ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 1/31
Repair instructions
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 2/31
1. Models described
2. Technical data
3. Notes / requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram
Contents
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
These instructions describe how to repair the following models:
3/31
Model Order no.
ASM 14-4 7 112 27 00 95 0
ASM 14-6 7 112 28 00 95 0
ASM 14-9 7 112 31 00 95 0
ASM 14-12 7 112 57 00 95 0
ASM 14-6-PC 7 112 54 00 95 0
ASM 14-9-PC 7 112 55 00 95 0
ASM 14-12-PC 7 112 56 00 95 0
1. Models described
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 4/31
2. Technical data
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 5/31
3. Notes / requirements
Note
These instructions are only intended for persons with suitable technical training. It is assumed
that the reader has mechanical and electrical training.
Only use original FEIN spare parts!
Requirements
Please note that power tools may only be repaired, maintained and checked by a trained
electrician, as improper repair can result in serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers’ liability insurance associations are
to be observed when commissioning.
The German Equipment and Product SafetyAct applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 6/31
Standard tools Special tool
- Vice
- Torx 10 screwdriver
- Slotted screwdriver: 0.6x3.5
- Slotted screwdriver: 7.0x100
- Circlip pliers: opener / straight, 18-60 mm
- Circlip pliers: opener / stepped, 3-10 mm
- Socket head wrench: WAF 2.5 mm
- Snap ring pliers
- Bar magnet
- Forceps
- Feeler gauge
- Side-cutting pliers
- Soldering station
- Torque wrench 3 21 23 002 00 6
NOTE
You can only order special tools with an order number from FEIN.
4. Tools required
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 7/31
Lubricants
Grease 3 21 600 1423 0 0.6 g Fill taper of tool holder with grease
Apply grease to ball seats
Apply approx. 1 g to needle bearing bush
Auxiliary substances
Loctite 270 0 90 006 0010 9 50 ml Secure screws
5. Lubricants and auxiliary substances required
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 8/31
6. Disassembly
Removing the motor housing
1. Remove the coded sleeve (1).
2. Unscrew the nine screws (2) from the motor housing.
3. Spread open the motor housing (3) and remove the housing cover.
4. Remove the pressure piece (4).
Tools:
- Slotted screwdriver 0.6x3.5
- Circlip pliers
- Torx 10 screwdriver
1
3
2
4
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 9/31
6. Disassembly
Removing the motor housing
1. Remove the slide switch with pressure spring (1) and the pushbutton with pressure spring (2).
2. Carefully pull out the foil conductor (3) and carefully remove from the motor housing.
1
2
3
ASM 14-4, 14-6, 14-9, 14-12, 14-6-PC, 14-9-PC, 14-12-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 10/31
6. Disassembly
Removing the motor housing
1. At the same time, lift the gearbox (1) and the tool holder (2).
2. Pull the clutch (2) off the planetary gear.
3. Remove the motor with the electronics (3) from the motor housing.
4. Pull the bush (4) off the planetary gear.
5. Pull off the plug (5).
Tools:
- Slotted screwdriver
7.0x125
1 2
4
3
5
