ZeroWire User Manual 11

Front of ZeroWire

Key Colour Description

ALARM

Red System is in alarm. Enter

your PIN code then

ENTER to turn off the

alarm. Press STATUS

key for more info.

STAY

Not lit System is disarmed if

Away is also not lit.

Yellow System is armed in the

“STAY” mode.

STATUS

Green System is ready to be

armed.

Yellow System message

present.

Red

(steady) System trouble message

present.

Touch the STATUS key to hear

system messages. If you are unable

to fix the issue, contact your service

provider for help.

AWAY

Not lit System is disarmed if

Stay is also not lit.

Red System is armed in the

“AWAY” mode.

READY

Not lit System cannot be

armed, press STATUS

key for more info

Green

(steady) Your system is ready to

arm in Away or Stay

mode.

Green

(flashing) Zones are currently

unsealed but system is

force-armable. If these

zones are not sealed by

the end of the exit time

the system will go into

alarm.

BYPASS

Touch the BYPASS key to access

the bypass menu where you can

bypass or un-bypass zones.

CHIME

Touch the CHIME key to access the

chime menu where you can select

zones to make a chime sound on

the ZeroWire when they are tripped.

HISTORY

Press the HISTORY key to listen for

alarm and event history.

Microphone Stay Arm Key Status Key Away Arm Key

Ready Light

Bypass Key

Chime Key

History Key

Siren

Enter KeyNumeric

Keys

Key

Speaker

Alarm Light

SOS

Emergency

Keys

12 ZeroWire User Manual

Basic Features

Arm your system in Away Mode

Protect your property using Away Mode when you are leaving the premises.

Normally zones must be secure before you can arm in Away Mode, this will be indicated

by the Ready Light being lit a solid green.

If the Ready Light is flashing green then “forced arming” is enabled. This means some

zones are not secure but you can still arm your security system. Read more about the

Forced Arming Feature on the next page.

If the Status Key is not green press the Status Key to hear what zones are not secured.

You may arm your system using your user PIN code:

READY STATUS

Check ready key is green.

Check status key is green.

AWAY

Select the Away Mode.

3. Leave the premises.

To silence the Exit Delay beeping, press the Away Key again and the beeping will stop.

This can also be performed from the UltraConnect app.

USER PIN CODE ENTER

EXIT DELAY BEEPS

All partitions

now protected

Druk

Away

Ready Light

is green

ZeroWire User Manual 13

If your service provider has enabled the quick arm feature, you can simply touch the Away

key:

READY STATUS

Check ready key is green.

Check status key is green.

AWAY

Select the Away Mode.

6. Leave the premises.

Forced Arming Feature

Normally all zones must be secure before you can arm your security system.

For example, a home with a door detector on the front door. When forced arming is NOT

enabled, you would have to close the door to secure the sensor before being allowed to

arm the system. When force arming is enabled, you can arm your system with the door

opened, and the door will automatically be protected after it is fully closed as you leave.

If your service provider has enabled the “forced arming” feature, you will be able to arm

your security system even if pre-selected zones are not secure. The Ready Light will flash

green to indicate this feature is available. Press Status key to hear which zones are not

secure.

Check with your installer to confirm how Forced Arming has been set up for your

system:

Option 1: At the end of the exit delay, zones that are not secured will automatically be

bypassed. If they later become secured, the bypass will be automatically removed and

they will become part of the active security system until the system is disarmed.

Option 2: At the end of the exit delay:

• delay sensor types that are not secured will start an entry delay and go into alarm if a

valid PIN code is not entered,

• instant sensor types that are not secured will go into alarm immediately.

Explanation of Stay Modes

Use one of the Stay Modes when you are staying inside the premises and you want the

perimeter protected. You will be able to move around inside the protected area without

setting the alarm off. This gives you peace of mind even when you are at home.

For example, Stay Mode is often used at night. Internal motion sensors will be ignored.

Perimeter detectors will be armed and active to detect intruders. The security of your home

in Stay mode is dependent on the type and number of detectors you have installed and are

active in Stay mode.

There are three similar modes available - Stay Mode, Stay Instant Mode, and Night Mode.

EXIT DELAY BEEPS

14 ZeroWire User Manual

In Stay Mode – Entry/Exit zones will be active, and zones with the Stay or Night Mode

property will be bypassed. Entry via a zone with the Entry/Exit property will start the

partition entry timer as normal.

This will allow you to move around inside your home without causing the system to sound

an alarm. A person entering the house will have the ability and time to disarm the system

as usual.

In Instant Stay Mode – Entry/Exit zones will be active with entry delay time removed, and

zones with the Stay or Night Mode property will be bypassed. Entry via a zone with the

Entry/Exit property will trigger an instant alarm.

This is a higher level of security and requires you to disarm the system (from inside or

remotely) before entering the protected area. No person will be able to enter the house

without triggering an alarm.

In Night Mode – Entry/Exit zones will be active with entry delay time removed, zones with

the Stay property will be bypassed, zones with the Night Mode property will be active.

Entry via a zone with the Entry/Exit property will trigger an instant alarm.

This is a higher level of security and requires you to disarm the system (from inside or

remotely) before entering the protected area. No person will be able to enter the house

without triggering an alarm.

Example

For example, in a two-level home, the upstairs motion sensors are programmed as Stay

and the downstairs motion sensors are programmed as Night Mode. The first press of the

Stay button arms the system in Stay Mode, allowing free access in the downstairs and

upstairs levels and will start the entry delay if someone enters through an Entry/Exit zone

such as the front door.

The second press of the Stay button arms the system in Instant Stay Mode, allowing free

access in the downstairs and upstairs level and will trigger an instant alarm (no entry

delay) if someone enters through an Entry Exit zone such as the front door. This prevents

even authorized users from entering the area unless it is disarmed first (for example, by

someone inside the area).

The third press of the Stay button arms the system in Night Mode, allowing free access in

the upstairs level and will trigger an instant alarm (no entry delay) if someone enters the

protected Night Mode area downstairs. This prevents even authorized users from entering

the area unless it is disarmed first (for example by someone inside the Stay area).

Arm your system in Stay Mode

Use Stay Mode when you are staying in the premises and you want the perimeter

protected whilst allowing you to move around inside without setting the alarm off.

Normally all Stay Mode zones must be secure before you can arm in Stay Mode.

If the Ready Light is flashing green then “forced arming” is enabled. This means some

zones are not secure but you can still arm your security system. Read more about the

Forced Arming Feature on the previous page.

ZeroWire User Manual 15



You may arm your system by entering your user PIN code:

STATUS

Check status key is green. Close all

protected doors and windows. If you

have motion detectors outside your “stay

mode”, have everyone leave those

areas.

STAY

Select the Stay Mode.

Stay within the protected areas.

Or, if your service provider has enabled the quick arm feature, you can simply touch the

Stay key:

STATUS

Check status key is green. Close all

protected doors and windows. If you

have motion detectors outside your

“stay mode”, have everyone leave

those areas.

STAY

Select the Stay Mode.

Stay within the protected Stay or Night

Mode areas.

If an armed zone is alarmed whilst your security system is in the Stay mode, it will sound a

warning tone on your ZeroWire and start a timer. At the end of the Stay Mode Entry Time

your sirens will sound. Your service provider predetermines this warning time at the time of

installation.

Downstairs only

protected

Touch Stay

Ready Light

is green

16 ZeroWire User Manual

To start the Stay Instant Mode touch the Stay key twice:

STATUS

Check status key is green. Close all

protected doors and windows. If you

have motion detectors outside your

“stay mode”, have everyone leave

those areas.

STAY

Select the Stay Mode twice.

Or press Stay button once when

system is already in Stay Mode. In this

case, you will not be asked second time

for a PIN code.

STAY

(flashing yellow)

Stay button will flash on and off.

Stay within areas protected with Stay

Mode or Night Mode zones.

If an armed zone is alarmed whilst your security system is in the Stay mode there will be

no warning timer and your sirens will sound immediately.

To start the Night Mode touch the Stay key three times:

STATUS

Check status key is green. Close all

protected doors and windows. If you

have motion detectors outside your

“stay mode”, have everyone leave

those areas.

STAY

Select the Stay Mode three times.

Or when system is already in Instant

Stay Mode, press Stay once. In this

case you will not be asked second time

for a PIN code.

STAY

(flashing red)

Stay button will flash on and off.

Stay within areas protected with Stay

Mode zones. Do not move into areas

protected with Night Mode zones.

If an armed zone is alarmed whilst your security system is in the Stay mode there will be

no warning timer and your sirens will sound immediately.

To set normal Stay Mode, touch the Stay key one more time:

STAY

Select the Stay Mode when the system

is in Night Mode.

STAY

Stay button will return to a solid yellow.

Stay within the protected areas.

ZeroWire User Manual 17

Note: Subsequent presses of the Stay button loop through the three Stay Mode states:

Stay Mode Stay Instant Mode Night Mode

Sensors which are automatically bypassed for Stay Mode are logged in the event history

(but not reported) as bypassed.

Events Preventing Arming

The following system alarms will prevent a system in EMEA from arming. You must clear

all of these. Contact your service provider for assistance.

Wireless supervision faults

Wireless Low Battery

Tamper

Trouble

Ethernet or WiFi fault

Phone Line Fault

Wireless Jamming

Over-current fault

Power fail

Low Battery

Expander fail

Status Key in EN Grade 2

For EN Grade 2 compliant systems, the Status Key behaviour has been modified for

greater security. It will be off or red, and not announce system status when pressed.

To check system status on EN Grade 2 systems:

18 ZeroWire User Manual

Enter a valid user PIN

STATUS

Select Status Key

Status condition(s) are

announced

Acknowledging Latched System Alarms

When the Status Key is red, there may be latched system alarms present. A master user

(Level 2) is required to acknowledge and clear these. Standard users cannot acknowledge

and clear these.

To acknowledge Latched System Alarms:

STATUS

Select Status Key

Status condition(s) are

announced

Enter a valid master PIN

STATUS

Status Key will change to green if

no other conditions are present

Exit Error / Fail To Close

If during exit delay a zone is tripped which causes an alarm, then the areas affected will

not be armed. Exit Error and Fail To Close are logged in the event history.

Check the zone is secure and try to arm the area(s) again.

Disarming

Make your way to the ZeroWire through one of the designated entry / exit doors.

Once a detector detects your presence, the entry delay will begin counting down and your

ZeroWire will repeat a warning message until a valid PIN code is entered. If a valid PIN

code is not entered by the end of the entry delay time, your sirens and communicator will

activate.

If you require more time to disarm your system, the entry time can be modified in Menu 8

by a master user. Away and Stay modes can be configured with different entry delay

times, ask your service provider for further details.

USER PIN CODE ENTER

STATUS ANNOUNCED

MASTER PIN ENTER

ZeroWire User Manual 19

Depending on how your system has been set up, entry through a non-designated door

may cause the alarm to sound immediately for greater security.



1. Enter the premises through a

designated entry/exit door

Approach the ZeroWire. When you are

detected, the entry warning timer will begin

and the ZeroWire will beep.

Enter your PIN code before the entry delay

expires.

All zones are now disarmed, any bypassed

zones are restored to normal operation.

Lock Out On 3 Invalid Attempts

If an invalid PIN code is entered three times, the ZeroWire will deny all login attempts for

90 seconds. Attempts are counted from any method (e.g. keypad, app, or web server).

You must wait the full 90 seconds before trying again with the correct PIN. This is to

prevent brute-force attacks on guessing PIN codes.

Bypass a Zone

The zone bypass menu is used to bypass (isolate) selected zones in your security system.

A bypassed zone is ignored by the system and is not capable of activating an alarm. This

option is commonly used to temporarily ignore zones that require service, or zones that

you wish to temporarily add to your “stay mode”.

Whilst still offering security with the remaining zones, bypassing zones lowers your level of

security.

All bypassed zones are reset and cleared from memory when your security system is next

armed / disarmed.

ENTRY DELAY BEEPS

USER PIN CODE ENTER

All partitions

now disarmed

Enter

One or more partitions

armed

Andere Handbücher für ZeroWire

Inhaltsverzeichnis

Andere Interlogix Sicherheitssystem Handbücher

Interlogix

Interlogix Advent Bedienungsanleitung

Interlogix

Interlogix ZeroWire Bedienungsanleitung

Interlogix

Interlogix ITI Simon Bedienungsanleitung

Interlogix

Interlogix ACL805SUW-BS Bedienungsanleitung

Interlogix

Interlogix UltraView UVC-6120-1 Bedienungsanleitung

Interlogix

Interlogix RF-7220-07-1 Montageanleitung

Interlogix

Interlogix 600-6520-95 Bedienungsanleitung

Interlogix

Interlogix advisorone Bedienungsanleitung

Interlogix

Interlogix Simon XT Bedienungsanleitung

Interlogix

Interlogix Simon XTi-5 Version 2 Bedienungsanleitung

Interlogix

Interlogix AL602ITI Bedienungsanleitung

Interlogix

Interlogix Caddx Bedienungsanleitung

Interlogix

Interlogix Simon XT Bedienungsanleitung

Interlogix

Interlogix NX-595E Bedienungsanleitung

Interlogix

Interlogix AS502 Montageanleitung

Interlogix

Interlogix xgen Betriebsanleitung

Interlogix

Interlogix ACL800SUW-BSMF Bedienungsanleitung

Interlogix

Interlogix ATS111 A Series Montageanleitung

Interlogix

Interlogix ZeroWire Bedienungsanleitung

Interlogix

Interlogix DC107 Series Montageanleitung

Interlogix

Interlogix Simon XT Bedienungsanleitung

Interlogix

Interlogix ATS111xA-N Series Montageanleitung

Interlogix

Interlogix Simon XTi-5 Version 2 Bedienungsanleitung

Interlogix

Interlogix NX-595E Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
