K40 CALIBRE Bedienungsanleitung
GROUND
#8 X 1/2" TEK
IGNITION
SWITCHED
+12 VOLTS
BLACK RED
BROWN
BLUE
GRAY
WHITE
GRAY
GRAY
WHITE
BLUE
INTERIOR
NETWORK
MODULE
FRONT
RADAR
LED
REAR
RADAR
LED
(CALIBRE DL
model only)
FRONT LASER DEFUSER REAR LASER DEFUSER
YELLOW*
BROWN*
WHITE
BLACK
SILVER (NOT USED)
COPPER
COPPER
SILVER
CLEAR
ZIP CORD
BLACK
ZIP CORD
BLUE
YELLOW*
BROWN*
BLACK
SILVER (NOT USED)
COPPER
COPPER
SILVER
CLEAR
ZIP CORD
BLACK
ZIP CORD
RECEIVER
CABLE
RECEIVER
CABLE
FUSE
CONNECTION
FUSE
CONNECTION
GROUND
#8 X 1/2" TEK
GROUND
#8 X 1/2" TEK
(OPTIONAL) (OPTIONAL)
1AMP 1AMP
FRONT REAR
+12 VOLT
BATTERY
OR IGNITION
SOURCE
+12 VOLT
BATTERY
OR IGNITION
SOURCE
AMPLIFIED
SPEAKER
BLOCK DIAGRAM
*THE YELLOW AND BROWN
RADAR RECEIVER WIRES
ARE USED TO CONNECT TO
THE OPTIONAL LASER
DEFUSER. IF NO LASER
DEFUSER IS BEING
INSTALLED WITH THE
RADAR RECEIVER (FRONT
AND/OR REAR), THE YEL-
LOW AND BROWN WIRES
WILL NOT BE USED.
CALIBRE
44586-1 4/06
IGNITION AND GROUND
1. Use a test meter to locate an ignition on source for the Interior Network Module with +12 volts when
ignition key is both on and cranking.
2. Connect the black wire to a solid chassis ground using the provided ring terminal and silver self-
tapping screw.
3. Radar receivers may be connected to either a +12 volt ignition on source or +12 volt constant
battery source.
*NOTE: THE RED WIRE
SHOULD BE CONNECTED
TO A MINIMUM 16 GAUGE
+12 VOLT IGNITION WIRE.
GROUND
#8 X 1/2" TEK
IGNITION
SWITCHED
+12 VOLTS
BLACK RED
BROWN
BLUE
GRAY
WHITE
GRAY
GRAY
WHITE
BLUE
INTERIOR
NETWORK
MODULE
FRONT
RADAR
pod
REAR
RADAR
pod
(CALIBRE DL-P
model only)
FRONT LASER DEFUSER REAR LASER DEFUSER
+12 VOLT
BATTERY
OR IGNITION
SOURCE
YELLOW*
BROWN*
WHITE
BLACK
SILVER (NOT USED)
COPPER
COPPER
SILVER
CLEAR
ZIP CORD
BLACK
ZIP CORD
+12 VOLT
BATTERY
OR IGNITION
SOURCE
BLUE
YELLOW*
BROWN*
BLACK
SILVER (NOT USED)
COPPER
COPPER
SILVER
CLEAR
ZIP CORD
BLACK
ZIP CORD
RECEIVER
CABLE
RECEIVER
CABLE
FUSE
CONNECTION
FUSE
CONNECTION
1AMP
GROUND
#8 X 1/2" TEK
GROUND
#8 X 1/2" TEK
(
OPTIONAL
)
(OPTIONAL)
FRONT REAR
1AMP
AMPLIFIED
SPEAKER
BLOCK DIAGRAM
IGNITION AND GROUND
1. Use a test meter to locate an ignition on source for the Interior Network Module with +12 volts when
ignition key is both on and cranking.
2. Connect the black wire to a solid chassis ground using the provided ring terminal and silver self-
tapping screw.
3. Radar receivers may be connected to either a +12 volt ignition on source or +12 volt constant
battery source.
*THE YELLOW AND BROWN
RADAR RECEIVER WIRES
ARE USED TO CONNECT
TO THE OPTIONAL LASER
DEFUSER(S). IF A LASER
DEFUSER IS NOT BEING
INSTALLED WITH A RADAR
RECEIVER (FRONT AND/OR
REAR), THE YELLOW AND
BROWN WIRES WILL NOT
BE USED.
CALIBRE
*NOTE: THE RED WIRE
SHOULD BE CONNECTED
TO A MINIMUM 16 GAUGE
+12 VOLT IGNITION WIRE.
