JBL Control Control One Pro Bedienungsanleitung

Control 1 Pro

Product User’s Guide

Two-Way, Professional Compact Loudspeaker

Key Features

• 150 Watts Continuous Power

Handling

• Professional Drivers and

Crossover Network

• Included Mounting Bracket

• Transparent and Faithful

Sonic Performance

• Magnetically Shielded Enclosure

• SonicGuard™ Overload

Protection

Your Control 1 Pro is a compact, high-

performance professional loudspeaker

system that features monitor-grade low

and high frequency drivers coupled with

a professional crossover network. The

rugged and durable molded enclosure is

magnetically shielded making the Control 1

Pro ideal for use with video and computer

monitors or other magnetically sensitive

equipment. Moreover, the Control 1 Pro’s

compact design is ideal for audio-visual

applications, computer workstations,

recording and broadcast studios, mobile

audio-video control rooms and foreground

and background music.

A) Screw the metal rod/ball assembly (1) into the threaded insert (2) on the back of

the cabinet (8) until it is seated against the bottom of the insert.

B) Next, tighten the “knurled” nut (3) with a small wrench until it is seated against the

back of the cabinet. Tighten the nut until it has “locked” the rod/ball assembly (1)

to the cabinet. Note: the nut may leave marks on the back of the cabinet where

the attachment is made however, the ﬂange of the nut will cover these marks.

Control 1 Pro

Bracket Assembly and Mounting Guide

Control 1 Pro User’s Guide

If there is no sound from your speakers:

• Make sure your power ampliﬁer is on and the gain is set above its minimum setting.

• Make sure there is a signal to your ampliﬁer from your mixer.

• Ensure all wires are connected and that none are cut or frayed.

• If more than one pair of speakers is being used, check the minimum impedance

requirments of your ampliﬁer (overloading your ampliﬁer can result in damage to

your amp).

If there is no sound from one of your speakers:

• Check the balance control on your mixer.

• Check the channel output gains of your ampliﬁer.

• Ensure all wires are connected and that none are cut or frayed.

If there is no (or weak) bass output or a poor stereo image:

• Make sure the polarities (+ and -) of the speakers inputs are properly connected.

C) Mount the wall bracket plate (4) onto a ﬂat sturdy surface using the

appropriate mounting hardware for the surface. A safety cable (5) (not

included) may be attached to the wall bracket via its eyelet (6) at one of the

two lower screw mounting points or to a secondary point off the mounting plate.

D) Next, slip the large molded nut (7) over the ball on the metal rod/ball assembly (1).

E) Holding the cabinet (8) with both hands, insert the ball on the metal rod/ball

assembly (1) into the cup of the wall plate (4).

F) Orient the speaker into the desired position and hand tighten the molded nut

(7). Once the orientation is ﬁnalized, use the metal bar (9) in one of the holes

on the molded nut (7) to securely tighten.

G) Finally, clip the safety cable to the cabinet’s safety bar (10) on the back of the

cabinet.

The Control 1 Pro’s logo can be oriented for display at 90° increments. To rotate the

logo, ﬁrst gently pry the grille and gasket from the cabinet. Next, push-in the logo’s

fastener (found on the underside of the grille) and rotate the logo to the desired

position.

Rotating the Logo

Troubleshooting

JBL Professional 3

System:

Frequency Range (-10 dB): 80Hz - 20kHz

Frequency Response (+/- 3 dB): 100Hz - 18kHz

Power Capacity1: 150 W

Sensitivity2: 87dB SPL, 1 W 1m (3.3 ft)

Maximum SPL3: 108dB continuous, 114dB peak

Directivity Factor (Q)2: 6.0

Directivity Index (DI): 7.8dB

Nominal Impedance: 4 ohms

Crossover Frequency: 4.2kHz

Overload Protection: Full-range SonicGuard™ power limiting to

protect network and transducers

Transducers:

LF Driver: 135mm (5.25 in) low frequency loudspeaker

HF Driver: 19mm (.75 in) polycarbonate dome tweeter

Enclosure:

Enclosure Material: Polypropylene Structural Foam

Finish: Black or White

Dimensions: 235mm x 159mm x 143mm

(9.25 in x 6.25 in x 5.6 in)

Net Weight (each): 1.8 kg (4 lbs)

Shipping Weight (pair): 4.6 kg (10 lbs)

Included Accessories: Mounting Bracket Assembly

1 IEC Standard, full bandwidth pink noise with 6 dB crest factor; 2 hour duration

2Average 1 kHz to 10 kHz

3Calculated based on power rating exclusive of power compression

JBL continually engages in research related to product improvement. Changes introduced into existing

products without notice are an expression of that philosophy.

8500 Balboa Boulevard

Northridge, CA 91329 USA

Visit us online at www.jblpro.com

P/N 363221-001

0706 REV B

Speciﬁcations

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere JBL Sprecher Handbücher

JBL

JBL Movie100 Bedienungsanleitung

JBL

JBL LSR4326P Bedienungsanleitung
