Getting Started

6 The Anatomy of the Field PC

7 Getting Started

6Field PC Owner’s Manual

The Field PC is a rugged handheld computer designed for

data collection from multiple environments. Equipped with

Windows Mobile 6 it features a wide variety of applications

soware and accessories.

The Anatomy of the Field PC

The picture below shows some of the important features of the

Field PC.

CAUTION: Tampering

with the jack screws will

break the waterproof

seal of the unit.

USB client (mini B)

Touchscreen/display

Top lanyard cleats

Battery door latches

Power button

Bottom lanyard cleats

USB host (full size A)

12V DC jack

Stylus

9-pin serial port

Back compartment door

Getting Started

Install the Battery Pack

When you receive the Field PC, you must install and charge

the NiMH baery pack before using. To do this, complete the

following steps:

1. Push up on the sliding latches on the sides of the Field PC

to open the baery compartment door.

2. Place the NiMH baery pack in the le side of the baery

compartment, push down, and slide it all the way to the

right. There is a small arrow on the boom right corner of

the baery pack, make sure the arrow is pointing to the

right when it is placed in the Field PC.

Ch 1 Getting Started 7

8Field PC Owner’s Manual

3. Push the baery door closed until the slide latches click

into place. If the latches are not securely in place the unit is

no longer water tight.

Note: Do not turn on the Field PC yet.

4. Plug the AC wall charger that came with the Field PC into

the wall socket.

5. Remove the rubber protector from the Field PC’s external

power input jack.

6. Plug the wall charger into the Field PC power jack located

at the top of the case. The Charge Seings screen opens

requesting you set the charge percentage. Select Enter

percentage and capacity, set the baery charge to 10%, and

leave the baery capacity at 4000.

7. Charge the baery pack at room temperature for at least

6 hours.

Ch 1 Getting Started 9

10 Field PC Owner’s Manual
