TK-C1480E

1/2" HIGH RESOLUTION COLOUR VIDEO CAMERA

Product Guide

Super LoLux

0.4

lux

TK-C1480Manual.xprNew01.10.295:27PMページ1

New TK-C1480E series

When JVC introduced its TK-1280E series and TK-C1380E series to the 1/2" camera market,

they are widely accepted and recognized as standard-setting cameras.

The new TK-C1480E series, which is to maintain market leadership, adopts newly developed

DSP and CCDs, which feature much higher sensitivity, as well as more functions than its

predecessor, the TK-C1380E series. Added functions include: backlighting and remote

surveillance with RS-422A/RS-485 communications.

Features

Using the 1/2-inch EXVIEW CCD permits sensitivities of 0.8 lux (F 1.2, 50%) and 0.4 lux (F

1.2, 25%). When combined with the slow shutter function, these are increased to 0.025 lux (F

1.2, 50%) and 0.0125 lux (F 1.2, 25%), respectively.

Until now it has been difficult to clearly distinguish between bright and dark subjects in the

same view. With the introduction of JVC’s newly developed DSP this shortcoming no longer

exists, making 24-hour surveillance possible.

For remote camera parameter setting in repeat surveillance communication, RS-422A/

RS-485 standards are provided. An easy-to-use parameter setup menu and high-quality

shooting with no backlight, both of which are popular functions of the TK-C1380E, are also

adopted by the new series.

1/2" IT 440,000-Pixel CCD

Super LoLux

480 TV Lines

S/N 50dB

ExDr (Extended Dynamic Range function)

Motion Detection

RS-422A/RS-485 Communication

Auto Black ON/OFF

Slow Shutter for High Sensitivity

It’s Able to Control by RM-P2580

CONCEPT

TK-C1480Manual.xprNew01.10.295:27PMページ1

Super LoLux Sensitivity

Using a new high-sensitivity CCD

permits Super LoLux photography.

TK-C1380E TK-C1480E

0.95 lux, 25% 0.4 lux, 25%

2.0 lux, 50% 0.8 lux, 50%

0.025 lux (50% at slow shutter x32)

0.0125 lux (25% at slow shutter x32)

Spectral Response

TK-C1380E (Conventional CCD) TK-C1480E (EXVIEW CCD)

Because there is a difference in the spectral response of the CCD between TK-C1380E and TK-C1480E, the

same color reproduction is difficult to obtain. (Of course, we have tried to adjust the color matrix of the

TK-C1480E so that it is as close as possible to that of TK-C1380E.)

DETAILED FEATURES

1.0

0.8

0.6

0.4

0.2

0.0

400 450 500 550 600 650 700

Wave Length (nm)

1.0

0.8

0.6

0.4

0.2

0.0

400 450 500 550 600 650 700

Wave Length (nm)

Relative Response

TK-C1480Manual.xprNew01.10.295:27PMページ2

ExDr

ExDr mode: This is the shutter mode for a subject for which strong light and normal (or low) light conditions

coexist.

The ExDr mode is divided into two further modes:

Manual ExDr mode and Auto ExDr mode.

1Manual ExDr mode:

Selectable high speed shutter

1/500 to 1/20,000

Other Competitors style: Fixed

Variable contrast level

+5 to -5

Minus (-) direction: The iris is set at strong light.

Plus (+) direction: The iris is set at low light.

Other Competitors style: Auto only

2Auto ExDr mode:

The iris at the strong light portion and at the low light portion can be automatically detected and the results are

combined to determine the required shutter speed.

Variable contrast level

+5 to -5

Minus (-) direction: Adjusted for strong light

Plus (+) direction: Adjusted for low light

DETAILED FEATURES

48 area

Auto peak detect →auto shutter

TK-C1480Manual.xprNew01.10.295:27PMページ3

JVC's positioning compared to competing companies

JVC TYPE (ExDr)

EXPANDABILITY SYSTEMS

CCD: SELECT ANY CHIP FROM MARKET

DSP & SOFTWARE: JVC EXCLUSIVE DSP & SOFTWARE

ANY CHIP FROM MARKET

e.g. able to use high

performance CCD like EXVIEW

EXCLUSIVE JVC ORIGINAL

DSP AND SOFTWARE SYSTEMS

OTHER MANUFACTURERS’ TYPE

CLOSED CIRCUIT SYSTEMS

CCD: EXCLUSIVE CCD

DSP & SOFTWARE: EXCLUSIVE DSP & SOFTWARE

EXCLUSIVE CCD

HYPER PROGRESSIVE

EXCLUSIVE DSP

AND SOFTWARE SYSTEMS

TK-C1480Manual.xprNew01.10.295:27PMページ4

DETAILED FEATURES

DIFFERENCE BETWEEN OTHER MANUFACTURER AND JVC TYPE FOR WIDE-DYNAMIC RANGE

HIGH LIGHT

SHUTTER

NORMAL LIHGT

SHUTTER

1. OTHER MANUFACTURER STYLE (PAL)

Normal Shutter Normal Shutter

For WIDE-Dynamic range function

CCD : EXCLUSIVE HYPER PROGESSIVE CCD

DSP : EXCLUSIVE PROCESSING

1/50

(FIX)

1/50

(FIX)

1/50

(FIX)

1/100

(FIX)

1/100

(FIX)

1/100

(FIX)

1/4000

(FIX)

1/4000

(FIX)

1/4000

(FIX)

2. JVC STYLE (PAL)

MERIT : better S/N level

DEMERIT : reduce the sensitity(reduce the graduation)

PAL long shutter : 1/100(FIX)

auto 1/10000

manual 1/20000

MANUAL ADJUST

POSSIBLE !!

MANUAL ADJUST

POSSIBLE !!

MANUAL ADJUST

POSSIBLE !!

x 2times reading x 2times reading x 2times reading

For WIDE-Dynamic range function

CCD : USE ANY CCD FROM MARKET(JVC USES EXVIEW)

DSP : EXCLUSIVE PROCESSING

1/50 1/50 1/501/50

MERIT : keep sensitivity(better graduation)

DEMERIT : AGC changeable based on the condition and if it has high light object,

it has noisy picture(S/N)

mixed picture output

under 1/60 shutter

with Gain control

mixed picture output

under 1/60 shutter

with Gain control

mixed picture output

under 1/60 shutter

with Gain control

A path B path

2 path reading

x2times reading

A path B path

2 path reading

x2times reading

A path B path

2 path reading

x2times reading

1/50 1/50 1/50 1/50

Variable

(Auto &

manual)

Variable

(Auto &

manual)

Variable

(Auto &

manual)

RAM

(MEMORY)

RAM

(MEMORY)

RAM

(MEMORY)

MIXED


OUTPUT

WITH 1/60

SHUTTER

MIXED


OUTPUT

WITH 1/60

SHUTTER

MIXED


OUTPUT

WITH 1/60

SHUTTER

MIXED


OUTPUT

WITH 1/60

SHUTTER

MIXED


OUTPUT

WITH 1/60

SHUTTER

MIXED


OUTPUT

WITH 1/60

SHUTTER

TK-C1480Manual.xprNew01.10.295:27PMページ5

High-speed side shutter operation for ExDr-AUTO

(Note) Slow shutter mode is not available for WD-ON and manual operation.

Auto Exdr, Auto and Normal modes are available for Sense Up operation.

Manual Exdr and Manual modes are not available for Sense Up operation.

SHUTTER LENS

Sees the highest peak on

the divided-by-48 portion.

Adjusts (and sets) the

shutter so that the peak

value may become a

certain level.

Too bright

as a whole

Stops down

the lens

Too dark

as a whole

Opens

the lens

Simultaneous operation

Lowers the high-speed

side shutter speed

(down to 1/100 second)

When the lens is fully

open because the area is

too dark as a whole.

Automatic

If still too dark for a speed

of 1/100 second, then WD

is set to OFF (WD-AUTO).

And at a speed of 1/50

second AGC is turned ON.

(Auto Iris Operation)

TK-C1480Manual.xprNew01.10.295:27PMページ6

Contrast MIX method (or Contrast Mixing)

Level on the Menu shows the value of changing (A).

+5 565mV 80%

+4 540mV 77%

+3 515mV 74%

+2 490mV 70%

+1 465mV 66%

normal 440mV 63%

-1 415mV 59%

-2 390mV 56%

-3 365mV 52%

-4 340mV 49%

-5 315mV 45%

*A place where low brightness is detected

DETAILED FEATURES

200%

100%

Low

brightness

side

(Long

Shutter)

High

brightness

side

(Short

Shutter)

Input

Output

200%

100%

Input

Output

200%

100%

Input

Output

200%

100%

Input

Output

200%

100%

Input

Output

200%

100%

Input

Output

Compression

Compressed

to 1/2

High

Low

High

Low

MIX

This is multiplied

by the gamma and

the knee.

Contrast

level

adjust (or

adj.)

menu on

the Menu

TK-C1480Manual.xprNew01.10.295:27PMページ7

Slow Shutter

Available (selectable) modes are: Off, x2, x4, x8, x16, x24 and x32. The same picture is stored in multiple fields

to obtain increased sensitivity.

In this case a decrease of resolution of 50% results when only even fields are used (odd fields are not used).

P.S. Priority Mode

The slow shutter speed can be used when AGC is ON.

1Motion

AGC is turned ON first, followed by slow shutter-ON.

(Motion picture priority mode)

2Picture

If AGC is turned ON first, noise tends to be introduced.

To prevent noise slow shutter is turned ON prior to turning AGC ON. If, however, the prime requirement is

sensitivity, AGC is turned ON first (with no consideration given to increased noise).

TK-C1480Manual.xprNew01.10.295:27PMページ8

Motion Detect

DETAILED FEATURES

It is possible to set freely the area where MOTION DETECTING functions.

TIMO ON DET ECT

MO E OFFD

LE EL NORMALV

AR A EDI TE

AL RMTI EM10sA

DE ONSTRAT I N

M..

MOTION DETECT screen

flash

lights gray flash

Setting screen

1. Select the item AREA EDIT on

the MOTION DETECT screen.

2. Press the SET button.

The setting screen is brought up.

3. Select the area not subject to

detection using the

button.

The area flashing ON and OFF in black

and white moves.

4. Press the SET button.

The area not subject to detection is set,

and it turns gray (lights up).

To cancel the set area, press the SET

button again.

5. Repeat items 3 and 4 above.

6. Upon completion of setting,

press the MENU button.

The screen returns to the MOTION

DETECT menu.

MEMO

Indicated positions on the screen are rough

guides.

Be sure to check and conform the positions

on the actual screen.

*It is possible to check and confirm the set

areas on the DEMONSTRATION screen.

The detection area is shown in gray.

TK-C1480Manual.xprNew01.10.295:27PMページ9

Inhaltsverzeichnis

Andere JVC Sicherheitskamera Handbücher

JVC

JVC TK-C700U - Color Cctv Camera Bedienungsanleitung

JVC

JVC VN-V686WPU Bedienungsanleitung

JVC

JVC TK-WD310E Bedienungsanleitung

JVC

JVC VN-H657WPBU Bedienungsanleitung

JVC

JVC TK-C676 Bedienungsanleitung

JVC

JVC VN-X235VPU Bedienungsanleitung

JVC

JVC TK-C2201WPU - Analog Mini-dome -- Ip66 Bedienungsanleitung

JVC

JVC TK-AM200U - Active Movement Color Dome... Bedienungsanleitung

JVC

JVC KY-PZ400NWE Bedienungsanleitung

JVC

JVC V.NETWORKS VN-C1U Bedienungsanleitung

JVC

JVC KY-PZ1OOWE Bedienungsanleitung

JVC

JVC VN-H217U Bedienungsanleitung

JVC

JVC SuperLoLux TK-C9200U Bedienungsanleitung

JVC

JVC VN-H657U Bedienungsanleitung

JVC

JVC Super LoLux HD VN-H137U Bedienungsanleitung

JVC

JVC LST0952-001A Bedienungsanleitung

JVC

JVC TK-C205VPU(A) Bedienungsanleitung

JVC

JVC TK-AM200U - Active Movement Color Dome... Bedienungsanleitung

JVC

JVC TK-C1460BE Bedienungsanleitung

JVC

JVC TK-C215V4U - CCTV Camera Bedienungsanleitung

JVC

JVC TK-T2101RE Bedienungsanleitung

JVC

JVC VN-C215VP4U - Fixed Ip Network Mini Dome Bedienungsanleitung

JVC

JVC VN-H657BU Bedienungsanleitung

JVC

JVC TK-C1380U - Color Ccd Camera Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
