IP Camera

USER GUIDE

This guide will explain how to set up a basic configuration for accessing and IP camera remotely using the eSAM

router.

To achieve this, we will follow the following steps

1. Enable remote access on the modem

2. Port Forward from the modem to the IP Camera so we can access it remotely.

3. Create a Dynamic DNS (DDNS) URL we can use to access the modem remotely without needing to know its

IP Address

Please consult the instruction manual of your IP camera before proceeding, as different cameras may operate in

different ways.

If you have any queries regarding the eSAM, please contact Intercel technical support at i[email protected]om.au.

In this section we will configure an eSAM to be easily accessed over the internet.

1. Use your web browser to connect to the eSAM. By default, this can be done by connecting your computer to

the eSAM’s Ethernet port and entering the IP Address http://192.168.1.1 into your web browser. You should

be presented with the screen below

2. Log into the eSAM. The default login details are:

Username: admin

Password: admin

(You should change these details for security reasons.)

3. For this guide, you will need to have a SIM card that provides you with a public IP address. This may be, for

example, a Telstra.extranet SIM Card.

4. Open the ‘Security>Remote Access’ screen. Enable WEB Access. Telnet and SSH are not required for this

guide, so we can leave them disabled. Press ‘Save’ to save the settings.

5. Open the ‘Status>Modem’ screen.

Please confirm that your modem has been assigned a public IP address. Public IP Addresses are any

addresses that are not in any of the following ranges:

10.x.x.x

192.x.x.x

If your device has not been assigned a Public IP Address, you may need to adjust your APN Settings or to

contact your ISP

6. Copy the IP Address from step 5 and paste it into your URL bar.

Press enter to access the modem using its public IP.

You should now be able to unplug the modem from your computer and still access it.

In this section we will configure port forwarding on the eSAM to access an IP Camera.

1. First, I will need to access the Camera from my computer. To do this I first read the IP address from the IP

Camera’s manual. The manual tells me that out of the box the Camera has the IP Address 192.168.1.158 –

please double check the manual of your camera to check that this is the same.

For the IP Camera and the Modem to communicate, they must both have an IP address on the same subnet

(the first three number of the IP address must match). I can accomplish this either by setting the IP Camera’s

IP to match that of the eSAM or changing the IP of the eSAM to match that of the Camera.

For this example I’ll change the IP of the eSAM to match the subnet of the camera.

So, I will change the eSAM’s local IP Address to 192.168.1.1 so it can communicate with the IP Camera at

192.168.1.158

Open the ‘Network > LAN’ screen on the modem

And change IP1 to 192.168.1.1. Press ‘Save’ to save your changes.

Please reboot the modem after changing the IP, to avoid confusing any devices already connected to it.

Note: If your webcam is assigned an IP by DHCP, or has an IP Address in the correct subnet, you will not

have to perform this step. Please contact Intercel technical support at [email protected].au if you have

any questions about your specific IP Camera Model.

2. Now connect the webcam to the Ethernet port of the eSAM. After connecting the two together, open the

‘System > Network Test’ Screen.

Enter the IP Address of the Camera into the ‘destination’ field and press ping. If the modem can communicate

with the Camera, then the Result field will show that a series of successful ping messages have been sent

from the modem to the IP Camera.

If you do not see a screen like this, then it indicates that the modem and IP Camera are not configured

correctly. In this case, please ensure that the modem and the camera are both on the same subnet.

3. Now that the camera and modem can communicate, we can add a port forwarding rule to forward traffic from

the modem’s internet-facing IP address to the IP Camera’s local IP address.

Open the ‘Forward> NAT’ screen

Press the ‘Add’ Button. Enter the details for your webcam as described below:

Interface: modem

Original Port: 8080

Mapping Address: The IP Address of the Camera (for this Camera, it is 192.168.1.158)

Mapping Port: 80 (the port for the web GUI of the IP Camera)

Press Save to save this rule.

Your ‘Forward> NAT’ screen should now look like this:

4. Now that we have forwarded a port for the IP Camera to use, we should be able to access it remotely using

the public IP Address.

Open a browser window and enter the public IP of your modem, followed by ‘:8080’. This tells the web

browser that we want to communicate with port 8080, which is the port we forwarded to the IP camera.

For this example, I must browse to http://120.157.66.109:8080/. Please replace ‘120.157.66.109’ with the

public IP address of your modem.

I can now access the IP Camera remotely from anywhere with an internet connection.

The port forwarding we are using works like this:

The modem acts as a go-between, using its NAT table to decide what it should do when sent data from

outside the network. Using the port the data was sent on as a guide it decides which device on the LAN the

packet should be sent to.

Please see the related Port Forwarding User Guide for more general instructions on port forwarding.
