Intel®ServerBoardS5520HC,

Intel®ServerBoardS5500HCV,

Intel®ServerBoardS5520HCT,

Intel®WorkstationBoardS5520SC,

Intel®ServerChassisSC5600,

Intel®ServerChassisSC5650,

Intel®ServerSystemSC5650HCBRP,

Intel®WorkstationSystemSC5650SCWS

SparesPartsList&ConfigurationGuide

A reference guide to assist customers in ordering the necessary components to configure the

Intel®Server Board S5520HC, Intel® Server Board S5520HCT, Intel®Server Board S5500HCV,

and Intel®Workstation Board S5520SC with appropriate Intel chassis.

Rev 1.09

January, 2010

~ Subject to Change ~

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED

BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH

PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED

WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES

RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,

Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to

specifications and product descriptions at any time, without notice.

Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States and other countries.

*Other names and brands may be claimed as the property of others.

Contents

Contents ..........................................................................................................3

Production Configuration.............................................................................4

Production Board SKUs..............................................................................8

Production System ....................................................................................10

Production Chassis....................................................................................12

Production Spares and Accessories ........................................................14

Production RAID Accessories (not including BBU).................................20

Production RAID Controller.......................................................................20

Intel Tested Memory List...........................................................................22

Intel THOL List...........................................................................................22

Intel® System Management Software – (Upgrade SKUs)......................24

Production Intel®Xeon Processor 5500 Series.......................................26

Production Intel Thermal Solution STS100 Series..................................27

Heat Sink Configuration Guide.................................................................27

VMware* vSphere* Virtualization Software Configuration Guide for vSphere* SKUs 28

Product Descriptions – Overview..............................................................28

VMware vSphere* and vCenter* Server SKUs........................................28

Production Configuration

This section contains information needed to order and configure the Intel®Server System SC5650HCBRP, Intel®

Workstation System SC5650SCWS, and Intel®Server Chassis SC5600, SC5650 Family with Intel®Server Board

S5520HC, S5520HCT and S5500HCV and Intel®Workstation Board S5520SC.

1) Production boxed Intel Server Boards contain the following:

•One baseboard with unified back plate assembly

•ATX I/O shield

•Cables: Serial B (COM2), 4 SAS/SATA cables

•Resource CD-ROM with utilities, drivers, documentation and technical information* (does not ship with

S5520HCT)

•Quick Start User’s Guide and Quick Reference Label

•ISMS 3.1 DVD * (does not ship with S5520HCT)

•Compatible with Intel®Xeon®processor 5500 series

2) Production OEM 10-packs of Intel Server Boards contain the following:

•One baseboard with unified back plate assembly

•Compatible with Intel®Xeon®processor 5500 series

3) The production SC5600LX KDK is compatible with the Intel®Server Boards S5520HC and S5500HCV. it

includes:

•Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support (2nd

redundancy 750W high efficiency PFC module included)

•Four redundant, hot-swap fans and ducting

•Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-

swap SAS or SATA drives.

•Quick Start User’s Guide and Configuration Label

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cords are included only in SC5600LXNA

•Five Bumpers for installing Intel®Server Board S5520HC or S5500HCV

•The Intel®Server Chassis SC5600LX is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power and FXXRGTHSINK or FXXRGTHS tower heat sink accessory (required).

4) The production Intel®Server Chassis SC5600BRP KDK is compatible with the Intel® Server Boards S5520HC

and S5500HCV. it includes:

•Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support

(2nd redundancy 750W high efficiency PFC module included)

•Three non-redundant fixed cooling fans with ducting

•Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-

swap SAS or SATA drives.

•Quick Start User’s Guide and Configuration Label

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cords are included only in SC5600BRPNA

•Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV

•The Intel®Server Chassis SC5600BRP is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

5) The production Intel®Server Chassis SC5600 Base KDK is compatible with Intel®Server Chassis S5520HC,

S5500HCV, and Intel® Workstation Board S5520SC. It includes:

•Non-redundant 670W PFC power supply

•Three non-redundant fixed cooling fans with ducting

•Support for six tool free non hot-swap hard drives. Upgradeable to 6 hot-swap SAS or SATA.

•Quick Start User’s Guide and Configuration Label

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cord is included only with SC5600BASENA.

•Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV, and Intel®Workstation Board

S5520SC.

•The Intel®Server Chassis SC5600BASE is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

6) The production Intel®Workstation Chassis SC5650WS SKU is compatible with the Intel®Workstation Board

S5520SC. It includes:

•Non-redundant 1000W high efficiency PFC power supply

•Three non-redundant fixed cooling fans with ducting

•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

•Quick Start User’s Guide

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is included only with SC5650WSNA

•Chassis intrusion switch assembly

•Five Bumpers for installing Intel®Workstation Board S5520SC.

•The chassis is designed to work with Intel®Xeon®processor 5500 series with 130W maximum power, and

is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

7) The production Intel®Server Chassis SC5650DP SKU is compatible with the Intel®Server Board S5520SC,

S5500HCV, and S5500BC. It includes:

•Non-redundant 600W PFC power supply

•Three non-redundant fixed cooling fan with ducting

•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

Note: Check the Power budget spreadsheet for supportable hard drive, memory and PCI configurations.

•Quick Start User’s Guide

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is only included in SC5650DPNA

•Chassis intrusion switch assembly

•Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.

•The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power, and is

compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.

8) The production Intel®Server Chassis SC5650BRP SKU is compatible with the Intel®Server Board S5520SC,

S5500HCV, and S5500BC. It includes:

•Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full

redundancy requires additional 600W module purchased separately)

•Three non-redundant fixed cooling fan with ducting

•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

•Quick Start User’s Guide

•Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is only included in SC5650BRPNA

•Chassis intrusion switch assembly

•Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.

•The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power, and is

compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.

9) The Intel®Server System SC5650HCBRP includes:

•Intel®Server Board S5520HC pre-installed in the Intel®Sever Chassis SC5650BRP

•Expander-based Intel® Hot Swap Drive Bay AXX6DRV3GEXP pre-installed with cooling and mounting kit

(APP3HSDBKIT) in the Intel®Server Chassis SC5650BRP (Require SAS add-in card or SAS module

purchased separately)

•Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full

redundancy requires additional 600W module purchased separately)

•Three non-redundant fixed cooling fan with ducting

•Quick Start User’s Guide and Configuration Label

•Cables (one each)

oFront Panel Cable (baseboard header to front panel, pre-routed))

oUSB Cable (USB header to chassis front panel, pre-routed)

oAdapter Cable providing two additional SATA power connectors (in cable kit)

oAC power cord is only included in SC5650HCBRPNA

•Chassis intrusion switch assembly (pre-routed)

•The server system is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power,

and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.

10) The Intel®Workstation System SC5650SCWS includes:

•Intel®Workstation Board S5520SC pre-installed in the Intel®Sever Chassis SC5650WS

•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

•Non-redundant 1000W high efficiency PFC power supply

•Three non-redundant fixed cooling fan with ducting

•Quick Start User’s Guide and Configuration Label

•Cables (one each)

oFront Panel Cable (baseboard header to front panel, pre-routed))

oUSB Cable (USB header to chassis front panel, pre-routed)

oAdapter Cable providing two additional SATA power connectors (in cable kit)

oAC power cord is only included in SC5650SCWSNA

•Chassis intrusion switch assembly (pre-routed)

•The workstation system is designed to work with Intel®Xeon®processor 5500 series with 130W maximum

power, and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.

11) Common accessories include:

Hot Swap Drive Bays:

– AXX6DRV3GEXP: Expander-based 6-drive bay that supports SAS/SATA drives. Requires two free

SAS ports from the SAS personality module or SAS RAID card.

– AXX4DRV3GEXP: Expander-based 4-drive bay that supports SAS/SATA drives. Requires two free

SAS ports from the SAS module or SAS RAID card. Only supported in Intel®Server Chassis

SC5600BRP, and SC5600LX.

– AXX6DRV3GR: 6-drive bay that supports SAS/SATA drives. Requires six free SAS or SATA ports.

SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card.

Support 6Gb SAS Hard Drives with compatible 6Gb SAS adapters

– AXX4DRV3GR: 4-drive bay that supports SAS/SATA drives. Requires four free SAS or SATA ports.

SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card.

Only supported in Intel®Server Chassis SC5600BRP and SC5600LX. Support 6Gb SAS Hard Drives

with compatible 6Gb SAS adapters.

AXX750WPS: Spare 750W power supply module for Intel®Server Chassis SC5600LX and SC5600BRP

ARIGRACK: Rack conversion kit (SC5600BASE, SC5600BRP and SC5600LX)

APP3RACKIT: Rack conversion kit (SC5600 chassis family).

AXXRAKSW5: Intel®RAID Activation Key AXXRAKSW5 to enable Intel Embedded RAID technology II for SAS

and/or SATA Software RAID 5 on S5520HC, S5500HCV, and S5520SC boards.

APPT600WHPSU: Additional 600W power supply module- required for full redundancy for SC5650BRP only.

APPTHSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis

family. This kit should be used with AXX6DRV3GR

APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis

family. This kit should be used with AXX6DRV3GEXP.

AXX25DRVADPTR: 2.5” hard drive carrier kit for installing 2.5” SATA or SAS hard drive or Solid State Drive into

3.5” hot swap drive bay

Production Board SKUs

Picture Product Code MM # UPC MOQ Description

S5520HC 900402 00735858207485 5 Boxed Intel

Server Board S5520HC. (Includes

I/O shield, cables, resource CD and ISMS DVD)

S5520HCR 905721 00735858213783 5 Boxed Intel

Server Board S5520HCR.(Includes

I/O shield, cables, resource CD and ISMS DVD)

BB5520HC 901640 00735858207492 10 Bulk pack of the Intel

Server Board S5520HC

BB5520HCR 905718 00735858213790 10 Bulk pack of the Intel

Server Board S5520HCR

S5520HCT 904912 00735858213776 1 Boxed Intel

Server Board S5520HCT. (Includes

I/O shield, cables)

S5500HCV 902386 00735858207508 5 Boxed Intel

Server Board S5500HCV. (Includes

I/O shield, cables, resource CD and ISMS DVD)

S5500HCVR 905723 00735858213820 5 Boxed Intel

Server Board S5500HCVR.

(Includes I/O shield, cables, resource CD and

ISMS DVD)

BB5500HCV 902387 00735858207515 10 Bulk pack of the Intel

Server Board S5500HCV

BB5500HCVR 905720 00735858213875 10 Bulk pack of the Intel

Server Board

S5500HCVR

S5520SC 900963 00735858207522 5 Boxed Intel

Workstation Board S5520SC.

(Includes I/O shield, cables, resource CD and

ISMS DVD)

S5520SCR 905722 00735858213806 5 Boxed Intel

Workstation Board S5520SCR.

(Includes I/O shield, cables, resource CD and

ISMS DVD)

BB5520SC 901634 00735858207539 10 Bulk pack of the Intel

Workstation Board

S5520SC.

BB5520SCR 905719 00735858213813 10 Bulk pack of the Intel

Workstation Board

S5520SCR.

MOQ = Minimum Order Quantity.

Production System

Picture Product Codec MM # UPC MOQ Description

SC5650HCBRP 904553 00735858212557 1 Intel

Server System SC5650HCBRP with

(1+0) PMBus-compliant 600W Redundant

power supply, 3 fixed chassis fans with

ducting, rackable with optional rack kit.

Supports up to 6 Hot-Swap drives (SAS or

SATA, require SAS add-in card or SAS

module purchased separately). Supports up

to 95W processor. No power cord or heat

sinks included.

SC5650HCBRPR 907331 TBD 1 Intel

Server System SC5650HCBRPR with

(1+0) PMBus-compliant 600W Redundant

power supply, 3 fixed chassis fans with

ducting, rackable with optional rack kit.

Supports up to 6 Hot-Swap drives (SAS or

SATA, require SAS add-in card or SAS

module purchased separately). Supports up

to 95W processor. No power cord or heat

sinks included.

SC5650HCBRPNA 903806 00735858213196 1 Same as Intel

System SC5650HCBRP

with North American power cord included.

No heat sinks included.

SC5650HCBRPRN

A 905764 TBD 1 Same as Intel

System SC5650HCBRPR

with North American power cord included.

No heat sinks included.

SC5650SCWS 904581 00735858212571 1 Intel

Workstation System SC5650SCWS

with 1000W fixed PSU, supports up to two

150W workstation graphics cards or single

300W workstation graphics card, 3 fixed

chassis fans with ducting, rackable with

optional rack kit, supports up to 6 fixed

drives, upgradeable to 6 Hot-Swap drives

(SAS or SATA). Supports up to 130W

processor. No power cord or heat sinks

included.

SC5650SCWSR 907332 TBD 1 Intel

Workstation System SC5650SCWSR

with 1000W fixed PSU, supports up to two

150W workstation graphics cards or single

300W workstation graphics card, 3 fixed

chassis fans with ducting, rackable with

optional rack kit, supports up to 6 fixed

drives, upgradeable to 6 Hot-Swap drives

(SAS or SATA). Supports up to 130W

processor. No power cord or heat sinks

included.

Andere Handbücher für S5520HC

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Netzwerk-Hardware Handbücher

Intel

Intel NetStructure 1300 Series Bedienungsanleitung

Intel

Intel 82543GC Technisches Handbuch

Intel

Intel 21555 Bedienungsanleitung

Intel

Intel Express 140T Bedienungsanleitung

Intel

Intel SS4200-E - Entry Storage System NAS Server Stücklistenhandbuch

Intel

Intel PRO/Wireless 2011B LAN USB Device Bedienungsanleitung

Intel

Intel 82540EP Bedienungsanleitung

Intel

Intel 41210 Leitfaden

Intel

Intel Intel 8x930Ax Bedienungsanleitung

Intel

Intel IXF1104 Bedienungsanleitung

Intel

Intel IXP45X Bedienungsanleitung

Intel

Intel SR2400 Bedienungsanleitung

Intel

Intel SE7210TP1SCSI Montageanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
