Juniper TX MATRIX PLUS Bedienungsanleitung

TX Matrix Plus Router

Quick Start

January 2015

Part Number: 530-062019

Revision 01

This document describes how to install the Juniper Networks TX Matrix Plus Router.

Contents TXMatrixPlusQuickStartDescription...................................3

Step1:PreparetheSite...............................................3

TX Matrix Plus Rack-Mounting Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Tools Required to Install the TX Matrix Plus Router . . . . . . . . . . . . . . . . . . . . . 4

Step 2: Install the Mounting Hardware for a TX Matrix Plus Router . . . . . . . . . . . . . 4

Install the TX Matrix Plus Mounting Hardware for a Four-Post Rack . . . . . . . . 5

InstallCageNuts,IfNeeded....................................5

Install the Four-Post Mounting Shelf and Rear Support Bracket . . . . . . . 6

Remove the Center-Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Install the TX Matrix Plus Mounting Hardware for an Open-Frame Rack . . . . 8

Assemble the Open-Frame Rack Mounting Shelf . . . . . . . . . . . . . . . . . . . 9

InstallCageNuts,IfNeeded....................................9

Install the Open-Frame Rack Mounting Shelf . . . . . . . . . . . . . . . . . . . . . . 11

Step 3: Install the TX Matrix Plus Router Using a Mechanical Lift . . . . . . . . . . . . . 12

RemoveTXMatrixPlusComponents................................12

Install the TX Matrix Plus Router Using a Lift . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Reinstall TX Matrix Plus Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Step 4: Connect the TX Matrix Plus Router to a Management Console or Auxiliary

Device.........................................................21

Step 5: Install the TX Matrix Plus Rear Cable Management System and Front

Cable Manager .................................................22

Step 6: Ground the TX Matrix Plus Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Step 7: Set the TX Matrix Plus Configuration Size and Switch Fabric Chassis

Number .......................................................23

Step 8: Connect Power to a Seven-Input 420-A Power Supply in a TX Matrix

PlusRouter....................................................24

Step 9: Power On the TX Matrix Plus Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Step 10: Perform the Initial Software Configuration for the TX Matrix Plus

Router ........................................................30

EnterConfigurationMode........................................30

Configure User Accounts and Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

ConfigureSystemAttributes.......................................31

CommittheConfiguration........................................32

Step 11: Connect the Switching Plane Cables to the TX Matrix Plus Router . . . . . 33

Step 12: Integrate the Line-Card Chassis into the Routing Matrix . . . . . . . . . . . . . . 33

TXMatrixPlusSafetyWarnings........................................33

TX Matrix Plus Preventing Electrostatic Discharge Damage . . . . . . . . . . . . . . . . . 34

TX Matrix Plus Compliance Statements for NEBs . . . . . . . . . . . . . . . . . . . . . . . . . 37

Compliance Statements for EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Canada .......................................................37

EuropeanCommunity............................................37

Israel .........................................................38

Japan.........................................................38

United States ..................................................38

Junos OS Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

RequestingTechnicalSupport........................................39

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

OpeningaCasewithJTAC........................................40

RevisionHistory....................................................40

TX Matrix Plus Router Quick Start

TX Matrix Plus Quick Start Description

This Quick Start contains information you need to install and configure the TX Matrix

Plus Router quickly. For complete installation instructions, see the TX Matrix Plus Router

Hardware Guide at http://www.juniper.net/techpubs/hardware/.

WARNING: This Quick Start contains a summary of safety warnings in “TX

Matrix Plus Safety Warnings” on page 33. For a complete list of warnings for

this router, including translations, see the TX Matrix Plus Router Hardware

Guide at http://www.juniper.net/techpubs/hardware/.

The TX Matrix Plus router is a modular, rack-mountable system. One TX Matrix Plus

router can be installed in one standard 23-in. wide, 78-in. high, EIA telco rack. The TX

Matrix Plus router is shipped in a wooden crate. A wooden pallet forms the base of the

crate. TheTX Matrix Plus chassis is bolted to this pallet. The shipping crate contains:

•One accessory box (the box to which this Quick Start is taped)

•One Juniper Networks TX Matrix Plus router

•One Quick Start (this document)

•One tool kit

•Mounting hardware

•Cable management system

Step 1: Prepare the Site

•TX Matrix Plus Rack-Mounting Requirements on page 3

•Tools Required to Install the TX Matrix Plus Router on page 4

TX Matrix Plus Rack-Mounting Requirements

The TX Matrix Plus router can be installed in many types of racks. Follow these guidelines:

•The rack rails must be spaced widely enough to accommodate the TX Matrix Plus

router chassis's external dimensions: 52.0 in. (132.1 cm) high, 36.2 in. (91.9 cm) deep,

and 21.4 in. (54.4 cm) wide. The center-mounting brackets and front-mounting flanges

extend the width to 23 in. (58.4 cm) racks.

•If the horizontal spacing between the rails is wider than the center-mounting brackets

or front-mounting flanges, use approved wing devices to narrow the opening between

the rails as required.

•The rack must be strong enough to support the weight of the fully configured TX Matrix

Plus router, up to 925 lb (420 kg).

•We recommend that you install one TX Matrix Plus router in its own dedicated rack.

TX Matrix Plus Quick Start Description

•For service personnel to remove and install hardware components, there must be

adequate space at the front and back of the TX Matrix Plus router. Allow at least 30 in.

(61.0 cm) both in front of and behind the TX Matrix Plus router.

•The rack must have an adequate supply of cooling air.

Figure 1: Rack Clearances and TX Matrix Plus Platform Dimensions

g004529

(mounting hole width)

Center-mounting bracket

Front-mounting flange

Front

cable manager

depth 2.7" (6.9 cm)

Cable

management

depth 9"

30" (72.6 cm)

clearance recommended

for maintenance

36.2" (91.9 cm)

21.4"

(54.4 cm)

Front of chassis Rear of chassis

23"

(58.4 cm)

30" (61 cm)

clearance required

for maintenance

Tools Required to Install the TX Matrix Plus Router

•A mechanical lift (required)

•7/16-in. nut driver

•1/2-in.or 13 mm open-end or socket wrench for removing chassis from pallet

•Phillips (+) screwdriver, number 2

•Electrostatic discharge wrist strap

•Antistatic mat

•Dust-free resealable plastic bags for temporary storage of fiber-optic dust covers

•Electrostatic discharge (ESD) grounding wrist strap

•Blank panels to cover any slots not occupied by a component

Step 2: Install the Mounting Hardware for a TX Matrix Plus Router

You can install the mounting hardware in either an open-frame rack or a four-post rack.

•Install the TX Matrix Plus Mounting Hardware for a Four-Post Rack on page 5

•Install the TX Matrix Plus Mounting Hardware for an Open-Frame Rack on page 8

TX Matrix Plus Router Quick Start

Install the TX Matrix Plus Mounting Hardware for a Four-Post Rack

1. Install Cage Nuts, If Needed on page 5

2. Install the Four-Post Mounting Shelf and Rear Support Bracket on page 6

3. Remove the Center-Mounting Brackets on page 7

Install Cage Nuts, If Needed

Insert cage nuts, if needed, into the holes listed in Table 1 on page 5 and

Table 2 on page 5 (an X indicates a mounting hole location). The hole distances are

relative to the standard U division on the rack that is aligned with the bottom of the

mounting shelf and rear support bracket.

To install cage nuts in a four-post rack:

1. On the rear rack rails, insert cage nuts in the holes specified for the rear support bracket.

Install the cage nuts in the rear of the rear rail (see Table 1 on page 5).

2. On the front rack rails, insert cage nuts in the holes specified for the four-post mounting

shelf. Install the cage nuts in the front of the front rail. (see Table 1 on page 5).

3. On the front rack rails, insert cage nuts in the holes specified for mounting the chassis.

Install the cage nuts in the front of the front rail (see Table 2 on page 5).

Table 1: Mounting Hole Locations for Installing the Four-Post Mounting

Shelf and Rear-Support Bracket

Rear

SupportBracket

Four-Post Rack

Mounting ShelfDistance Above U DivisionHole

XX1.86 U3.25 in. (8.3 cm)6

XX1.5 U2.63 in. (6.7 cm)5

XX1.14 U2.00 in. (5.1 cm)4

XX0.86 U1.50 in. (3.8 cm)3

XX0.50 U0.88 in. (2.2 cm)2

XX0.14 U0.25 in. (0.6 cm)1

The holes in the front-mounting flanges are spaced at 2 U (3.5 in. or 8.9 cm).

Table 2: Mounting Hole Locations for Installing a TX Matrix Plus Chassis

in a Four-Post Rack

Distance Above U DivisionHole

28.86 U50.50 in. (128.3 cm)87

26.86 U47.00 in. (119.4 cm)81

Install the TX Matrix Plus Mounting Hardware for a Four-Post Rack

Table 2: Mounting Hole Locations for Installing a TX Matrix Plus Chassis

in a Four-Post Rack (continued)

Distance Above U DivisionHole

24.86 U43.50 in. (110.5 cm)75

22.86 U40.00 in. (101.6 cm)69

20.86 U36.5 in. (92.7 cm)63

18.86 U33.00 in. (88.8 cm)57

16.86 U29.50 in. (74.9 cm)51

14.86 U24.26 in. (61.6 cm)45

12.86 U22.51 in. (57.2 cm)39

10.86 U19.01 in. (48.3 cm)33

8.86 U15.51 in. (39.4 cm)27

6.86 U12.00 in. (30.5 cm)21

4.86 U8.50 in. (21.6 cm)15

2.86 U5.00 in. (12.7 cm)9

Install the Four-Post Mounting Shelf and Rear Support Bracket

To install the four-post mounting shelf and rear support bracket (see Figure 2 on page 7):

1. On the rear of each rear rack rail, partially insert a mounting screw into the lowest hole

specified in Table 1 on page 5.

2. Install the rear support bracket on the rear of the rear rack rails. Rest the bottom slot

of the rear support bracket on a mounting screw. The rear support bracket extends

toward the center of the rack.

3. Partially insert screws into the open holes in the rear support bracket.

4. Tighten all the screws completely.

5. On the front of each front rack rail, partially insert a mounting screw into the lowest

hole specified in Table 1 on page 5.

6. Install the four-post rack mounting shelf on the front rack rails. Rest the bottom slot

of the front flange on a mounting screw. Rest the back of the four-post rack mounting

shelf on top of the rear support bracket.

7. Tighten all the screws completely.

TX Matrix Plus Router Quick Start

8. Fasten the four-post mounting shelf to the rear support bracket by partially inserting

the screws provided in the accessory kit into the open holes on top of the four-post

mounting shelf.

NOTE: Several holes are provided on top of the shelf. Two holes on each

side of the shelf will align with the holes in the rear support bracket.

9. Tighten all the screws completely.

Figure 2: Installing the TX Matrix Plus Mounting Hardware for a Four-Post

Rack

g004534

Rear support bracket

Four-post mounting shelf

fits over the rear support

bracket.

These screws attach the four-post

mounting shelf to the rear support

bracket.

Four-post mounting shelf

Remove the Center-Mounting Brackets

The center-mounting brackets are not used for a four-post rack, and must be removed

from the chassis.

To remove the center-mounting brackets from the chassis:

1. Loosen the screws from each bracket (see Figure 3 on page 8).

2. Remove each bracket.

Remove the Center-Mounting Brackets

Figure 3: TX Matrix Plus Center-Mounting Bracket Removal

g004533

Center-mounting bracket

Install the TX Matrix Plus Mounting Hardware for an Open-Frame Rack

1. Assemble the Open-Frame Rack Mounting Shelf on page 9

2. Install Cage Nuts, If Needed on page 9

3. Install the Open-Frame Rack Mounting Shelf on page 11

TX Matrix Plus Router Quick Start

Assemble the Open-Frame Rack Mounting Shelf

The open-frame rack mounting shelf is shipped in three pieces: one bottom piece and

two side pieces. Eight screws are provided. To assemble the open-frame rack mounting

shelf:

1. Place one side of the mounting shelf over the holes on the bottom shelf piece.

2. Partially insert screws into the open holes in the flanges of the open-frame rack

mounting shelf.

3. Tighten all the screws completely.

4. Place the other side of the mounting shelf over the holes on the bottom shelf piece.

5. Partially insert screws into the open holes in the flanges of the open-frame rack

mounting shelf.

6. Tighten all the screws completely.

Install Cage Nuts, If Needed

Insert cage nuts, if needed, into the holes listed in Table 3 on page 9 and

Table 4 on page 10 (an X indicates a mounting hole location). The hole distances are

relative to the standard U division on the rack that is aligned with the bottom of the

mounting shelf and rear support bracket.

To install cage nuts in an open-frame rack:

1. On the rear side of both rack rails, insert cage nuts in the holes specified for the

open-frame mounting shelf (see Table 3 on page 9).

2. On the front side of both rack rails, insert cage nuts in the holes specified for mouting

the chassis (see Table 4 on page 10).

Table 3: Mounting Hole Locations for Installing a TX Matrix Plus

Open-Frame Rack Shelf

Open-Frame MountingShelfDistance Above U DivisionHole

X13.86 U24.25 in. (61.6 cm)42

X12.86 U22.5 in. (57.2 cm)39

X11.86 U20.75 in. (52.7 cm)36

X10.86 U19.0 in. (48.3 cm)33

X9.86 U17.25 in. (43.8 cm)30

X8.86 U15.5 in. (39.4 cm)27

X7.86 U13.75 in. (34.9 cm)24

Assemble the Open-Frame Rack Mounting Shelf

Table 3: Mounting Hole Locations for Installing a TX Matrix Plus

Open-Frame Rack Shelf (continued)

Open-Frame MountingShelfDistance Above U DivisionHole

X6.86 U12.0 in. (30.5 cm)21

X5.86 U10.25 in. (26.0 cm)18

X4.86 U8.5 in. (21.6 cm)15

X3.86 U6.75 in. (17.1 cm)12

X2.86 U5.0 in. (12.7 cm)9

X1.86 U3.25 in. (3.8 cm)6

The holes in the center-mounting brackets are spaced at 2 U (3.5 in. or 8.9 cm).

Table 4: Mounting Hole Locations for Installing a TX Matrix Plus Chassis

in an Open-Frame Rack

ChassisDistance Above U DivisionHole

X29.86 U52.5 in. (132.7 cm)90

X27.86 U48.75 in. (123.8 cm)84

X25.86 U45.25 in. (114.9 cm)78

X23.86 U41.75 in. (106.0 cm)72

X21.86 U38.25 in. (97.2 cm)66

X19.86 U34.75 in. (88.3 cm)60

X17.86 U31.25 in. (79.4 cm)54

X15.86 U27.75 in. (70.5 cm)48

X13.86 U24.25 in. (61.6 cm)42

X11.86 U20.75 in. (52.7 cm)36

X9.86 U17.25 in. (43.8 cm)30

X7.86 U13.75 in. (34.9 cm)24

X5.86 U10.25 in. (26.0 cm)18

X3.86 U6.75 in. (17.1 cm)12

TX Matrix Plus Router Quick Start

Andere Handbücher für TX MATRIX PLUS

Inhaltsverzeichnis

Andere Juniper Netzwerk-Router Handbücher

Juniper

Juniper T Series Bedienungsanleitung

Juniper

Juniper EX9200 Series Technisches Datenblatt

Juniper

Juniper MX150 Montageanleitung

Juniper

Juniper M-Series Bedienungsanleitung

Juniper

Juniper M10i Montageanleitung

Juniper

Juniper T4000 - Montageanleitung

Juniper

Juniper Internet Router M160 Montageanleitung

Juniper

Juniper JUNOS OS 10.4 Bedienungsanleitung

Juniper

Juniper MX Series Bedienungsanleitung

Juniper

Juniper ERX - RELEASE 11.1.X HARDWARE GUIDE... Montageanleitung

Juniper

Juniper MX Series Bedienungsanleitung

Juniper

Juniper ACX Series Bedienungsanleitung

Juniper

Juniper MX204 Bedienungsanleitung

Juniper

Juniper ACX1000 Bedienungsanleitung

Juniper

Juniper MX960 Montageanleitung

Juniper

Juniper M10 Montageanleitung

Juniper

Juniper J4350 Bedienungsanleitung

Juniper

Juniper ACX2000 Bedienungsanleitung

Juniper

Juniper ERX-1410 Bedienungsanleitung

Juniper

Juniper NetScreen-5GT Wireless Bedienungsanleitung

Juniper

Juniper M120 Bedienungsanleitung

Juniper

Juniper QFX10002 Bedienungsanleitung

Juniper

Juniper E SERIES BROADBAND SERVICES ROUTERS - E SERIES END-OF-LIFE MODULE GUIDE... Bedienungsanleitung

Juniper

Juniper J-Series Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
