JVA Solar Wi-Fi Anywhere
Quick Start Guide
WA150
PTE2704
The JVA Logo is a registered trademark of JVA Technologies
© JVA Technologies
Page 2
Introducon
The PTE2704 JVA Wi-Fi Anywhere (WA150) provides an integrated Wire-
less Cellular USB Dongle (Wingle) power supply with a solar baery char-
ger and management system.
This product provides a Wi-Fi network wherever a 3G/4G signal is avail-
able*. The Wi-Fi can then be used to connect an IP device or Internet of
Things (IoT) device to the Cloud (Internet).
The JVA Solar Wi-Fi Anywhere is installed with an ALDI SIM card at the
factory, all you need to do is:
1. Register the SIM card
2. Connect any Wi-Fi enabled device to the network provided
This quick-start guide explains how to deploy your WA150 and connect a
baery ready for Wi-Fi connecons.
*An external cellular antenna (included) may be connected to increase
recepon. An upgraded YAGI style antenna is available from sales@jva-
fence.com.au
Specicaons
Component Informaon
Solar Panel Nominal 12v Solar Panel
(maximum open circuit voltage - 22v DC)
Maxmium Power 150W
Baery Nominal 12.8v DC
Minimum Baery size 225Ah
A larger baery may be required if any
addional 12v device is connected to the baery
Outputs(1) 12v DC SAE Connector
Used for powering the IP Monitor
Page 3
JVA WA150
Component Informaon
Outputs (2) 12v DC Baery Connector
Alligator clips for baery connecon
SIM Full Size
Wi-Fi 2.4GHz b/g/n
Up to 10 connecons at a me
Network
(Huawei E8372)
3G 850/2100MHz
4GX 700MHz + 4G B1/3/7/21
Antenna Connector Female SMA
Ensure antenna is mounted away from sources of
interference such as AC or high voltage cables.
Troubleshoong
Fault Likely Cause Remedy
No lights are on Power is not connected
Power wires are re-
versed
Check power connec-
ons
Check baery polarity
Baery not charging Solar wiring backwards
Broken cables
Solar panel broken
Check that the Solar +
goes to the le-hand
screw terminal
Check that the baery
cables are not dam-
aged
Check solar panel for
physical damage (bro-
ken glass, bent frame
etc.)
Page 4 © JVA Technologies www.jva-fence.com
Fault Likely Cause Remedy
Cannot connect to
Wi-Fi
Low signal from 3G/4G
Out of Wi-Fi range
(~10m)
SIM card not inserted
correctly
Check management
page of Wingle
Move closer to Wingle
Re-insert SIM card
If the unit is sll not working correctly, contact your nearest JVA distribu-
tor for technical support.
Before you start
Acvate the SIM card
Acvate your SIM card and test it in a mobile phone. The Wi-Fi network
allows a data-only connecon, the number of devices connected to the
module will determine how much data will be used.
As a guide, a single IP Energiser or IP Monitor will use less than 1MB per
day, so for connecng a single IP Energiser, an upper limit of 500MB per
year is an opon with a lot of headroom.
Tools Needed:
• H6 Hex allen key (Solar Bracket)
• 13mm wrench (Solar Bracket)
• 14mm wrench (U-bolt)
Page 5
© JVA Technologies www.jva-fence.com JVA WA150
Deployment and Orientaon
1. Unpack the solar kit from it’s packaging. Look inside the packaging for
a set of U-Bolts.
2. Remove the U-Bolts from the zip lock bag and mount it to the top and
boom panel of the bracket.
(A) U-Bolt x 2 (B) Top or Boom Panel
(C) Washers x 4 (D) Spring Washers x 4 (E) Hex Nut x 4
Page 6 © JVA Technologies www.jva-fence.com
3. Mark the mounng pole. This is where the top of the U-bolt will be.
Slide the U-bolts over the pole and ghten when the top bolt aligns
with the previous marking.
4. Loosen the 6 bolts on the inside of the frame. DO NOT completely re-
move these bolts. Li the boom of the solar panel unl the aached
arms holding it are angled at 90 degrees. Tighten all 6 bolts again and
face the panel north.
Page 7
© JVA Technologies www.jva-fence.com JVA WA150
5. If you have a JVA energiser it can be installed between the solar panel
and the pole. There are 2 mounng screws that can be used to hang
the energiser up.
6. If your JVA energiser is ed, plug it into the middle lead (load output)
of the Wi-Fi anywhere. The energiser aligator leads and plug pack will
be unused (le over).
7. Aach the red and black eyelet crimps to the baery. To nd a baery
that will suit you, visit our website: hps://jva-fence.com.au/solar.php
Page 8 © JVA Technologies www.jva-fence.com
8. Alternave wiring:**
Alternavely, the energiser can be connected to the baery directly using
the alligator leads that came with the energiser.
** The Wi-Fi anywhere middle lead (load output) will remain unused.
The plug pack provided with the energiser will also be unused.
Page 9
© JVA Technologies www.jva-fence.com JVA WA150
Overview
Page 10 © JVA Technologies www.jva-fence.com
LED Indicators
D1 (Solar) Solid on when solar panel in sunlight
Blinking when solar panel in low power condions
O when no solar power detected
D6 (USB_5V) Solid on when USB Power is turned on
Ba Level Shows baery level from boom to top: 25% to 100%
Boom LED ashes if baery is disconnected or bad
