ICS2300/ICS2330
PT Type H.264
Wired/Wireless
IP Camera
Advanced Installation Guide
Version 1.0
- 1 -
PREFACE
Thank you for purchasing IC2300/ICS2330, a standalone system
that can be connected directly to an Ethernet or Fast Ethernet
network.
Equipped with a megapixel CMOS sensor, the camera allows you
to capture a wider field of view with a resolution of up to 1280 x
1024. With support for latest H.264 technology, you can record
streaming video that utilizes high quality H.264 images to your hard
drive, enable motion detection and setup automated e-mail alerts
for security.
With the Infrared LEDs and light sensor on the camera, you can
capture clear images even in the dark environment. The camera’s
pan/tilt functions allow you to control the camera to monitor
everywhere remotely. In addition, the camera can attach a variety
of external devices for your specific purposes through the GPIO
connectors.
Compared to the conventional PC Camera, this camera features a
built-in CPU and web-based solutions that can provide a cost-
effective solution to transmit the real-time high-quality video
images and sounds synchronously for monitoring. The camera can
be managed remotely, so that you can use a web browser to
access and control it from any desktop/notebook computer over
the Intranet or Internet.
The simple installation procedures and web-based interface allow
you to integrate it into your network easily. With comprehensive
applications supported, the Internet camera is your best solution
for remote monitor, high quality, and high performance video
images.
- 2 -
This Advanced Installation Guide provides you with the instructions
and illustrations on how to use your camera, which includes:
Chapter 1 Introduction to Your Camera describes the features
of the camera. You will also know the components and
functions of the camera.
Chapter 2 Hardware Installation helps you install the camera
according to your application environment. You can
use this camera at home, at work, at any where you
want.
Chapter 3 Accessing the Camera lets you start using your
camera without problem. The camera can be set up
easily and work within your network environment
instantly.
Chapter 4 Configuring the Camera guides you through the
configuration of the camera using the Web browser on
your PC.
Chapter 5 Appendix provides the specification of the camera
and some useful information for using your camera.
NOTE The illustrations and configuration values in this guide are for
reference only. The actual settings depend on your practical
application of the camera.
- 3 -
Contents
Preface ....................................................................................................1
Chapter 1 Introduction To Your Camera..................................................4
1.1 Checking the Package Contents ...............................................4
1.2 Getting to Know Your Camera...................................................5
1.3 Features and Benefits................................................................8
1.4 System Requirement...............................................................11
Chapter 2 Hardware Installation.............................................................12
2.1 Installing the Wall Mount Kit ....................................................12
2.2 Connecting the Camera to LAN/WLAN....................................13
2.3 Applications of the Camera......................................................15
Chapter 3 Accessing The Camera.........................................................16
3.1 Using IPFinder.........................................................................16
3.2 Accessing to the Camera.........................................................17
3.3 Configuring the IP Address of the PC......................................21
Chapter 4 Configuring The Camera.......................................................22
4.1 Using the Web Configuration...................................................22
4.2 Quick Setup.............................................................................23
4.3 Basic Setup .............................................................................28
4.4 Network Settings .....................................................................31
4.5 Pan & Tilt Settings...................................................................39
4.6 Setting up Video & Audio.........................................................40
4.7 Event Server Configuration......................................................45
4.8 Motion Detect ..........................................................................50
4.9 Event Configuration.................................................................51
4.10 Tools........................................................................................55
4.11 USB.........................................................................................57
4.12 Information...............................................................................59
Appendix................................................................................................60
A.1 Specification............................................................................60
A.2 Terminal Application................................................................63
A.3 Glossary of Terms ...................................................................64
- 4 -
CHAPTER 1
INTRODUCTION TO YOUR CAMERA
1.1 Checking the Package Contents
Check the items contained in the package carefully. You should
have the following:
One ICS2300/ICS2330
One AC Power Adapter
One Wall Mount Kit
One External Antenna (for wireless model)
One Ethernet Cable (RJ-45 type)
One GPIO Connector
One Installation CD-ROM
One Quick Installation Guide
NOTE Once any item contained is damaged or missing, contact the
authorized dealer of your locale.
- 5 -
1.2 Getting to Know Your Camera
Front / Right Panel
a. Infrared LEDs (x7) allow your camera to capture clear image
in a dark environment.
b. Light Sensor is used to trigger on and off the Infrared LEDs
according the environmental light level.
c. Lens Assembly
d. USB Port allows you to connect an external USB device. It
provides the power distribution up to 500mA.
b
c
a
d
e
f
g
h
- 6 -
e. Internal Microphone allows the camera to receive sound and
voice.
f. Link LED indicates the camera’s network connectivity with the
flashing green light.
g. Power LED indicates the camera is powered on with the
steady amber light.
h. External Antenna
Rea Panel
o
i
j
klmn
p
- 7 -
i. USB Unmount Button is used to remove the connected USB
device safely.
NOTE After long pressing the Unmount button for four seconds, the
Power LED starts flashing. When the Power LED resumes the
steady amber light, you can remove the USB device safely.
j. DC Power Connector connects the AC power adapter, in
order to supply power to the camera.
k. WPS Button (for wireless model) is used to protect your
WLAN. Instead of entering the network name (SSID), your
wireless network can be protected simply by pushing a button.
TIP For more information of using the WPS button, refer to the
instruction of the Web Configuration, Network >> Wireless >>
WPS Setting.
l. GPIO Connectors is used to connect the external devices.
m. Reset Button will restart the camera when it is pressed quickly;
when it is pressed and held for five seconds, the camera will
resume the factory default settings.
n. Wireless Antenna Connector (for wireless model) is used to
attach the external antenna.
o. Ethernet Cable Connector connects the network cable, which
supports the NWay protocol so that the camera can detect the
network speed automatically.
p. Audio-out Connector connects an external active speaker.
- 8 -
1.3 Features and Benefits
H.264/MPEG4/MJPEG Multi-codec Supported
The camera provides you with excellent images by the
H.264/MPEG4/ MJPEG multi-codec selectable technology,
allowing you to adjust image size and quality, and bit rate
according to the networking environment.
High Resolution Surveillance
Equipped with a megapixel CMOS sensor, the high
performance camera is designed for your professional
surveillance and security applications. The image resolution
is up to 1280 x 1024.
Day & Night Surveillance Supported
The seven Infrared LEDs around the standard lens assembly
enable the camera to capture crystal clear images in the dark
environment or at night. When the Light Sensor detects the
environmental light level becomes low, the camera captures the
images in black & white mode using these infrared LEDs.
Optimal Viewing
With the pan/tile functions, you can easily monitor everywhere
via the camera by moving the camera lens to the left/right
(165/165 degrees) or up/down (90/15 degrees). In addition, you
can assign up to eight positions for the camera, enabling you to
move the camera lens to the desired position quickly.
Remote Control Supported
By using a standard Web browser or the bundled UltraView
Pro software application, the administrator can easily change
the configuration of the camera via Intranet or Internet. In
addition, the camera can be upgraded remotely when a new
firmware is available. The users are also allowed to monitor
the image and take snapshots via the network.
- 9 -
Multiple Profiles Supported
The camera supports multiple profiles simultaneously, so
that you can separately set up different image settings (such
as image quality and frame rate) for the three video types of
the camera: H.264, MPEG4, MJPEG, and 3GPP.
Flexible Audio Capability
The camera allows you to connect the external microphone
to receive on-the-spot audio via the Internet, allowing you to
monitor the on-site voice. In addition, you can connect an
external active speaker to the camera to speak through the
camera (supporting mono audio only).
Supports RTSP
The camera supports RTSP (Real Time Streaming Protocol),
which is a technology that allows you to view streaming
media via the network. You can view the real-time video with
the Quick Time player or RealPlayer. To view the real-time
streaming image on your computer, open the Web browser
and enter the RTSP link:
MPEG4 stream: rtsp://(IP address of the camera)/mpeg4
H.264 stream: rtsp://(IP address of the camera)/h264
Mobile Device Viewing Supported
The camera supports real time video viewing on your mobile
device. After installing the required software applications,
you can easily motor the camera’s real-time video from your
iPhone, iPod Touch, or iPad (requires iPhone OS 3.1 or
later). The latest Android phone can be supported too.
For iPhone application software, please search "iPuxCam" in
the app store on iPhone to download and install.
For Android application software, please visit the website:
http://www.ipux.net to download and install.
