Juniper M120 Bedienungsanleitung

M120 Internet Router

PIC Guide

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, California 94089

USA

408-745-2000

www.juniper.net

Part Number: 530-024399-01, Revision 1

This guide provides an overview and description of the Physical Interface Cards (PICs)

supported by the Juniper Networks M120 Internet router. The PICs are described

alphabetically. Table 1 on page 3 lists the PICs supported by the M120 Internet

router by PIC family.

PICs provide the physical connection to various network media types. The PICs are

mounted on Flexible PIC Concentrators (FPCs), which are inserted into a slot in a

router. A PIC typically occupies a single slot on an FPC. PICs receive incoming packets

from the network and transmit outgoing packets to the network. During this process,

each PIC performs framing and high-speed signaling for its media type. Before

transmitting outgoing data packets, the PICs encapsulate the packets received from

the FPCs. Each PIC is equipped with a media-specific ASIC that performs control

functions tailored to the PIC's media type. For complete information about installing

PICs and transceivers, see the PIC and Transceiver Installation Instructions located at

http://www.juniper.net/techpubs/.

Blank PICs resemble other PICs but do not provide any physical connection or activity.

When a slot is not occupied by a PIC, you must insert a blank PIC to fill the empty

slot and ensure proper cooling of the system.

M120 routers support the Type 1, Type 2, and Type 3 FPCs listed in Table 2 on page

6 and the Compact FPCs (cFPCs) listed in Table 3 on page 6. Table 6 on page 9

provides a PIC/FPC compatibility matrix for the supported PICs for the M120 router.

For a complete list of end-of-life FPCs and end-of-life Enhanced FPCs for M-series

and T-series routing platforms, see the M-series and T-series Routing Platform

End-of-Life FPC Guide located at http://www.juniper.net/techpubs/.

2■

M120 Internet Router PIC Guide

Table 1: PICs Supported by the M120 Internet Router

Page

First JUNOS

SupportPortsPIC Family and Type

ATM2 IQ

208.0R24ATM2 DS3 IQ

228.0R24ATM2 E3 IQ

248.0R22ATM2 OC3/STM1 IQ

278.0R21ATM2 OC12/STM4 IQ

278.0R22ATM2 OC12/STM4 IQ

308.0R21ATM2 OC48/STM16 IQ with SFP

Channelized IQ

338.0R24Channelized DS3 IQ

358.0R210Channelized E1 IQ

378.0R21Channelized OC3 IQ

408.0R21Channelized OC12 IQ

438.0R21Channelized STM1 IQ

458.0R210Channelized T1 IQ

DS3, E1, E3, and T1

488.0R24DS3

508.0R24E1

1128.0R24T1

E3 IQ

528.0R24E3 IQ

EIA-530

548.0R22EIA-530

Fast Ethernet

568.0R24Fast Ethernet

568.0R28Fast Ethernet

568.0R212Fast Ethernet

568.0R248Fast Ethernet

Gigabit Ethernet

738.0R2110-Gigabit Ethernet with XENPAK

■3

Table 1: PICs Supported by the M120 Internet Router (continued)

Page

First JUNOS

SupportPortsPIC Family and Type

788.0R2110-Gigabit Ethernet DWDM

608.0R21Gigabit Ethernet with SFP

608.0R22Gigabit Ethernet with SFP

608.0R24Gigabit Ethernet with SFP

608.0R210Gigabit Ethernet with SFP

Ethernet IQ

638.0R21Gigabit Ethernet IQ with SFP

638.0R22Gigabit Ethernet IQ with SFP

Ethernet IQ2

668.0R24Gigabit Ethernet IQ2 with SFP

668.0R28Gigabit Ethernet IQ2 with SFP

668.58Gigabit Ethernet IQ2 with SFP

708.2110-Gigabit Ethernet IQ2 with XFP

Services

128.0R20Adaptive Services II

178.0R20Adaptive Services II Layer 2 Services

158.0R20Adaptive Services II FIPS

808.2R20MultiServices 100

808.20MultiServices 400

808.30MultiServices 500

1148.0R20Tunnel Services

SONET/SDH

838.0R24SONET/SDH OC3c/STM1

878.44SONET/SDH OC3/STM1 (Multi-Rate)

with SFP

878.34SONET/SDH OC3/STM1 (Multi-Rate)

with SFP

4■

M120 Internet Router PIC Guide

Table 1: PICs Supported by the M120 Internet Router (continued)

Page

First JUNOS

SupportPortsPIC Family and Type

918.0R21SONET/SDH OC12c/STM4

948.41SONET/SDH OC12/STM4

(Multi-Rate) with SFP

948.34SONET/SDH OC12/STM4

(Multi-Rate) with SFP

998.0R24SONET/SDH OC48c/STM16 with SFP

1038.31SONET/SDH OC48 /STM16

(Multi-Rate) with SFP

1088.31SONET/SDH OC192c/STM64 PIC

with XFP

■5

FPCs and cFPCs Supported

M120 routers support the FPCs listed in Table 2 on page 6.

Table 2: FPCs Supported by the M120 Router

First JUNOS

Release

Maximum Throughput

per FPC

Maximum Number

of PICs Supported

per FPC

FPC Model NumberFPC NameFPC Type

8.0R24 Gbps4M120-FPC1FPC11

8.0R210 Gbps4M120-FPC2FPC22

8.0R210 Gbps1M120-FPC3FPC33

A cFPC is a combination of a PIC and an FPC. It contains the interface circuitry and the FPC as a single assembly. Both cFPCs

provide receptacles for XFP optical transceivers. The M120 chassis provides two slots for cFPCs, and supports any combination

of cFPC types. M120 routers support the cFPCs listed in Table 3 on page 6.

Table 3: cFPCs Supported by the M120 Router

ConnectorFirst JUNOS

Release

Maximum

Throughput per

cFPC

cFPC Model

Number

cFPC Name

Duplex LC/PC (Rx

and Tx)

8.0R210 GbpsM120-cFPC-1XGE-XFP10-Gigabit Ethernet

Duplex LC/PC (Rx

and Tx)

8.0R210 GbpsM120-cFPC-1OC192-XFPSONET/SDH OC192/STM64

The 10-Gigabit Ethernet cFPC supports the XFPs listed in Table 4 on page 6.

Table 4: Optical Interface Support for 10-Gigabit Ethernet cFPC

10-GBASE-Z10-GBASE-E10-GBASE-L10-GBASE-SParameter

XFP-10G-Z-OC192-LR2XFP-10G-E-OC192-IR2XFP-10G-L-OC192-SR1XFP-10G-STransceiver model

number

Single-modeSingle-modeSingle-modeMultimodeOptical interface

XFPXFPXFPXFPTransceiver type

Multivendor

agreement

IEEE 802.3ae—2002IEEE 802.3ae—2002IEEE 802.3ae—2002Standard

6■FPCs and cFPCs Supported

M120 Internet Router PIC Guide

Table 4: Optical Interface Support for 10-Gigabit Ethernet cFPC (continued)

10-GBASE-Z10-GBASE-E10-GBASE-L10-GBASE-SParameter

9/125 SMF cable:

49.6 miles/80 km

9/125 SMF cable:

24.8 miles/40 km:

Distances greater than

30 km are considered

to be engineered

links.

9/125 SMF cable:

6.2 miles/10 km

50/125 MMF cable,

2000 Mhz-Km:

984 feet/300 m

50/125 MMF cable,

500 Mhz-Km:

269 feet/82 m

50/125 MMF cable,

400 Mhz-Km:

217 feet/66 m

62.5/125 MMF cable,

200 Mhz-Km:

108 feet/33 m

62.5/125 MMF cable,

160 Mhz-Km:

85 feet/26 m

Maximum distance

1530 through

1565 nm

1530 through

1565 nm

1260 through

1355 nm

840 through 860 nmTransmitter wavelength

0 through 4 dBm–4.7 through 4 dBm–4 through 0.5 dBm–4.5 through –1 dBmAverage launch power

–24.0 through

–7.0 dBm

–15.8 through

–1.0 dBm

–14.4 through

0.5 dBm

–9.9 through

–1.0 dBm

Average receive power

–7 dBm–1.0 dBm0.5 dBm–1.0 dBmReceiver saturation

–24 dBm–15.8 dBm–14.4 dBm–9.9 dBmReceiver sensitivity

The SONET/SDH OC192/STM64 cFPC supports the XFPs listed in Table 5 on page 7.

Table 5: Optical Interface Support for SONET/SDH OC192/STM64 cFPC

Long Reach (LR) 2

Intermediate reach

(IR) 2Short reach (SR) 1Parameter

XFP-10G-Z-OC192-LR2.XFP-10G-E-OC192-IR2XFP-10G-L-OC192-SR1Transceiver model number

Single-modeSingle-modeSingle-modeOptical interface

XFPXFPXFPTransceiver type

Telcordia GR-253

OC192 LR2

Telcordia GR-253

OC192 IR2

Telcordia GR-253

OC192 SR1

Standard

FPCs and cFPCs Supported ■7

FPCs and cFPCs Supported

Table 5: Optical Interface Support for SONET/SDH OC192/STM64 cFPC (continued)

Long Reach (LR) 2

Intermediate reach

(IR) 2Short reach (SR) 1Parameter

SMF cable:

49.71 miles/80 km

SMF cable:

24.8 miles/40 km;

distances greater than

30 km are considered

to be engineered

links.

SMF cable:

6.21 miles/10 km

Maximum distance

1530 through 1565 nm1530 through

1565 nm

1290 through

1330 nm

Transmitter wavelength

0 through 4 dBm–1.0. through 2 dBm–6 through –1 dBmAverage launch power

–7 dBm–1.0 dBm–1.0 dBmReceiver saturation

–24 dBm–14 dBm–11 dBmReceiver sensitivity

8■FPCs and cFPCs Supported

M120 Internet Router PIC Guide

PIC/FPC Compatibility

Table 6 on page 9 provides a PIC/FPC compatibility matrix for the supported PICs for the M120 router.

Table 6: M120 PIC/FPC Compatibility

FPC3FPC2FPC1PIC Model NumberNumber of PortsPIC Type

ATM2 IQ PICs

––8.0R2PB-4DS3-ATM24ATM2 DS3 IQ

––8.0R2PB-4E3-ATM24ATM2 E3 IQ

––8.0R2

PB-2OC3-ATM2-MM

PB-2OC3-ATM2-SMIR

ATM2 OC3/STM1 IQ

––8.0R2

PB-1OC12-ATM2-MM

PB-1OC12-ATM2-SMIR

ATM2 OC12/STM4 IQ

–8.0R2–

PB-2OC12-ATM2-MM

PB-2OC12-ATM2-SMIR

ATM2 OC12/STM4 IQ

–8.0R2–PB-1OC48-ATM2-SFP1ATM2 OC48/STM16 IQ, SFP

Channelized IQ PICs

––8.0R2PB-4CHDS3-QPP4ChDS3 IQ

––8.0R2PB-10CHE1-RJ48-QPP10ChE1 IQ

––8.0R2PB-1CHOC3-SMIR-QPP1ChOC3 IQ

––8.0R2PB-1CHOC12SMIR-QPP1ChOC12 IQ

––8.0R2PB-1CHSTM1-SMIR-QPP1ChSTM1 IQ

––8.0R2PB-10CHT1-RJ48-QPP10ChT1 IQ

T1, DS3, E1, E3 PICs

––8.0R2PB-4DS34DS3

––8.0R2

PB-4E1-COAX

PB-4E1-RJ48

––8.0R2PB-4T1-RJ484T1

E3 IQ PIC

––8.0R2PB-4E3-QPP4E3 IQ

PIC/FPC Compatibility ■9

PIC/FPC Compatibility

Table 6: M120 PIC/FPC Compatibility (continued)

FPC3FPC2FPC1PIC Model NumberNumber of PortsPIC Type

EIA-530 PIC

––8.0R2PB-2EIA5302EIA-530

Ethernet PICs

––8.0R2PB-4FE-TX4Fast Ethernet

––8.0R2PB-8FE-FX8Fast Ethernet

––8.0R2PB-12FE-TX12Fast Ethernet

–8.0R2–PB-48FE-TX48Fast Ethernet

––8.0R2PB-1GE-SFP1Gigabit Ethernet, SFP

–8.0R2–PB-2GE-SFP2Gigabit Ethernet, SFP

–8.0R2–PB-4GE-SFP4Gigabit Ethernet, SFP

8.0R2––PC-10GE-SFP10Gigabit Ethernet, SFP

10-Gigabit Ethernet PICs

8.0R2––PC-1XGE-XENPAK110-Gigabit Ethernet, XENPAK

8.0R2––PC-1XGE-DWDM-CBAND110-Gigabit Ethernet, DWDM

Ethernet IQ PICs

––8.0R2PB-1GE-SFP-QPP1Gigabit Ethernet IQ, SFP

–8.0R2–PB-2GE-SFP-QPP2Gigabit Ethernet IQ, SFP

10-Gigabit Ethernet IQ2 PICs

8.2––PC-1XGE-TYPE3–XFP-IQ2110-Gigabit Ethernet IQ2 PIC, XFP

Ethernet IQ2 PICs

––8.0R2PB-4GE-TYPE1-SFP-IQ24Gigabit Ethernet IQ2, SFP

–8.0R2–PB-8GE-TYPE2-SFP-IQ28Gigabit Ethernet IQ2, SFP

8.5––PC-8GE-TYPE3-SFP-IQ28Gigabit Ethernet IQ2, SFP

Services PICs

––8.0R2PB-AS20Adaptive Services II (AS)

––8.0R2PB-AS2-LAYER2SERVICES0

Adaptive Services II (AS) Layer 2

Services

––8.0R2PB-AS2-FIPS0Adaptive Services II (AS) FIPS

10 ■PIC/FPC Compatibility

M120 Internet Router PIC Guide

Andere Handbücher für M120

Inhaltsverzeichnis

Andere Juniper Netzwerk-Router Handbücher

Juniper

Juniper PTX10001-36MR Bedienungsanleitung

Juniper

Juniper ACX2200 Bedienungsanleitung

Juniper

Juniper ACX500 Bedienungsanleitung

Juniper

Juniper PTX10002-60C Bedienungsanleitung

Juniper

Juniper J-Series Bedienungsanleitung

Juniper

Juniper E-Series Montageanleitung

Juniper

Juniper ACX500 Bedienungsanleitung

Juniper

Juniper E SERIES BROADBAND SERVICES ROUTERS 11.3.X - ERX MODULE GUIDE REV... Bedienungsanleitung

Juniper

Juniper ERX - RELEASE 11.1.X HARDWARE GUIDE... Montageanleitung

Juniper

Juniper MX104 Montageanleitung

Juniper

Juniper ACX6160 Bedienungsanleitung

Juniper

Juniper T320 Montageanleitung

Juniper

Juniper ACX5048 Montageanleitung

Juniper

Juniper EX4500 Series Montageanleitung

Juniper

Juniper ACX6160 Montageanleitung

Juniper

Juniper M10i Montage- und Bedienungsanleitung

Juniper

Juniper EX9200 Series Technisches Datenblatt

Juniper

Juniper CTP2000 Series Bedienerhandbuch

Juniper

Juniper SSR1200 Montageanleitung

Juniper

Juniper M120 Montageanleitung

Juniper

Juniper PTX10003-160C Bedienungsanleitung

Juniper

Juniper T4000 - Bedienungsanleitung

Juniper

Juniper MX Series Bedienungsanleitung

Juniper

Juniper MX204 Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
