4 IN 1 MULTI-FUNCTION PETROL GARDEN TOOL

CT2836

ORIGINAI INSTRUCTION

WARNING

•Before using our products, please read this

manual carefully to understand the proper use

of your unit. Keep this manual handy.

•This product is of a special type designed

especially for garden service. It is only to be

used by a trained operator.

Cannon Tools Limited

Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM

SAVE THESE INSTRUCTIONS FOR REFERENCE

EC DECLARATION OF CONFORMITY

We CANNON TOOLS LTD

20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K

Declare that the following machine complies with the appropriate basic safety

and health requirements of the EC Directive based on its design and type, as

brought into circulation by us.

In case of alteration of the machine, not agreed upon by us, this declaration will

lose its validity.

Product description: 4 IN 1 MULTI-FUNCTION PETROL GARDEN TOOL

Model: CT2836

Applicable EC Directives:

EC Machinery Directive 2006/42/EC

EC Directive of Electromagnetic Compatibility 2014/30/EU

EU Noise Directive 2000/14/EC & 2005/88/EC

Harmonized standards：

EN ISO11806-1:2011, EN ISO 10517:2019,EN ISO 14982:2009

EN ISO 3744:1995, ISO 90207:1995, ISO 11904:1991, ISO 10084:1995

20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.

Mr. Gurcharan Tony Singh Sanghera

Managing Director

CANNON TOOLS LTD

2020-11-10

1. TECHNICAL INFORMATION

Engine information

Volume of the fuel tank

1200ml

Max engine speed

9500/min

Engine idling speed

3000/min

Clutch engagement speed

3910 /min

Engine displacement

52 cm³

Maximal power

1.45 kW / 7500/min

Noise level and vibration

Sound power level: 105,4 dB(A)

Guarantee sound power level: 111dB(A)

Sound pressure level: 96,2 dB(A)

Uncertainties K = 3 dB(A)

Vibration

-Front handle:

Idling: 8,303 m/s²

Racing: 7,723 m/s²

-Rear handle:

Idling: 7,737 m/s²

Racing: 6,763 m/s²

-K = 1,5 m/s²

Brush cutter

Cutting diameter

1.4x255mm

Maximum rotational frequency of the spindle

9500/min

Cutting blade

Hedge trimmer

Cutting length

Cutting wide: 24mm;

Cutting range:430mm

Type of the hedge trimmer blade

Double

Maximum rotational frequency of the spindle

9500/min

Grass trimmer

Cutting diameter

430mm

Maximum rotational frequency of the spindle

9500/min

Cutting string head

￠2.5mm max

Pole pruner

Cutting length

10” /25 cm

Maximum rotational frequency of the spindle

9500/min

2. SAFETY INSTRUCTIONS

2.1.1 General warnings

Proper safety precautions must be observed. This unit must be handled carefully.

DO NOT EXPOSE YOURSELF OR OTHERS TO DANGER.

Follow these general rules. Do not permit others to use this machine unless they

are thoroughly responsible and have read, and understand the machine manual

and are trained in its operation.

Always wear safety goggles for eye protection. Dress properly; do not wear

loose clothing or jewellery that could become caught in moving parts of the unit.

Safe, sturdy, non-skid footwear should always be worn. Long hair should be tied

back. It is recommended that legs and feet be covered to protect from flying

debris during operation.

Protective equipment must always be wear during the operation of the tool,

including at least hearing protection, eyes protection, helmet, gloves, and mask

of protection, slip-resistant foot protection, and protective clothes.

Inspect the entire machine for loose parts (nuts, bolts, screws, etc.) and any

damage. Repair or replace as necessary before using the machine. DO NOT

USE any attachment other than the ones recommended by our company.

Serious injury to the operator or bystanders could result as well as damage to

the machine. Ask advice to you dealer of manufacturer. Do not use cutting

attachment such as metal multi-piece pivoting chains and flail blades.

Secure the machine during transport to prevent loss of fuel, damage or injury;

always install the protection device on the blade, check the cap of the fuel tank,

and do not transport the tool upside down.

Keep the handles free from oil and fuel.

Always use proper handles and shoulder strap when cutting.

Do not smoke while mixing fuel or filling tank.

Do not mix fuel in an enclosed room or near open flames. Assure adequate

ventilation.

Always mix and store the fuel in a properly marked container that is approved by

local codes and ordinances for such usage.

Never remove the fuel tank cap while the engine is running.

Never start or run the engage inside a closed room or building. Fumes from the

exhaust contain dangerous carbon monoxide.

Never attempt to make engine adjustments while the unit is running and

strapped to the operator. Always make engine adjustments with the unit resting

on a flat, clear surface.

Do not use the unit if it is damaged or poorly adjusted. Never remove the

machine’s guard. Serious injury to the operator or bystanders could result as

well as damage to the machine.

Inspect the area to be cut and remove all debris that could become entangled in

the nylon cutting head. Also remove any objects that the unit may throw during

cutting.

Keep children away. Onlookers should be kept at a safe distance from the work

area, at least 15 meters.

Never leave the machine unattended.

Do not use this unit for any job other than those for which it is intended as

described in this manual.

Do not overreach. Keep proper footing and balance at all times. Do not run the

unit while standing on a ladder or on any other unstable footing location.

Keep hands and feet clear of the nylon cutting head or blade while unit is in use.

Do not use this type of machine for sweeping away debris.

Do not use the unit when you are tired, ill or under the influence of medication,

drugs or alcohol.

Use nylon cutting head which is free of damage. If a stone or any other obstacle

is hit, stop the engine and check the nylon cutting head. A broken or unbalanced

nylon cutting head must never be used.

Do not store in a closed area where fuel vapors can reach an open flame from

hot water heaters, furnaces, etc. Store in a locked, well-ventilated area only.

Ensure safe and proper performance of your product. These parts are available

from your dealer. The use of any other accessories or attachments may cause a

potential hazard or injury to the user, damage to the machine and void this

warranty.

Clean the machine completely, especially, the fuel tank, its surroundings, and

the air cleaner.

When refueling, be sure to stop the engine and confirm that it is cooled down.

Never refuel when the engine is running or hot. When gasoline spills, be sure to

wipe it up completely dispose of those materials before starting the engine.

Stay clear of other workers or bystanders by at least 15 meters.

Whenever approaching an operator of the machine, carefully call his attention

and confirm that the operator stop the engine. Be careful not to startle or distract

the operator which can cause an unsafe situation.

Never touch the nylon cutting head or blade whenever the engine is running. If it

is necessary to replace the protector or cutting attachment, be sure to stop the

engine and confirm that the cutting device has stopped running.

The engine should be turned off when the machine is moved between work

areas.

Be careful not to hit the nylon cutting head against stones, or the ground.

Unreasonable rough operation will shorten the life of the machine as well as

create an unsafe environment for yourself and those around you.

Pay attention to loosening and overheating of parts. If there is any abnormality of

the machine, stop operation immediately and check the machine carefully. If

necessary, have the machine serviced by an authorized dealer. Never continue

to operate a machine which may be malfunctioning.

In start-up or during operation of the engine, never touch hot parts such as the

muffler, the high voltage wire or the spark plug.

After the engine has stopped, the muffler is still hot. Never place the machine in

any places where there are flammable materials (dry grass, etc.), combustible

gasses or combustible liquids.

Pay special attention to operation in the rain or just after the rain as the ground

may be slippery.

If you slip or fall to the ground or into a hole, release the throttle lever

immediately.

Be careful not to drop the machine or hit it against obstacles.

Before proceeding to adjust or repair the machine, be sure to stop the engine

and detach the spark plug.

When the machine is placed in storage for a long time, drain fuel from the fuel

tank and carburetor, clean the parts, move the machine to a safe place and

confirm that the engine is cooled down.

Make periodic inspections to assure safe and efficient operation. For a thorough

inspection of your machine, please contact a dealer.

Keep the machine away from fire or sparks.

It is believed that a condition called Raynaud’s phenomenon, which affects the

fingers of certain individuals, may be brought about by exposure to vibration and

cold. Loss of color and numbness in the fingers. The following precautions are

strongly recommended because the minimum exposure which might trigger the

ailment is unknown.

Keep your body warm, especially the head, neck, feet, ankles, hands and wrists.

Maintain good blood circulation by performing vigorous arm exercises during

frequent work breaks and also by not smoking.

Limit the hours of operation. Try to fill each day with jobs where operating the

brush cutter or other hand-held power equipment is not required.

If you experience discomfort, redness and swelling of the fingers followed by

whitening and loss of feeling, consult your physician before further exposing

yourself to cold and vibration.

Always wear ear protection, loud noise for long time can make hearing debase

even lost hearing.

Total face and head protection must be wearing to prevent damage from

plummet or branch.

Wear no-slip heavy duty work gloves to improve your grip on the brush cutter

handle. Gloves also reduce the transmission of machine vibration to your hands.

WARNING: The cutter area is still dangerous while the machine is coasting

to a stop.

When transport, this unit must be handled carefully. Do not expose yourself or

others to danger.

Envelop the blade before storage. Keep children away from it.

Never remove the machine’s guard.

Clean and maintain the tool before storage . Bring maintenance after each use

according the instructions of this manual. Improper maintenance can reduce

the lie of the tool, bring bad results and wear the tool and its accessories.

Check the tool before and after use. Check for loose fasteners, fuel leaks and

damaged parts, such as cracks in the cutting attachment. If the tool is damaged,

if parts are missed or meet some dysfunctions, do not use the tool and bring it to

a service agent for inspection and reparation.

Check the tool after dropping or other impacts to identify any significant

defects; if any defects are observed, stop to use the tool and bring it to a service

agent for inspection and reparation.

Do not store in a closed area where fuel vapors can reach an open flame from hot

water heaters, furnaces, etc. Store in a locked, well-ventilated area only.

Never place the machine in any places where there are flammable materials

(dry grass, etc.), combustible gasses or combustible liquids.

When the machine is placed in storage for a long time, drain fuel from the fuel

tank and carburetor, clean the parts, move the machine to a safe place and

confirm that the engine is cooled down.

Emission of exhaust gases

National regulation can restrict the use of the machine.

Never modify a trimmer or cutter in any way.

Improper use of the machine can cause SERIOUS OR FATAL PERSONAL

INJURY.

The engine exhaust form this product contains chemicals to cause cancer,

birth defects, of other reproductive harm.

Check regularly that the cutting attachment stops turning when the engine

idles.

2.1.2 Kickback and Related Warnings

● Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad,

brush or any other accessory. Pinching or snagging causes rapid stalling of the

rotating accessory which in turn causes the uncontrolled power tool to be forced in

the direction opposite of the accessory’s rotation at the point of the binding.

● For example, if an abrasive wheel is snagged or pinched by the work piece, the

edge of the wheel that is entering into the pinch point can dig into the surface of the

material causing the wheel to climb out or kick out. The wheel may either jump

toward or away from the operator, depending on direction of the wheel’s movement

at the point of pinching. Abrasive wheels may also break under these conditions.

●Kickback is the result of power tool misuse and/or incorrect operating procedures or

conditions and can be avoided by taking proper precautions as given below:

oNever place your hand near the rotating accessory. Accessory may kickback over

your hand.

oDo not position your body in the area where power tool will move if kickback

occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at

the point of snagging.

oUse special care when working corners, sharp edges etc. Avoid bouncing and

snagging the accessory. Corners, sharp edges or bouncing have a tendency to snag

the rotating accessory and cause loss of control or kickback.

2.1.3 Residual risks

Even if you use this tool correctly, there are always residual risks. The following

hazards may arise in connection with the structure and manufacture of this

power tool:

-Hearing impairment if no suitable hearing protection is worn.

-Cuts if no suitable protective clothing is worn.

-Health damage resulting from vibration in the hands and arms if the device

is used for a long period of time or is not handled and maintained properly.

-Inhalation of particles

-Inhalation of exhaust gases

-Skin contact with oil / gasoline

-Inhalation of gasoline / oil vapors

-Contact with projected objects

-Burns when touching with hot surfaces

-Prolonged use of this product exposes the operator to vibration and can

produce so-called "white finger" disease. To reduce the risk, wear gloves

and keep your hands warm.

-If any of the symptoms of "white finger syndrome" occur, seek immediate

medical attention. Symptoms of the "white finger" include numbness, loss of

sensitivity, tingling, pain, loss of strength, color changes or skin condition.

These symptoms usually appear on the fingers, hands or wrists. Risk

increases at low temperatures.

3. INTENDED USE

3.1 Brush cutter and grass trimmer

3.1.1 Intended use

This machine can be used as a trimmer with the cutting edge, and as a brush

cutter with the cutting blade.

The grass trimmer must be strictly and only to cut grass or weeds that are not too

dense. The brush cutter must be used to cut hard grass, more dense weeds and

small branches with a maximum diameter of 10mm.

3.1.2 Improper use

This machine is not intended to cut bushes or others similar plants requiring the

tool to get off the ground. Do not use this tool to work other materials such as

stones, clay soils, etc.

3.2 Mounted pole pruner

3.2.1 Intended use / improper use

The pole pruner is exclusively intended for pruning trees and/or cutting small

wood from the ground. Any other use is considered improper and will damage

the tool.

The correct use also includes reading and observing the instructions for use at

each use as well as observing the warnings fixed on the machine. Before and

during use, it is imperative to check the blade to ensure that there is no

mechanical damage. In case of necessary repairs, please contact your specialist

dealer.

Only the use of spare parts approved by the manufacturer or original spare parts

is permitted. If unauthorized or non-original spare parts are used, the user is

liable for consequential injury to persons or property resulting in the

manufacturer being deprived of all liability.

3.3 Hedge trimmer

3.3.1 Intended Use

Your hedge trimmer is a device used by a person to trim hedges and shrubs by

working with one or more blades arranged linearly and back and forth. A

potential hazard exists if the device is used for other purposes. Improper

handling of the hedge trimmer increases the risk of injury from blades. Only the

use of spare parts and accessories approved by the manufacturer is permitted.

3.4 QUICK RELEASE MECHANISM

Once properly adjusted, check that the quick release harnesses work properly.

Pull the strip to release the machine from you in the case of emergency.

4. TECHNICAL DESCRIPTION

1- Engine unit

2- Control unit

3- Main pole

4- Handle

5- Connection

6- Shoulder strap

7- Pole Pruner head

8- Edge trimmer head

9- Brush cutter & Grass

trimmer head

10- Nylon spool

11- Blade

1. Engine unit

2. Spark plug

3. Recoil starter

4. Air filter

assembly

5. Fuel tank

6. Wiring

7. Shaft

8. Handle

9. Throttle trigger

10. Throttle

lockout lever

11. Throttle lock

button

12. Ignition On/Off

switch

13. Hook for

shoulder strap

Inhaltsverzeichnis

Andere Jobsite Werkzeuge Handbücher

Jobsite

Jobsite CT4343 Bedienungsanleitung

Beliebte Werkzeuge Handbücher anderer Marken

Martor

Martor SECUNORM 175 Bedienungsanleitung

ERKCO

ERKCO 1000 Bedienungsanleitung

jbc

jbc N4473 Bedienungsanleitung

FEINMETALL

FEINMETALL FZWZ-SET-001 Bedienungsanleitung

Worx Professional

Worx Professional Sonicrafter WU676 Bedienungsanleitung

Gage Bilt

Gage Bilt GB713SH Bedienungsanleitung

Hilti

Hilti DX 9-ENP Bedienungsanleitung

norbar

norbar NORTRONIC 34399 Bedienungsanleitung

BGS technic

BGS technic 8578 Bedienungsanleitung

Makita

Makita DHR241 Bedienungsanleitung

Motor Guard

Motor Guard JMB-1250 Bedienungsanleitung

Power Adhesives

Power Adhesives 805-12 Bedienungsanleitung

Clemco

Clemco 24189 Bedienungsanleitung

VVG

VVG VNG 903 Series Bedienungsanleitung

Hilti

Hilti FX 3-A Bedienungsanleitung

Grizzly

Grizzly H6472 Bedienungsanleitung

axing

axing BWZ 5-02 Bedienungsanleitung

Dh-Robotics

Dh-Robotics RGI-100 Anleitung zur Verwendung
