WOOD CHIPPER
User’s Manual
TC100
Please read through this owner’s manual carefully before using the product, to ensure the safety
of yourself and others.
*Due to continuing improvements, actual product may differ slightly from the product described
herein.
Thank you for choosing chipper of JONCO. We are sure, this machine will
definitely help you with wood chipping and make your work easier and faster in
following long period of time. To the owner of this machine, you will also find, it
is so simple for maintenance, accessories and problems solution, with support by
a wide and professional team service net around you.
Attention!
Please read the manual and warning signs or security points carefully.
ignoring to read and understand the manual content, may cause failure to
start machine, damage to the machine or serious injure to operator. Before
using the machine, make sure you have read the manual and understand all.
1. Specifications
MECHANICAL SPECIFICATIONS
Engine
Air cool, diesel engine / Gasoline engine
Displacement
460cc
Start
Electric
Chipping Capacity
5"
Rotor Speed
2,200 RPM
Blade
2 blade, 1 anvil blade
Trailer
Jockey wheel
Axis with tubeless tire
Size
2370*1070*1600MM
Weight
250KG
Serial Number
A Serial Number is used to identify your machine. The number is located on the
Serial Number Label on your machine. For your convenience and ready reference,
enter the Serial Number in the space provided on the front cover of this manual.
2 . General safety rules
• Read this safety & operating manual before you use TC100 chipper. Become
familiar with the operation and service recommendations to ensure the best
performance from your machine.
• Thoroughly inspect the area in which you will be working and remove all foreign
objects such as rope, wire, etc., and remove these objects before chipping.
Inserting these objects into the chipper hopper could damage the machine and/or
cause injury.
• This is a high-powered machine, with moving parts operating with high energy
at high speeds. You must use proper clothing and safety gear when operating this
machine to prevent or minimize the risk of severe injury. This machine can crush,
grind, cut, and sever parts of your body if they enter the inlet or discharge area of
your chipper.
2.1 Labels
Your TC100 CHIPPER carries prominent labels as reminders for its proper and
safe use. Shown below are copies of all the safety and operation labels that appear
on the equipment. Take a moment to study them and make a note of their location
on your chipper as you assemble and before you operate the unit. Replace
damaged or missing safety and operation labels immediately.
No entry in the area marked. Stay away from the machine in
radius of 10 meters.
Attention
Read manual before using the machine.
Use gloves.
Use goggles
Use mufflers
No touch on rotor, be caution that rotor is easily rolling and very
dangerous.
Be careful of sharp blades.
2.2 Safety for Yourself and Those Around You
• This is a high-powered machine, with moving parts operating with high energy
at high speeds. You must operate the machine safely.
• Unsafe operation can create a number of hazards for you, as well as anyone else
in the nearby area.
ALWAYS TAKE THE FOLLOWING PRECAUTIONS WHEN USING THIS
MACHINE:
• Always wear protective goggles or safety glasses with side shields while
chipping to protect your eyes from possible thrown debris.
• Avoid wearing loose clothing or jewelry, which can catch on moving parts or the
material fed into the chipper hopper.
• We recommend wearing gloves while chipping. Be sure your gloves fit properly
and do not have loose cuffs or drawstrings.
• Wear shoes with non-slip treads when using your chipper. If you have safety
shoes, we recommend wearing them. Do not use the machine while barefoot or
wearing open sandals.
• Wear long pants while operating TC100 chipper.
• Use mufflers or ear plugs rated for at least 20 dba to protect your hearing.
• Never allow people who are unfamiliar with these instructions to use the chipper.
Allow only responsible individuals who are familiar with these rules of safe
operation to use your machine.
• Never place your hands, feet, or any part of your body in the chipper hopper,
discharge opening, or near or under any moving part while the machine is running.
Keep area of discharge clear of people, animals, buildings, glass, or anything else
that will obstruct clear discharge, cause injury, or damage. Wind can also change
discharge direction, so be aware. If it becomes necessary to push material into the
chipper hopper, use a small diameter stick, not your hands.
• Keep bystanders 10 meters away from your work area at all times. Wood chips
exit the chipper at great speeds. To be safe, do not operate the machine near small
children or pets, and never allow children to operate the chipper. Stop the engine
when another person or pet approaches.
• Never use the machine without ensuring that all guards and shields are in place,
including the chipper hopper, conveyor and blowback shield.
• Always operate the machine from the operator zone. Never pass or stand on the
discharge side of the machine when the tractor engine is running or the rotor is
turning.
•Never transport the chipper with engine on and the rotor turning.
• Clear the area of objects such as wire and rope, etc. Inserting these objects into
the chipper hopper could damage the rotor and/or cause injury.
• Never, under any conditions, remove, bend, cut, fit, weld, or otherwise alter
standard parts on TC100 chipper. Modifications to your machine could cause
personal injuries and property damage and will void your warranty.
2.3 Safety for Children and Pets
• Tragic accidents can occur if the operator is not alert to the presence of children
and pets. Children are often attracted to the machine and the chipping activity.
Never assume that children will remain where you last saw them.
ALWAYS FOLLOW THESE PRECAUTIONS:
• Keep children and pets at least 100 feet from the working area and under the
watchful care of a responsible adult.
• be alert and turn the machine off if children or pets enter the work area.
• never allow children to operate TC100 chipper.
2.4 General Safety
• TC100 chipper is a powerful tool, not a plaything.
• Operating this chipper safely is necessary to prevent or minimize the risk of
death or serious injury. Unsafe operation can create a number of hazards for you.
• Exercise extreme caution at all times. The design of this machine is to chip wood.
Do not use it for any other purpose.
ALWAYS TAKE THE FOLLOWING PRECAUTIONS WHEN
OPERATING THIS CHIPPER:
• Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people, their property, and themselves.
• know how to stop the chipper quickly by stop diesel engine.
• Operate this machine on a level surface only. Never operate your unit on a
slippery, wet, muddy, or icy surface. Exercise caution to avoid slipping or falling.
• Keep your face and body back from the chipper hopper to avoid accidental
bounce back of any material.
• When feeding material into the chipper hopper, be extremely careful that pieces
of metal, rocks, or other foreign objects are not included. Personal injury or
damage to the machine could result.
• Whenever you leave the operating position or if you have to remove processed
material, leaves, or debris from the machine, always shut down the engine,
remove the key, wait for all moving parts to come to a complete stop, then wait 5
minutes before removing processed material, leaves, or debris from the machine.
• If the cutting mechanism strikes a foreign object or if your machine should start
making an unusual noise or vibration, immediately shut down engine, remove the
key, wait for all moving parts to come to a complete stop, then wait 5 minutes
before inspecting for clogging or damage. Vibration is generally a Warning of
trouble. Clean and repair and/or replace damaged parts.
• Never tamper with safety devices. Check their proper operation regularly.
• Stay alert for hidden hazards or traffic. Never carry passengers on your machine.
• Never overload or attempt to chip material beyond the manufacturer’s
recommendation; see chapter 4. personal injury or damage to the machine could
result.
• While using TC100 chipper, don't hurry or take things for granted. When in
doubt about the equipment or your surroundings, stop the machine and take the
time to look things over.
• Never operate the machine when under the influence of alcohol, drugs, or
medication.
• Use the machine only in daylight.
• Keep all nuts and bolts tight and keep the equipment in good operating
condition.
No list of warnings and cautions can be all-inclusive. If situations occur that
Are not covered by this manual, the operator must apply common sense and
Operate this chipper in a safe manner.
2.5 Transportation Safety
• Before transporting, be certain the TC100 chipper is correctly and securely
attached to your truck.
• Make sure the jockey when is raised high enough during transportation.
• Never transport the machine for long distances.
• Never allow anyone to ride on the TC100 chipper.
• Never transport anything on the machine.
• Never transport the TC100 chipper with engine on.
• Obey local, state, and federal regulations when transporting the machine on
Public roads and highways.
• Allow for added length in driving situations, e.g., when turning, parking, and
Crossing intersections.
• Adjust your transportation speed for terrain and conditions.
• Use caution when backing or turning. Be aware of the large turning radius
Required with TC100 chipper attached to your truck.
Additional Information and Potential Changes
Jonco company reserves the right to discontinue, change, and improve its
products at any time without notice or obligation to the purchaser. The
descriptions and specifications contained in this manual were in effect at printing.
Equipment described within this manual may be optional. Some illustrations may
not be applicable to your machine.
3. Setting up
This chapter outlines unpacking and a few simple steps you will need to follow to
set up your new machine before you use it. It may be helpful to familiarize
yourself with the controls and features of your TC100 CHIPPER as shown in
before beginning these procedures.
3.1
3.2 Unpacking
• Wear gloves when removing the crate top to protect your hands from debris.
• Stabilize the wood crate on clean flat terrain before attempting to unpack and
assemble the chipper.
Unpacking the TC100 CHIPPER is a two-person job. We recommend you have an
extra set of hands available before you begin because the CHIPPER weighs
300KG.
Step A
1. Use the electric driller with socket 10mm to take off the fix screw
2. Lift up crate top and put it aside by two people
3. Remove the carton board
4. Take off the stretching plastic
5. Cut plastic banding with wire cutter
Step B
1. Put carton board under banding aside on a
flat area
2. Remove the conveyor and all other parts
packed inside
3. Put the hopper aside with carton board cushioned
All the package materials are recyclable, please do not throw them away as waste.
3.3 Assembly
1. Attach the tow bar to the trailer. then fix the jockey wheel on.
2. Attach the axis on to trailer frame.
3. Raise up the jockey wheel in clockwise, to get enough space for tire assembly.
(keep the air valve outside and tighten the nut with tapered side in)
4. Low down the jockey, and you can drag the trailer away from the pallet
