PB42 Printer

Quick Start Guide

Intermec Technologies Corporation

Corporate Headquarters

6001 36th Ave. W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is proprietary and is provided

solely for the purpose of allowing customers to operate and

service Intermec-manufactured equipment and is not to be

released, reproduced, or used for any other purpose without

written permission of Intermec.

Information and specifications contained in this document are

subject to change without prior notice and do not represent a

commitment on the part of Intermec Technologies Corporation.

reserved.

The word Intermec, the Intermec logo, Norand, ArciTech,

CrossBar, Data Collection Browser, dcBrowser, Duratherm,

EasyCoder, EasyLAN, Enterprise Wireless LAN, EZBuilder,

Fingerprint, i-gistics, INCA (under license), InterDriver,

Intermec Printer Network Manager, IRL, JANUS, LabelShop,

Mobile Framework, MobileLAN, Nor*Ware, Pen*Key,

Precision Print, PrintSet, RoutePower, TE 2000, Trakker

Antares, UAP, Universal Access Point, and Virtual Wedge are

either trademarks or registered trademarks of Intermec

Technologies Corporation.

Throughout this manual, trademarked names may be used.

Rather than put a trademark (™or ®) symbol in every

occurrence of a trademarked name, we state that we are using

the names only in an editorial fashion, and to the benefit of the

trademark owner, with no intention of infringement.

There are U.S. and foreign patents pending.

PB42 Printer Quick Start Guide 1

What is the PB42 Printer?

The PB42 printer is a rugged receipt printer designed for use

with the CK60 computer. The PB42 provides:

• Print resolution of 203 dpi

• Print speeds up to 8.5 cm (3.3 inches) per second

• Serial or Bluetooth™ communication options

Installing and Charging the Batteries

The PB42 ships with two batteries. You need to fully charge the

batteries before you can use the printer. You can charge the

batteries inside the PB42 printer or in the CK60 battery charger.

To charge the batteries in the PB42 printer, you need an AC

power adapter (P/N 851-076-001) and a power cord.

Use Intermec battery pack P/N 318-015-001 only.

Use of another pack may present a risk of fire or

explosion.

Employez le bloc-batterie d’Intermec P/N 318-

015-001 seulement. L’utilisation de tout autre

bloc-batterie présente un risque d’incendie ou

d’explosion.

The battery pack used in this device may present a

fire or chemical burn hazard if mistreated. Do not

recharge, disassemble, heat above 100 C (212 F) or

incinerate.

Le bloc-batterie utilisé dans cet appareil peut

présenter un risque d’incendie ou de brûlure

chimique en cas de mauvais traitement. Ne

rechargez pas, ne désassemblez pas, ne chauffez pas

à une température supérieure à 100 C (212 F) et

n’incinérez pas ce bloc-batterie.

Dispose of used battery pack promptly. Keep away from

children.

It takes about 4 hours to charge the batteries inside the PB42.

2 PB42 Printer Quick Start Guide

To install the batteries

1 Pull the battery cover latch towards the front of the printer

and lift up on the battery cover.

2 Insert batteries into the two battery slots until they lock in

place. The contact side of the battery faces the media cover.

Battery cover

Batteries

Media cover

Battery cover

latch

Battery cover

PB42 Printer Quick Start Guide 3

3 Close the battery cover.

4 Connect the AC power adapter to the DC power connector

on the printer.

5 Connect one end of the power cord to the AC power adapter

and then plug other end into an AC outlet.

Loading Media

You can use roll or fanfold receipt media with the PB42 printer.

The PB42 ships with a sample roll of media that you can use the

first time you unpack the shipping box and verify that the

printer is working correctly.

The media you use in the PB42 must meet these specifications.

Specification Dimensions

Receipt roll core (ID) 1.9 cm (.75 inch)

Receipt roll maximum diameter 6.7 cm (2.65 inches)

Media maximum width 11.2 cm (4.40 inches)

To load media

1 Slide the media cover release button to the unlocked (left)

position.

2 Press the media cover release button to open the media cover.

DC power

connector

4 PB42 Printer Quick Start Guide

3 Insert the media between the two media supports. Make sure

you load the media clockwise so that it pulls off the core from

the bottom of the printer.

4 Pull out a few inches of the media.

Media cover

release

Media cover

Media

sup

ports

PB42 Printer Quick Start Guide 5

5 Close the media cover until it latches.

6 Slide the media cover release button to the locked (right)

position.

Understanding the Control Panel

The PB42 control panel contains two buttons and three lights.

Button or LED Function

Radio button Turns the radio on and off.

Blinks fast green when the radio is receiving

data.

Blinks slow green when the radio is on.

Battery lights Indicates whether the battery is charging

(red), low (red blinking), or fully charged

(green).

Ready-to-Work™

indicator

Indicates a connection to the host if on

solid blue. If the blue light blinks, the

printer is open or there is a hardware error.

Feed button Press to advance media. Press and hold to

advance media at 2 inches per second (ips).

Feed button

Radio button

Battery lights

Ready-to-Work

indicator

6 PB42 Printer Quick Start Guide

Performing a Test Print

After you have loaded the media in the printer, you are ready to

print the configuration test information. Use this information

for reference when installing your PB42 printer and for verifying

proper printer operation.

To perform a test print

• Press and hold the Feed and Radio buttons for 5 seconds.

Loading New Firmware

You can upload firmware on your PB42 from the CK60

handheld computer. To upgrade your firmware, you need to

send a .upg file to the PB42 printer:

• PB42xxxxx.upg

Where xxxxx is the version number of the firmware.

To load new firmware

1 On the CK60, go to My Device > Program Files > Intermec

and start FWUpgrade.

2 Select the Settings tab.

3 Select COM6 for the COM port and select the “Use Remote

DCB” check box.

4 Select the Printer Flash Update tab.

5 Click Choose Update. A browser window opens.

6 Browse to your .upg file, select it, and click OK. The browser

windor closes and you return to the Printer Flash Update

tab.

7 Select Send Update.

8 Wait for the Upgrade Done message on the CK60. The

PB42 beeps twice when it is done receiving information.

PB42 Printer Quick Start Guide 7

Specifications

Physical Dimensions

Depth: 7.87 cm (3.1 inches)

Height: 18.03 cm (7.1 inches)

Width: 16.82 cm (6.62 inches)

Weight: less than 1.23 kg (2.7 lb) with battery packs and

receipt paper.

Power Specifications

AC power adapter: 50 Watt

Voltage range: 12V ± 5%

Operating: Rechargeable 7.2V 2.4 Ah lithium-ion

batteries

Temperature and Humidity Specifications

Operating temperature: -20°C (-4°F) to 50°C (122°F)

Non-operating temperature: -30°C (-22°F) to 70°C (158°F)

Relative humidity: 10% to 90% non-condensing

Bar Code Symbologies

Interleaved 2 of 5, Codabar, EAN-128, PDF417, UPC-A,

Code 128, EAN-13, EAN-8, Code 39, New GTIN

6001 36th Avenue West

Everett, WA 98203

U.S.A.

www.intermec.com

PB42 Printer Quick Start Guide

*074572-001*

074572-001
