JLab JBuds Frames Bedienungsanleitung
LR
JBUDS
FRAMES
Locate the L&Ron the back. If needed, add the
Rubber Sleeves on hooks for narrow stem glasses.
ASSEMBLY
1
Press and hold BOTH buttons 5+ seconds. One side
will start blinking blue/white indicating ready to connect.
CONNECTING BLUETOOTH
1
Slide the JBuds Frames on corresponding
left and right stems of glasses.
2
Enter your device settings and connect to
“JLab JBuds Frames”. Solid white lights will
indicate you are connected.
2
C
U
S
T
O
M
E
R
S
U
P
P
O
R
T
U
.
S
.
B
A
S
E
D
We love that you are rocking JLab!
We take pride in our products and fully stand behind them.
YOUR WARRANTY
All warranty claims are subject to JLab authorization
and at our sole discretion. Retain your proof of
purchase to ensure warranty coverage.
CONTACT US
or visit jlab.com/contact
L
I
M
I
T
E
D
T
W
O
Y
E
A
R
REGISTER TODAY
jlab.com/register
Product updates | How-to tips
FAQs & more
The JBuds Frames should be positioned
closest to the ear for best performance.
L
R
Thin Frames:
ICON facing out
Very Thin Frames:
LOGO facing out
Rubber
Sleeves
Bluetooth
Settings
JLab JBuds Frames
ADDING NEW/ADDITIONAL BLUETOOTH DEVICES:
Turn OFF Bluetooth from any previously connected device. Turn ON Bluetooth from new device. Power ON the JBuds Frames and they will
enter Bluetooth pairing after 10 seconds. Select “JLab JBuds Frames” in new device settings to connect.
VOICE PROMPTS
“Hello”: Power ON
“Earbuds joined”:
Earbuds paired to each other
“Ready to Pair”: JBuds Frames are ready
to pair to Bluetooth device
“Bluetooth Connected”:
Earbud is connected to device
“Battery Full”: 100-80%
“Battery Medium”: 80-20%
“Low Battery”: Less than 20%
When power decreases to 10%,
“Low Battery” will play
“Goodbye”: Power OFF
BUTTON FUNCTIONS
Triple press either the right or left earbud 3 times for different EQ settings.
EQ SETTINGS
JLab SIGNATURE
JLab C3™ signature
sound with amplified
bass and vocals
BASS BOOST
Amplified bass
and sub-bass
CHARGING
RIGHT
BUTTON
LEFT
BUTTON
INDICATOR
LIGHT
INDICATOR
LIGHT
VOLUME DOWN: Single press
SIRI (iOS) or “OK GOOGLE” (ANDROID):
Double press
TRACK BACKWARD: Press & hold 1+ sec
VOLUME UP: Single press
PLAY / PAUSE: Double press
TRACK FORWARD: Press & hold 1+ sec
ANSWER: Single press
HANGUP: Double press
REJECT INCOMING CALLS: Press & hold 1+ sec
EQ CHANGE: Triple press on either earbud (Cycles JLab Signature/Bass Boost)
POWER ON / OFF: Press & hold 3+ sec on either earbud (Button will power OFF both sides)
OR
Connect the JBuds Frames to computer
or USB 5V 1A (or less) output device. CHARGING
TROUBLESHOOTING
QUICK TIPS
Instructional videos at: JLAB.COM/MANUALS
NO AUDIO IN ONE SIDE OR BLUETOOTH DOES NOT CONNECT/RECONNECT (MANUAL RESET)
Enter your Bluetooth device settings and forget the JLab JBuds Frames.
When JBuds Frames are powered OFF, Press and hold both buttons 15+ sec.
Frames will power ON then power OFF.
Press and hold both buttons 3+ sec to power ON. JBuds Frames will start blinking blue/white indicating ready to connect.
Enter device settings and reconnect.
Position the JBuds Frames as close to your ears as possible.
This will greatly improve the audio performance.
You can use either JBuds Frames left or right independently or
both together with Dual Connect to listen to music or take calls.
Note you will only have access to the left or right controls if
you’re using only one.
OR
L R
Bluetooth
Settings
JLab JBuds Frames Connected
1
2
3
Bluetooth
Settings
JLab JBuds Frames i
PRESS & HOLD
15+ SEC
Bluetooth
Settings
JLab JBuds Frames
CAUTIONS
• Avoid extreme heat, cold, and humidity.
• Avoid dropping or crushing the earbuds.
• Wax may build up in the earbud tips, lowering the sound quality.
Carefully remove the wax with a cotton swab or other small tool to improve the sound quality.
• If you experience discomfort or pain, try lowering the volume or discontinuing use temporarily.
• If you experience regular discomfort while using this product, discontinue use and consult your physician.
• We recommend you treat your earbuds as you would a nice pair of sunglasses and keep them in safe location when not in use.
JLAB.COM
Shop products |Product alerts |Burn-in your headphones
