................................20

Troubleshooting.........................................................................................21

Problems during initial installation ..............................................21

Problems during client installation...............................................21

Other Internet Station problems ...................................................22

Online Troubleshooting Information ..................................................23

Specifications and Compatibility ..............................................................25

Specifications List ........................................................................25

Software Compatibility List .........................................................26

Compliance and License Agreements........................................................27

Certification Statements ...............................................................27

Intel®InBusiness™ Internet Station

Overview

The Intel®InBusiness™ Internet Station is a powerful, yet simple communica-

tions device. When you use the Internet Station, networked computers have

simultaneous access to the Internet through a single Internet account.

The Internet Station Installation CD-ROM detects your network configurations. It

then offers specific setup options, based on your configurations, which help you

set up your network to use the Internet Station. Browser-based configuration

software walks you through a simple setup. This helps you get your Internet

Station up and working without investing a lot of time.

The Auto Disconnect feature makes sure that your ISP connection is off when it is

not in use. The Internet Station’s revolutionary InstantIP™ technology automati-

cally takes care of all network configurations. Two PC Card slots and one serial

port make the product flexible enough to grow with your network changes.

Modem Aggregation, the Internet Station’s newest feature, combines the speed of

two or three analog modems for faster Internet access.

With the Internet Station’s Modem Pooling feature, use additional modems for

faxing and data transmission to online services. Modem Pooling allows shared

access to the modems connected to the Internet Station.You can use the modems

available for pooling in the same way as you would a modem attached to your PC.

Features

•Shared, simultaneous Internet access for your network through a single Internet

account

•ISDN adapter or analog modem support for Internet connections

•Two PC Card slots and one serial port for easy modem upgrades

•Modem Aggregation for increased Internet access speed

•Modem Pooling gives users shared modem access for fax or data transfer

•Auto connect and disconnect makes sure that the ISP connection is available

when needed

•Simple network connection through the built-in 10Base-T Ethernet port

•InstantIP technology for automatic configuration of Internet protocols

6 Intel®InBusiness™ Internet Station

•Web browser-based configuration for fast and simple Internet setup

•Microsoft Internet Explorer* and Modem Pooling software included

Sending email over the Internet is easy using the email program included with

Internet Explorer or another email package. Email allows you to communicate

without the long distance charges.You only pay for your ISP account, usually

accessed through a local call.You can complement the power of the Internet

Station with the Intel®InBusiness™ eMail Station. The eMail Station coordinates

and manages your email services. For more information on the eMail Station, see

the product brochure in your Information Packet.

Compatibility

The Internet Station is compatible with other network products from Intel and

most manufacturers, this includes network adapters, print servers, hubs, switches,

and other networked devices. It is also compatible with any 10Base-T hub.

The Internet Station features automatic setup and web browser installation

compatible with Windows* 95, Windows 98, and Windows NT* 4.0 operating

systems.

Intel®InBusiness™ Internet Station

Any computer with Internet Explorer* 4.01, or Netscape Navigator* or Commu-

nicator* 4.06 (or newer versions of each) can access the Internet through the

Internet Station.

New Technologies

The Internet Station offers many new technologies that make your company’s

Internet access easier to manage.

InstantIP technology

InstantIP technology is a powerful feature of the Internet Station. It provides

simplified setup and administration of complicated Internet addresses. The

InstantIP technology design allows both beginner and experienced users to make

their network Internet-ready in minutes. InstantIP technology saves money on

additional software and Internet addresses that you may have to purchase. It also

provides advanced security features that protect computers, servers, and files on

the local network from external intrusions such as hackers on the Internet.

InstantIP technology combines four key functions: Dynamic Host Control

Protocol (DHCP), Network Address Translation (NAT), Domain Name Services

(DNS), and Dynamic Addressing.

DHCP

Dynamic Host Control Protocol is a standard that dynamically allocates

or leases Internet Protocol (IP) addresses to individual computers on the

local network. The Internet Station has a pool of addresses pre-installed.

Choose to use this range of addresses or a range that you have already set

up on your network. DHCP also configures the computers to automati-

cally use the Internet Station as their gateway to the Internet. The

alternative to DHCP is to manually configure the TCP/IP settings of

every computer on the network.

NAT

Network Address Translation translates IP addresses on the private

network (the Local Area Network) through a single IP address used by

the Internet Station. In other words, while multiple users are accessing

the Internet through the product, the public side (the Internet) only sees

the address of the Internet Station. When used in combination with

8 Intel®InBusiness™ Internet Station

DHCP, NAT alleviates the cost and complexity of having an IP address

for every computer on the network.

DNS

Domain Name Services simplifies Internet usage by mapping domain

names, a unique name that identifies the Internet site, to IP addresses, a

unique Internet Protocol number. It allows users to set up a distinct

domain name for a group of computers or other resource. DNS, for

example, allows the user to enter the more familiar domain name,

istation, instead of the IP address, 192.168.42.254, to communicate with

the Internet Station.

Dynamic Addressing

Dynamic Addressing on the Internet Station automatically accepts an IP

address assigned by your ISP every time you dial in. It also eliminates

complex configuration of the box.You can configure the Internet Station

to accept static addressing. Static addressing uses the same IP address

each time the Internet Station connects to your ISP.

Benefits of InstantIP technology

Cost Savings: requires less time and technical assistance

Increased Network Security: the outside only sees the Internet Station address

Simple IP Address Administration: automatic setup and maintenance

Flexibility: allows for dynamic and static configuration

To read more about InstantIP technology, access the white paper at http://

support.intel.com/support/inbusiness/internetstation.

Modem Aggregation

Modem Aggregation, a new feature for the Internet Station, improves the Internet

Station’s ability to increase the speed of access to the Internet. Modem Aggrega-

tion works by combining the speeds of 2-3 analog modems attached to the

Internet Station. When you want to send or receive information through the

Internet, the Internet Station detects which modem is free and uses that line. The

information you are sending or receiving does not have to wait in a queue until a

single modem’s line is free.

We refer to this technology as Multilink Protocol over Analog Lines and Analog

Bonding. To use the Modem Aggregation feature, your ISP must support Multilink

Intel®InBusiness™ Internet Station

technologies. If the ISP supports Multilink, you need to consider any additional

charges for its use.

Benefits of Modem Aggregation

Faster Internet and Information Transfer Access: decrease time spent on tasks

Readily Available Hardware: analog modems are readily available

Cost Savings: no need to pay for ISDN to increase access speed

Modem Pooling

Modem Pooling allows all users connected to the network access to the modems

connected to the Internet Station. Use extra modems for fax, data transfer, etc.

When you need to access a modem, select the program you want to use for your

task (DialUp Network, Microsoft Fax, etc.). The Modem Pooling software locates

an available modem and sends your file to it as if the modem where attached to

your PC. If you choose to use the Modem Pooling feature, you must assign at

least one of your modems for that purpose. Modems cannot be used for Internet

access and pooling at the same time. Each computer that will access the modem

pool needs to have the Modem Pooling software installed.

Benefits of Modem Pooling

Cost Savings: fewer modems and telephone lines

Office Wide Access to Modems for Fax and Data Transfer: easier task manage-

ment

Auto Connect/Disconnect

The Auto Connect/Disconnect feature makes sure that the connection to the ISP is

available when needed and off when not in use. The Internet Station configuration

looks for packets of information meant for the Internet. When the Internet Station

detects a packet, it automatically dials the ISP. Once connected a timer starts and

counts down to zero. When the timer reaches zero the Internet Station automati-

cally disconnects.

Benefits of Auto Disconnect

Cost Savings: do not pay for continuous access to ISP

Automatic Connection and Disconnection to the ISP: ease of account maintenance

To read more about Auto Disconnect technology, access the white paper at http://

support.intel.com/support/inbusiness/internetstation.

10 Intel®InBusiness™ Internet Station

Before You Begin

Before you begin to connect the Internet Station hardware or install the software,

you must have your hardware, software, and ISP services available. The Specifi-

cations and Compatibility section lists many options that the Internet Station

supports. Use these lists to make your hardware and software choices.

To configure the Internet Station you need a PC that uses Microsoft Windows 95,

98, or Windows NT 4.0 operating system. The PC must have a compatible web

browser. Compatible browsers are Microsoft Internet Explorer 4.01 and Netscape

Navigator or Communicator 4.06. The Internet Station Installation CD-ROM

contains a copy of the Microsoft Internet Explorer 4.01. If you do not have a

browser and choose to use Microsoft Internet Explorer, install it from the Installa-

tion CD-ROM.

To access the Internet you need

•an Internet Service Provider (ISP) account.

•an analog modem or ISDN terminal adapter.

•a dedicated telephone or ISDN line.

•computers connected to an Ethernet network.

ØNote: Modem Pooling and Modem Aggregation

The Internet Station supports up to three modems. Only one modem is required

for Internet access.To use Modem Aggregation, install up to three analog

modems for faster Internet access. Use the other modems for faxing and data

transmission to online services. Modem Pooling allows shared access to the

modems connected to the Internet Station.You can use the modems available

for pooling in the same way as you would a modem attached to your PC.

Order an ISP account

The first step is to order your ISP account. The ISP you select must use technolo-

gies compatible with the way you want to use your Internet Station. Review the

Internet Station features in the Overview section and make your decisions about

their use before you choose your ISP.

Inhaltsverzeichnis

Andere Intel Netzwerkkarte Handbücher

Intel

Intel NetportExpress PRO Bedienungsanleitung

Intel

Intel 10 Gigabit AF DA Dual Port Server Adapte Referenzhandbuch

Intel

Intel Intel Device View Bedienungsanleitung

Intel

Intel ETHEREXPRESS PRO/100 Bedienungsanleitung

Intel

Intel 82541PI Leitfaden

Intel

Intel DK50 Series Bedienungsanleitung

Intel

Intel PCMCIA Bedienungsanleitung

Intel

Intel AnyPoint Wireless II Network Bedienungsanleitung

Intel

Intel X520 SFP+ Bedienungsanleitung

Intel

Intel 8 LAN Technisches Handbuch

Intel

Intel PRO/Wireless 2011B LAN USB Device WUD2011BWW Bedienungsanleitung

Intel

Intel Altera M0344-ND Bedienungsanleitung

Intel

Intel Wireless WiFi Link 4965AGN Bedienungsanleitung

Beliebte Netzwerkkarte Handbücher anderer Marken

FirstComm

FirstComm OBiWiFi5G Bedienungsanleitung

Sun Microsystems

Sun Microsystems Interface Adapter Bedienungsanleitung

TRENDnet

TRENDnet TU2-ETG Bedienungsanleitung

YASKAWA

YASKAWA SI-EN3 Bedienungsanleitung

Paradyne

Paradyne BitStorm 2600 IP DSLAM Bedienungsanleitung

Belkin

Belkin F5D7050 Bedienungsanleitung

3Com

3Com EtherLink 3C509B Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITX Bedienungsanleitung

Cisco

Cisco MC16E Bedienungsanleitung

Delta Electronics

Delta Electronics Braking Modules VFDB Series Bedienungsanleitung

TwinMOS

TwinMOS Booming Bedienungsanleitung

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Bedienungsanleitung

Buffalo

Buffalo AirStation WLI-PCM-L11GP Bedienungsanleitung

National Instruments

National Instruments NI 9234 Bedienungsanleitung

Hama

Hama 49276 Bedienungsanleitung

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Bedienungsanleitung

Compaq

Compaq Wireless LAN 100 Bedienungsanleitung

Bose

Bose PowerMatch Dante Bedienungsanleitung
