JVC CU-VPSD60U Bedienungsanleitung
CU-VPSD60U
PC CARD ADAPTER FOR SD Memory Card and MultiMediaCard
ADAPTATEUR DE CARTE PC POUR
SD Memory Card et
MultiMediaCard
PC-KARTENADAPTER FÜR SD Memory Card und MultiMediaCard
LYT0717-001A
INSTRUCTIONS
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
This manual explains how to use your PC Card Adapter correctly.
Please follow the instructions carefully.
Ce mode d'emploi explique comment utiliser votre PC Card Adapter correctement.
Veuillez suivre soigneusement ces précautions.
Dieses Dokument erklärt den richtigen Gebrauch des PC Card Adapters.
Befolgen Sie bitte sorgfältig die hier gegebenen Anweisungen.
CARD
PC CARD
ATA
MultiMediaCard
ADAPTOR
CU-V50
For Customer Use :
Enter below the Model No. and
Serial No.
Retain this information for future
reference.
Model No.
Serial No.
ENGLISH
FRANÇAIS
DEUTSCH
EN-2
Compliance with the ATA standard for PC cards JVC
PC CARD ADAPTER FOR
SD Memory Card/
MultiMediaCard
CU-VPSD60U
IMPORTANT
Be sure to read the following information before using this product.
nJVC cannot accept liability either for damage due to loss of data
or for direct or indirect damage due to the inappropriate installa-
tion of this product.
nJVC cannot accept liability for damage due either to direct or
indirect damage due to the use or failure of this product.
nIn order to prevent possible accidents, we recommend that the
user back up important data.
n“Microsoft®”, its logo and “MS-DOS” are registered trademarks
of the Microsoft Corporation.
nWindows®is a registered trademark of Microsoft Corporation.
nIBM is a registered trademark of IBM Corporation.
nApple is a registered trademark of Apple Computers Inc.
nMacintosh is a registered trademark of Apple Computers Inc.
nThe company names and brand names mentioned in this manual
aretrademarksorregisteredtrademarksoftheirrespectiveowners.
CHECKING THE PACKAGE CONTENTS
Before using this
product, check that
all items are present
in the package.
Should any item be
missing, please
contact your dealer.
PC Card Adapter for
SD Memory Card/
MultiMediaCard ..... x 1
Storage case ......... x 1
Instructionmanual
x 1
CARD
PC CARD
ATA
MultiMediaCard
ADAPTOR
CU-V50
CARD
PC CARD
ATA
MultiMediaCard
ADAPTOR
CU-V50
ENGLISH
EN-3
CONTENTS
Before Use
SAFETY PRECAUTIONS
1. CHECKING THE OPERATING ENVIRONMENT ....... 8
1-1. Operating Environment ..................................... 8
1-2. Applicable Media ............................................... 8
2. ATTACHING/REMOVING THE MEMORY CARD ....... 9
EQUIPMENT SETUP
3. SETTING UP THE EQUIPMENT .............................. 10
3-1. Running on Windows®95/98/98SE/Me/
2000 Professional ............................................ 10
3-2. Operation with Macintosh................................. 12
TROUBLESHOOTING
4. TROUBLESHOOTING ............................................. 13
5. SPECIFICATIONS ................................................... 14
EN-4
IMPORTANT
Read the following carefully.
The CU-VPSD60U may not work properly on some
models of PC.
Notes on This Owner’s Manual
(1) Unauthorized transfer or duplication of all or any
part of Owner’s Manual is forbidden.
(2) The Owner’s Manual can only be used with one
CU-VPSD60U PC CARD ADAPTER (referred to
hereafter as the CU-VPSD60U).
(3) JVC accepts no liability whatsoever for any loss
incurredby the customer or by any third partywhile
using the CU-VPSD60U with this Owner’s Manual.
(4) Every effort has been made to ensure that this
product is flawless. If any defect is found that is
due to a fault on the part of the manufacturer, the
product will be replaced free of charge. No respon-
sibility is accepted for defects not caused by the
manufacturer.
(5) The contents of this Manual is subject to change
without notice.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme
á la norme NMB-003 du Canada.
US ONLY
ENGLISH
EN-5
●Beforeusingthisproduct,readthisOwner’s Manualcare-
fully, particularly the Safety Notes.
●After reading this manual, keep it handy at all times for
easy reference.
DANGER
Indicates that, if this warning is ignored, improper
handling of the product is likely to result in death or
serious injury.
WARNING
Indicates that, if this warning is ignored, improper
handling of the product may cause death or serious
injury.
CAUTION
Indicates that, if this warning is ignored, improper
handling of the product may cause personal injury or
material damage.
About the Icons
Anumberoficons aredisplayedbothin thisOwner’sManual
and on the product. These icons are intended to facilitate
safe and correct use of the product, to prevent injury to
yourself or anyone else, and to prevent material damage.
These icons and their meanings are explained below.
Ensurethatyoufullyunderstandthesewarnings before you
read this manual.
Safety Notes (to be observed at all times)
EN-6
Specific Exemptions
• JVCacceptsno liability whatsoeverforany injury ordamage
incurred while using this product due to fires, earthquakes,
the actions of third parties, intentional or accidental misuse
by the owner, or any other abnormal circumstance.
• JVC accepts no liability whatsoever for any incidental dam-
age or loss (including lost income, interrupted work,
corruption or loss of stored data, etc.) arising from the use
of this product or the inability to use this product.
• JVCaccepts no liabilitywhatsoever for damage or lossaris-
ingfrom theuse ofthis product in ways not described in this
Owner’s Manual.
• JVCaccepts no liabilitywhatsoever for damage or lossaris-
ing from malfunctions occurring when this device is
connected to any other device.
ENGLISH
EN-7
●Do not attach this product to locations other than a PC
card slot. Otherwise the PC in use may be damaged.
•Beforeattaching this PCcard,make sure that thecard
slotof your PCisdesigned to accommodatePC cards
(PCMCIA) TYPE II or TYPE III.
●If the CU-VPSD60U produces an unusual odor, sound
orsmokeduring use, switchoffyourpersonalcomputer
immediatelyand unplug theplug from thepoweroutlet.
Continuing to use the CU-VPSD60U could result in a
fire or other damage.
Contact your JVC dealer or authorized JVC service
facility to request repairs.
●Do not affix labels or stickers to the outside of the CU-
VPSD60U as these could fall off inside the PC card
slot and damage the slot.
●Do not remove the adapter card, SD Memory Card or
MultiMediaCard while it is being accessed.
Otherwise the stored data may be destroyed or lost.
CAUTION
EN-8
HANDLING PRECAUTIONS
This product incorporates precision electronic parts.
Handle it carefully by using caution in the following points.
n Avoid exposure to a high temperature or to direct sunlight.
nDo not attempt to bend the PC card or subject it to a strong
impact.
n Do not moisten the PC card.
n Do not touch the connector directly by hand, etc.
1. CHECKING THE OPERATING
ENVIRONMENT
The PC card is a card for use in expanding the functionality of a
computer, established based on an international standard devel-
oped jointly by the JEIDA (Japan Electronic Industry Development
Association) and PCMCIA (Personal Computer Memory Card In-
ternational Association). The previous standard corresponding to
the new PC card standard was “PCMCIARel. 2.1/JEIDAVer. 4.2”.
1-1. Operating Environment
1. Apersonal computer which has a TYPE II or TYPE III PC card
slot in compliance with the “PCMCIA Rel. 2.1/JEIDA Ver. 4.2”
and “PC Card Standard”.
2. Windows®95/98/98SE/Me/2000 Professional, or Mac OS 8.5
or a later Operating System.
* For details, consult your dealer or nearest Support Center.
1-2. Applicable Media
See “Applicable Media” in Section 5, “Specifications”.
Use only for compatible OS. Otherwise, files may be destroyed.
Hereafter, the term “Memory Card” will be used to refer to both SD
Memory Cards and MultiMediaCards.
ENGLISH
EN-9
2.
ATTACHING/REMOVINGTHEMEMORYCARD
The illustrations on this page show examples of a notebook PC in use.
Please also refer to the instruction manual of your PC for details.
1Hold the Memory Card with the label
side up and insert it into the slot on
the PC card adapter.
2Insertthe PC cardadapter into thePC
cardslot of aPC or similarequipment.
Attaching the Memory Card
NOTE:
If a PC card adapter without a Memory Card is inserted in a
PC, the PC will not recognize the PC card adapter.
Removing the Memory Card
1Take the PC card adapter out of your
PC.
2Push the eject button on the PC card
adapterandpullout the Memory Card.
NOTE (for Windows®):
Do not insert or eject the Memory Card into or from the PC card
while it is inserted in your PC.
When removing a PC card adapter from a PC, be sure to open
the PC card (PCMCIA) properly. Terminate operation or halt the
use of the PC card and wait until the message “You may safely
remove this device.” before actually removing the PC card.
MultiMediaCard
CU-MMC04U
4MB
CARD
PC CARD
ATA
MultiMediaCard
ADAPTOR
CU-V50
2
1
PC card adapter
Insertion slot
Memory Card
Label
side
PC card slot
Push.
1
3
2
CARD
PC CARD
ATA
MultiMediaCard
ADAPTOR
CU-V50
Eject button
EN-10
3. SETTING UP THE EQUIPMENT
3-1. Running on Windows®95/98/98SE/Me/2000
Professional
v PC card recognition procedure
Windows®95/98/98SE/Me/2000 Professional incorporates a
Socket Service, Card Service and ATA Card Device Driver.
Therefore, the PC card becomes ready for use as soon as it is
inserted in the PC card slot. The procedure is as described in the
following.
1Start Windows®95/98/98SE/Me/
2000 Professional.
2InsertthePC card inthePCcard slot.
3When the [New Hardware Found]
screenappears,select [Windows de-
faultdriver] and click[OK]. Except for
Windows®95,thissetupis performed
automatically.
4WhenthePCrecognizesthePCcard,
it displays the files stored in the PC
card, which now become available.
NOTE:
Thedialogboxshown on the rightmay
not be displayed automatically with
certain PCs. In this case, check My
Computer to see if a new HDD has
been created in it.
