Interlogix TVE-DEC11 Bedienungsanleitung

TVE-DEC11 IP Video

Decoder User Manual

P/N 1072901B-EN • REV 1.0 • ISS 04MAR15

2015 United Technologies Corporation.

Interlogix is part of UTC Building & Industrial

Systems, a unit of

United Technologies Corporation.

Trademarks and

patents

rade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products

Manufacturer

nterlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance

Class B:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. T

his

equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

There is no guarantee that interference will not occur in a pa

rticular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the followin

g measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for

help.

European Union

directives

12004/108/EC (EMC directive):

Hereby, UTC Fire & Security

Americas Corporation, Inc

declares that this device is in compliance

or with the essential requirements and other relevant provisions of

Directive 2004/108/EC

2012/19/EU

(WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in

the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

Contact information

For

contact information, see www.utcfireandsecurity.com or

www.utcfssecurityproducts.eu.

TVE-DEC11 IP Video Decoder User Manual i

Content

Introduction 2

Package contents 2

Key features 2

Product description 3

Connections 4

Network Settings 6

TruVision Device Manager 6

Using a web browser 9

Before you start 9

Accessing the web browser 9

Decoder operation 10

Dynamic decoding 10

Sequence mode 11

Remote playback 12

Display settings 14

Enable/disable decoding channel 15

Picture overlay 15

Connection status 16

Check decoding channel status 16

Check display channel status 17

Transparent channel 17

Configuration 19

Device properties 19

Time settings 20

Network settings 21

Serial port settings 23

Alarm settings 25

Arming time 26

User account management 26

Import/Export Configure File 28

Device management 29

Specifications 30

2 TVE-DEC11 IP Video Decoder User Manual

Introduction

The TruVision TVE H.264 IP video decoder converts compressed IP video streams

to analog video output for display. Based on a powerful DSP and a stable

embedded system design, the TVE-DEC11 decoder provides a high resolution

decoding function for both live view and playback streams from Interlogix IP

cameras, digital video recorders and network video recorders.

This user manual provides basic information on setting up and using the TVE-

DEC11 model.

The decoder browser is shipped with on-screen display (OSD) menus in English and

Chinese.

Package contents

The TruVision TVE H.264 IP video decoder is shipped with the following items:

• TVE-DEC11 decoder

• Power adaptor

• Power cable

• Quick start guide

• CD (includes the user manual and TruVision Device Manager)

Key features

The following key features are supported by TVE decoders:

• Supports compression H.264 and MPEG4 codec

• Powerful decoding capability:

- 2-channel video stream at 5MP resolution, or

- 4-channel video stream at 1080P resolution, or

- 8-channel video stream at 720P resolution, or

- 16-channel video stream at WD1 resolution

• Multiple video display outputs: BNC, VGA and HDMI

• Compatible with Interlogix TruVision IP cameras and TruVision NVRs. Please

check the Interlogix web site for the latest compatible device list.

• Supports ONVIF, PSIA and CGI communication

• Discoverable via the TruVision Discovery Tool

TVE-DEC11 IP Video Decoder User Manual 3

Product description

Figure 1: Front panel

Name Description

Power The power LED

Link Network connection LED

Tx/Rx Data transmitting/receiving status LED

HDMI HDMI output

VGA VGA output

Audio out RCA Audio output

Video out BNC output

Figure 2: Rear panel

Name Description

Line out Audio output, 3.5mm connector.

Line in Audio input, 3.5mm connector.

Ethernet

Connect the 10M/100M/1000Mbps self-adaptive UTP Ethernet port to a

network.

RS-232

Connect to an RS-232 device, such as a computer.

RS-485

Connect to RS-485 serial port.

Alarm Input Connect up to four alarm relay inputs.

Alarm Output Connect up to four alarm relay outputs.

DC 12V Connect a 12 V power supply via a PSU.

. GND Connect to ground.

4 TVE-DEC11 IP Video Decoder User Manual

Connections

See Figure 2 on page 3 for information on connecting the power, camera, audio and

network cables.

Alarm connections

The TVE decoder supports the open/close relay input as the alarm input mode.

When the alarm input signal not in open/close relay signal mode, please follow the

connections shown below:

Figure 3: Alarm input connections

Alarm input connections for Emerson alarm:

Alarm input connections for normal alarm:

. Emerson alarm

. V output

. 10 V regulator

4. 4N35 optocoupler

5. Relay output

6. Normal alarm

7. JQC-3FG 24 V relay

The TVE decoder supports the open/close relay input as the alarm output mode.

The alarm input can be selected to NO or NC. Different alarm output connection

methods are applied to the AC or DC load. See Figure 3.

TVE-DEC11 IP Video Decoder User Manual 5

Figure 4: Alarm output connections

Note: Please note the different connections of JJ1 shown above. For a DC load,

JJ1can be safely used both in NC and NO methods. It is recommended to use 12 V

/ 1 A. For an external AC input, JJ1 must be open. The motherboard has two

jumpers, each corresponding to one alarm output. Both jumpers are factory set to be

connected.

6 TVE-DEC11 IP Video Decoder User Manual

Network Settings

This chapter explains how to use TruVision Device Manager to find and configure

the IP address and other parameters of the device.

Note: The default user name of TVE is admin, and password is 1234. The default IP

address is 192.168.1.70

TruVision Device Manager

The TruVision Device Manager tool can be found on the CD shipped with that

product.

This tool automatically identifies TruVision devices that support “auto-discovery” in

the same subnets. You can view and modify the IP address of any discovered

device.

To install the TruVision Device Manager:

1. Insert the CD in the computer’s CD/DVD drive.

2. Browse to the folder Tools and double-click the Setup file located in the folder.

3. Click Next.

4. Select the folder where the setup will install the files then click Next.

TVE-DEC11 IP Video Decoder User Manual 7

5. The program requires a utility called WinPcap to be installed on the computer. If

it is already installed, go to step 6.

If the program is not installed, the WinPcap window appears. Follow the on-

screen instructions.

6. The TruVision Device Manager Wizard appears. Click Finish to complete its

installation.

Using the TruVision Device Manager

The setup will install the necessary files and place the following shortcut on your

desktop.

Figure 5: TruVision Device Manager shortcut icon

To use the TruVision Device Manager:

1. Double-click the shortcut icon to open the tool.

The Start window appears.

2. The list of TruVision devices located on your network appears.

Note: The TruVision Device Manager can only detect devices that are on the

same LAN. The tool cannot detect devices placed on a VLAN.

8 TVE-DEC11 IP Video Decoder User Manual

The tool identifies:

• Device type

• Device MAC address

• IP address

• Number of video channels supported by the device

• Connection port

• Software version

• Device serial number

• DSP/firmware version

• Device subnet mask

• Device start time

3. To change the IP address and/or the subnet mask of the device, click the line of

the device address to be changed. The key device characteristics for that device

are listed in the right pane.

4. Change/modify the IP address and or subnet mask as required. Input the

device’s logon password and press Save.

5. Repeat this process for each device that needs to be modified. When all

changes to all discovered devices is complete, press Exit to close the tool.
