INSTRUCTION MANUAL

ICM36R CLAMP MULTIMETER

ICM 36R

EN FR IT DE

1

ISO-TECH ICM36R

CLAMP MULTIMETER

INSTRUCTION MANUAL

2

3

INTRODUCTION

1-1 Unpacking and Inspection

Upon removing your new Current Meter from its packing, you should have the following items:

1. Current meter.

2. Carrying case.

3. Instruction Manual.

1-2 Meter Safety

Terms as Marked on Equipment

Attention — Refer to Manual.

Double Insulation — Protection Class II

DANGER — Risk if electric shock.

Symbols in Manual

This symbol indicates where cautionary or other information is found in the manual.

Battery

4

1-3 Front Panel

Refer to Figure 1 and the following numbered steps to familiarize yourself with the meter's front panel controls.

1. Digital Display — The digital display has a 3 1/2 digit LCD readout (maximum reading 1999) plus auto polarity,

decimal point, <, DC,AC, and =.

2. Drop-Proof Wrist Strap — Prevents the instrument from slipping off the hand while in use.

3. Function Switch — Slide switch is used to select the desired range.

4. DC Zero Adj. Knob — Zero adjusts on DC current ranges.

5. AC/DC Slide Switch — Selects a.c. or d.c. current measurement.

6. Data Hold Switch — Holds display reading for all functions and ranges.

7. Trigger — Press the lever to open the current transformer jaws. When the pressure on the lever is released, the

jaws will close again.

8. Current transformer Jaws — Designed to pick up the current flowing through the conductor.

5

Figure 1

6

SPECIFICATIONS

2-1 General Specifications

Display : 3 1/2 Digital Liquid Crystal Display (LCD) with a maximum reading of 1999.

Polarity : Automatic polarity indicated.

Overrange Indication : "1" or "-1" indicated.

Measuring Rate : 2 times per second, nominal.

Position Error : ± 1% of reading.

Type of Sensing : Hall effect sensing for AC and DC.

Low Battery Indication : "<" is displayed when the battery voltage drops below the operating voltage.

7

2-2 Environmental Conditions

Indoor use only.

Maximum Altitude : 2000 meters.

Installation Category : IEC 1010 Cat. II 600V, Cat. III 300V.

Pollution Degree : 2

Operating Ambient : 0°C ~ 50°C, < 75% R.H.

Storage Temperature : -20°C ~ 60°C, < 80% R.H.

Temperature Coefficient : 0.2 x (Specified accuracy) / °C, < 18°C or > 28°C.

Power Requirement : Alkaline 9V battery.

Battery Life : 40 hours typical (Alkaline).

Max/Conductor Size : 34mm diameter or 20 x 40mm busbar.

Size : 600mm (W) x 203mm (L) x 29mm (H).

Weight : 310 grams.

Supplied Accessories : Battery (installed), manual and carrying case.

8

2-3 Electrical Specifications

Accuracy is ± (% reading + number of digits) at 23°C ± 5°C, less than 75% R.H.

(1) DC A

Range Resolution Accuracy

200A 0.1A ±(1.9%reading + 5digits) for 0 ~ 20A

±(1.9%reading + 3digits) for 20A ~ 200A

600A 1A ±(1.9%reading + 3digits) for 200A ~ 600A

9

(2) AC A

Range Resolution Accuracy

200A 0.1A ±(1.9%reading + 7digits) for 0 ~ 20A

±(1.9%reading + 5digits) for 20A ~ 200A

600A 1A ±(1.9%reading + 5digits) for 200A ~ 600A

Frequency Response: 40Hz ~ 400Hz.

Data Hold: Hold display reading for all functions and ranges.

(3) Auto Power Off

The meter will automatically shut itself off approximately 30 minutes after power on.
