JUKI M-1 Series Bedienungsanleitung

M-1 Series

INSTRUCTION MANUAL

(Electrical)

Foreword

Welcome to use the products of our company and it’s the right investment choices of clothing

industry! This is the product reference manual of the company's newly developed "suction line cut".

Please carefully read this manual to better use the company's products!

⚫Before reading this manual, please note the following requirements:

1. Before practicing,the user must be grounded to ensure personal safety!（Ground resistance : <

4Ω）

2. Non-professionals do not disassemble the control box;

3. Please use at room temperature above 5 ℃,below 45 ℃;

4. Please work in 30% to 90% of the relatively humid environment;

5. Rated voltage 220V±10%,frequency 50/60HZ；

6. Use soft cotton cloth to clean the upper and lower infrared light before daily use.

⚫Safety Precautions:

1. Do not put your feet on the pedal when the power is connected;

2. This product requires professional installation and commissioning;

3. Do not open the control box when power is on;

4. Turn off the power when changing the needle, threading or replacing the

bottom thread;

5. Turn off the power when installing, removing and repairing;

6. Turn off the power when turning or lifting the sewing machine;

7. Away from high-frequency electromagnetic waves and radio waves, etc, in order to avoid the

servo drive being interference by the electromagnetic waves and leading to the wrong action.

⚫Warranty strategy:

1. Any quality problems other than man-made damage during the warranty period may be free

of charge;

2. Without the consent of the company to disassemble, modification damage will not give the

warranty;

3. If you can’t solve a problem, you can contact the company;

4. The company has the final interpretation of this manual

Catalogue

1: Introduction to the common operation of the display

2: How to enter and modify parameters

3: Operation parameters description table

3.1 Technician system parameter list

3.2 Workers system parameter list

4: Control box port description

5: fault code analysis

1: Introduction to the common operation of the display

NO.

Icon

Function description

Mode switch key: to switch the current sewing mode, will be in cycle

between the free seam, semi-automatic, fully automatic, and normal sewing.

Infrared light function key: open and close the infrared light, long press 2

seconds into the light eye sensitivity adjustment.

In the light eye sensitivity adjustment interface,

click, , , to automatically adjust the light eye intensity

corresponding to thin material, medium material, thick material.After the

adjustment is completed, press the button to save.

Presser -foot function key: Select the ways of the presser-foot when sewing

mode, you can continuously press to successively select before presser-foot,

after the presser-foot, before and after the presser-foot, or closed.

Trimming function key: select the ways of trimming when sewing mode,

continuously press in turn can choose the front cut line, after the cut line,

before and after the cut line, or close.

Air-suction function key (need to install the suction device): select the

method of suction when sewing, continuously press can be selected before

the suction, after the suction, before and after the suction, or closed.

Stop-needle adjustment key: used to change over the needle bar stop

position at the time of stopping sewing between up and down.

Menu key: enter the user parameters, long press 2 seconds to enter the

system parameters (need a password).

Confirm key: parameter confirmation key.

Numeric adjustment key: used to modify the data.

Left key: When the parameter is modified, the cursor moves left.

2: How to enter parameters and how to modify the parameters

The analysis to enter System parameters: long press ( ) button for 2 seconds into the

"system parameters" list (need the password to enter adjustment). （）,（） Keys be

used to select to modify the parameter value or menu value, the selected place will be flashing.

（）（）Keys will increase or decrease the value of the flashing area. After editing the

parameters, press the （） key to save the parameters and exit the system parameters.

Right key: When the parameter is modified, the cursor moves right.

Maintenance key: When the machine need to be adjusted when an exception

occurs, press this button or turn off the power for maintenance.

F-SENSOR

The front infrared sensor

indicator light

When the front infrared sensor is

blocked by a cloth, F-SENSOR light

on, else light off.

M-SENSOR

The middle infrared sensor

indicator light

When the middle infrared sensor is

blocked by a cloth, M-SENSOR light

on, else light off.

B-SENSOR

The Behind infrared sensor

indicator light

When the behind infrared sensor is

blocked by a cloth, B-SENSOR light

on, else light off.

ERROR

Safety switch indicator light

Flashing when disconnecting, light off

under normal circumstances

MAINTAIN

Maintenance indicator light

When the maintenance key is pressed,

the lamp flashes and the lamp is turned

off after exiting the service mode.

3: Operating Parameter Description Table

3.1 Technician system parameter list( long press to enter )

NO.

Function

description

Parameter

default

values

Parameter

adjustment

range

Parameter description

S02

Check the number

of needles after

living the first

infrared light

1~50

Set the number of needles between

two infrared light

S03

Delay before

trimming the

number of stitches

0~50

After the behind infrared light

sensing, the number of stitches to

delay trim

S04

Delay after

trimming the

number of stitches

0~50

After the behind infrared light

leaving, the number of stitches to

delay trim

S05

Front suction open

needle number

1~50

Induction of the first infrared light

from which needles began to inhale

S06

Front suction close

needle number

1~50

When opened, the count after a few

stitches to close the intake

S07

Behind suction

open needle

number

1~50

leaving the behind infrared light

from which needles began to inhale

S08

Behind suction

close delay

200

50~5000ms

After leaving the light eye, count

how much milliseconds to close the

inhale

S12

Stop delay pin

number

1~99

After How many needles , it

automatically stops after the cut line

S13

The suction

opening pin

number

1~247

Suction after how many needles

leave eye light

S14

Suction close pin

number

1~100

Number of suction pins

S15

Back cut light eye

1~100

After leaving the light in eyes for

how many needle not detected the

third eye light signal to begin to cut

the line

S16

Back sensor

response time

1~100ms

The front eye light’s response time

after the induction

S19

The front presser

foot retaining time

220

100~2000ms

The duration after the presser foot

lift(ms)

S20

Trimming full

power

100

0—100%

Trimming action full power

adjustment

S21

Presser foot

protection time

1~120s

how much time before manual

presser foot turn off（s）

S22

the presser foot

protection time

20~800ms

The time of putting the presser foot

(ms)

S23

Continuous feed,

suction, and shear

line

0~1

0：close 1：open

S24

Manual trimming

switch

0~1

0: When the motor is running,

manual trimming doesn’t work.

1: It works

S25

Safety switch

0~3

0: closed safety switch 1: sewing

station safety switch 2: presser foot

safety switch 3: open all safety

switch

S26

Scissors keep time

10~1000ms

Cutting time（no need adjust in

principle）

S27

Interface recovery

time

5~99s

The time does the control panel go

back to the main interface (seconds)

after entering the menu

S29

Front light eye

polarity

0~1

front light eye reflex reverse polarity

S30

Back light eye

polarity

0~1

back light eye reflex reverse polarity

S31

Presser foot full

time

180

10~990ms

Presser foot work full power time

S32

Presser foot full

power

100

20~100%

presser foot start action,

instantaneous power output

S33

Presser foot keep

power

10~90%

presser foot lift after maintain

power(no more than 50%)

S35

Back cut light eyes

0~1

0：close 1：open

S37

Language

0~1

0：Chinese 1：English

S38

Maximum speed

lock

5500

300~6500

Limit the maximum adjustable

speed of the motor

S39

Restore factory

parameters

0~1

Adjusted to 1 and long press OK key

to reset valid

3.2 Workers system parameter list ( short press to enter )

Number

Function

declaration

default

Reference

range

Parameter specification

P-01

Operator schema

0~3

0：normal sewing1：free seam2:semi-automatic

3:full automatic

P-02

Infrared Sensor

switch

0~1

0:off 1:on

P-03

trimming

0~3

0:off 1:front trimming 2:back trimming 3:front

and back trimming

P-04

suction

0~3

0:off 1:front suction 2:back suction 3:front and

back suction

P-06

Presser foot

0~3

0:no presser foot 1:front presser foot 2:back

presser foot 3:front and back presser foot

P-07

Start mode of

velocity

0~1

0:automatic 1:pedal

P-08

Needle position

0~1

0:below needle position 1:up needle position

P-09

automatic presser

foot

0~1

0:off 1:on

P-10

Hand-operated

suction

0~1

0:off 1:on

P-11

Start sewing

speed

5500

300~6500

P-12

Maximum speed

5500

300~6500

P-13

Work lamp

brightness

0~2

P-14

Back-light

brightness

0~1

0:off 1:on

P-15

Free for sewing

0~1

0:off 1:on

P-16

Semi-automatic

constant speed

trimming

0~1

0:off 1:on

P-17

Front presser

foot

0~1

0:Automatic mode 1:hand-operated mode

Andere Handbücher für M-1 Series

Andere JUKI Nähmaschine Handbücher

JUKI

JUKI DDL-900B Bedienungsanleitung

JUKI

JUKI MO-735 Bedienungsanleitung

JUKI

JUKI MF-7500-E11 Bedienungsanleitung

JUKI

JUKI MO-6900C Series Bedienungsanleitung

JUKI

JUKI APW-896/IP-420 Bedienungsanleitung

JUKI

JUKI MO-655 Bedienungsanleitung

JUKI

JUKI LK-1903B Series Bedienungsanleitung

JUKI

JUKI MO-50e Bedienungsanleitung

JUKI

JUKI DDL-8100B-7 Series Bedienungsanleitung

JUKI

JUKI Union Special MFC-7406 Bedienungsanleitung

JUKI

JUKI TL-2200QVP Mini Bedienungsanleitung

JUKI

JUKI TC16 Bedienungsanleitung

JUKI

JUKI LU-2810 Series Bedienungsanleitung

JUKI

JUKI LU-1510 Bedienungsanleitung

JUKI

JUKI HZL-F series Bedienungsanleitung

JUKI

JUKI IP-100A Kurzanleitung

JUKI

JUKI DDL-5550-7 Bedienungsanleitung

JUKI

JUKI AMS-210EN/IP-420 Bedienungsanleitung

JUKI

JUKI LZ-2284N-7 Bedienungsanleitung

JUKI

JUKI LH-3128 Bedienungsanleitung

JUKI

JUKI MCS-1500 Bedienungsanleitung

JUKI

JUKI DDL-8700B-7 Bedienungsanleitung

JUKI

JUKI MH-481 Bedienungsanleitung

JUKI

JUKI MS-1190 Bedienungsanleitung

Beliebte Nähmaschine Handbücher anderer Marken

Riccar

Riccar RL634DE Bedienungsanleitung

Singer

Singer 2517 Bedienungsanleitung

Pfaff

Pfaff 3307-1 SERIES Bedienungsanleitung

Janome

Janome Quilt Maker Pro 18 VERSA Bedienungsanleitung

Siruba

Siruba C007JP Bedienungsanleitung

Husqvarna Viking

Husqvarna Viking Designer SE Bedienungsanleitung

Singer

Singer 148-5 Bedienungsanleitung

IKEA

IKEA SY Bedienungsanleitung

Pfaff

Pfaff 571 Bedienungsanleitung

Singer

Singer 15-91 Bedienungsanleitung

Brother

Brother BB370 Bedienungsanleitung

Pegasus

Pegasus WT100 Series Bedienungsanleitung

Reliable

Reliable 7100DB Bedienungsanleitung

Pfaff

Pfaff 937 Bedienungsanleitung

Singer

Singer 6038 Bedienungsanleitung

Singer

Singer 413K Bedienungsanleitung

Pfaff

Pfaff 1471 E1 Bedienungsanleitung

Kenmore

Kenmore 16677 - Serger Sewing Machine Bedienungsanleitung
