Kenmore 596.57002600 Bedienungsanleitung

Side-by-Side Refrigerator

Use & Care Guide

Refrigerador de dos puertas

Guía de uso y cuidado, página 37

Réfrigérateur à compartiment juxtaposés

Guide d’utilisation et d’entretien, page 71

Part No. 12842131 Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. www.sears.com

Form No. A/03/06 Sears Canada, Inc., Toronto, Ontario, Canada M5B 2B8 Au Canada, www.sears.ca

Litho U.S.A.

596.57002600 596.57012600 596.57003600 596.57013600

596.57043600 596.57053600 596.57006600 596.57016600

596.57049600 596.57059600 596.57009600 596.57019600

Contents

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Warranty and Protection Agreements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

Location Door and Hinge Removal

Measuring the Opening Replacing the Doors

Transporting Your Refrigerator Handles

Leveling Connecting the Water Supply

Temperature Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-14

Temperature Control

Advanced Temperature Control

Fresh Food Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16

Shelves

Storage Drawers

Freezer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Shelves and Baskets

Door Storage

Ice and Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-20

Automatic Ice Maker Water Dispenser Operation

Dispenser Features Dispenser Control

Water Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Removal and Installation

Food Storage Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-24

Fresh Food Storage

Frozen Food Storage

Food Storage Chart

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-28

Refrigerator Cleaning Chart Replacing Light Bulbs

Removing Odors From Refrigerator Preparing for Vacation

Energy Saving Tips Preparing to Move

Operating Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-33

Guía de uso y cuidado . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Guide d’utilisation et d’entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Important Safety Instructions

WARNING – Hazards or unsafe practices which

COULD result in severe personal injury or death.

WARNING

DANGER – Immediate hazards which WILL result

in severe personal injury or death.

DANGER

CAUTION – Hazards or unsafe practices which COULD

result in minor personal injury or property damage.

CAUTION

What You Need to Know About

Safety Instructions

Warning and Important Safety Instructions appearing in

this guide are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining or operating appliance.

Recognize Safety Symbols, Words,

Labels

Installer: Please leave this guide with this appliance.

Consumer: Please read and keep this Use & Care

Guide for future reference, it provides the proper use

and maintenance information.

In our continuing effort to improve the quality and

performance of our appliances, it may be necessary

to make changes to the appliance without revising

this guide.

This appliance is equipped with a three-prong

grounding plug for your protection against possible

electrical shock hazards. It must be plugged into a

grounding receptacle. Where a standard two-prong

wall receptacle is encountered, it is the personal

responsibility and obligation of the customer to have it

replaced with a properly grounded three-prong wall

receptacle. Do not under any circumstances, cut or

remove the third (ground) prong from the power cord.

Do not use an adapter plug.

Power supply cord with

three-prong grounding plug

Grounding type

wall receptacle

To reduce risk of injury or death, follow basic

precautions, including the following:

Important: Child entrapment and suffocation are

not problems of the past. Junked or abandoned

refrigerators are still dangerous – even if they sit out

for “just a few days.” If you are getting rid of your old

refrigerator, please follow the instructions below to

help prevent accidents.

Before you throw away your old

refrigerator or freezer:

•Take off the doors.

• Leave the shelves in place so

children may not easily climb

inside.

DANGER

To reduce risk of fire, electric shock, serious

injury or death when using your refrigerator,

follow these basic precautions:

1. Read all instructions before using the refrigerator.

2. Observe all local codes and ordinances.

3. Be sure to follow grounding instructions.

4. Check with a qualified electrician if you are not

sure this appliance is properly grounded.

5. Do not ground to a gas line.

6. Do not ground to a cold-water pipe.

7. Refrigerator is designed to operate on a separate

115 volt, 15 amp., 60cycle line.

8. Do not modify plug on power cord. If plug does

not fit electrical outlet, have proper outlet installed

by a qualified electrician.

9. Do not use a two-prong adapter, extension cord

or power strip.

10. Do not remove warning tag from power cord.

11. Do not tamper with refrigerator controls.

12. Do not service or replace any partof refrigerator

unless specifically recommended in Use & Care

Guide or published user-repair instructions. Do

not attempt service if instructions are not

understood or if they are beyond personal skill

level.

13. Always disconnect refrigerator from electrical

supply before attempting any service. Disconnect

power cord by grasping the plug, not the cord.

14. Install refrigerator according to Installation

Instructions. All connections for water, electrical

power and grounding must comply with local

codes and be made by licensed personnel when

required.

15. Keep your refrigerator in good condition. Bumping

or dropping refrigerator can damage refrigerator

or cause refrigerator to malfunction or leak. If

damage occurs, have refrigerator checked by

qualified service technician.

16. Replace worn power cords and/or loose plugs.

17. Always read and follow manufacturer’s storage

and ideal environment instructions for items being

stored in refrigerator.

18. Your refrigerator should not be operated in the

presence of explosive fumes.

19. Children should not climb, hang or stand on any

part of the refrigerator.

20. Clean up spills or water leakage associated with

water installation.

Important Safety Instructions

SAVE THESE INSTRUCTIONS

WARNING

Warranty

Product Record

In the space below record the model and serial

numbers and purchase date of your refrigerator. You

will find the model and serial number sticker inside the

refrigerator section on the left wall.

Model Number: 596. ____________________________

Serial Number: __________________________________

Purchase Date:__________________________________

Keep this booklet and your Sears sales receipt in

asafeplace for future reference.

Reverse Osmosis Water Systems

•Some Reverse Osmosis home water systems cause

low water pressure. Low water pressure can affect

the water and ice dispensing system by causing

small or hollow ice cubes and slow water flow

from the dispenser. Service problems related to the

home’s Reverse Osmosis water system are not

covered by the warranty.

Warranty

One Year Limited Warranty

When installed, operated and maintained according to

all instructions supplied with the product, if this

appliance fails due to a defect in material or

workmanship within one year from the date of

purchase, call 1-800-4-MY-HOME®to arrange for free

repair.

If this appliance is used for other than private family

purposed, this warranty applies for only 90 days from

the date of purchase.

This warranty covers only defects in material and

workmanship. Sears will NOT pay for:

1. Expendable items that can wear out from normal

use, including but not limited to filters, belts, light

bulbs, and bags.

2. A service technician to instruct the user in correct

product installation, operation or maintenance.

3. A service technician to clean or maintain this

product.

4. Damage to or failure of this product if it is not

installed, operated or maintained according to all

instructions supplied with the product.

5. Damage to or failure of this product resulting from

accident, abuse, misuse or use for other than its

intended purpose.

6. Damage to or failure of this product caused by the

use of detergents, cleaners, chemicals or utensils

other than those recommended in all instructions

supplied with the product.

7. Damage to or failure of parts or systems resulting

from unauthorized modifications made to this

product.

Disclaimer of implied warranties; limitation of

remedies

Customer’s sole and exclusive remedy under this

limited warranty shall be product repair as provided

herein. Implied warranteis, including warrantiesof

merchantability or fitness for a particular purpose, are

limited to one year or the shortest period allowed by

law. Sears shall not be liable for incidental or

consequential damages. Some states and provinces do

not allow the exclusion or limitation of incidental or

consequential damages, or limitations on the duration

of implied warranties or merchantability or fitness, so

these exclusions or limitations may not apply to you.

This warranty applies only while this appliance is used

in the United States and Canada.

This warranty gives you specific legal rights, and you

may also have other rights which vary from state to

state.

Sears, Roebuck and Co., Dept. 817WA, Hoffman

Estates, IL 60179

Sears Canada Inc., Toronto, Ontario, Canada

M5B 2B8

In the USA

Master Protection Agreements

Congratulations on making a smart purchase. Your new

Kenmore®product is designed and manufactured for

years of dependable operation. But like all products, it

may require preventive maintenance or repair from

time to time. That’s when having a Master Protection

Agreement can save you money and aggravation.

Purchase a Master Protection Agreement now and

protect yourself from unexpected hassle and expense.

The Master Protection Agreement also helps extend

the life of your new product. Here’s what’s included in

the Agreement:

Expert service by our 12,000 professional repair

specialists

Unlimited service and no charge for parts and

labor on all covered repairs

“No-lemon” guarantee –replacement of your

covered product if four or more product failures

occur within twelve months

Product replacement if your covered product can’t

be fixed

Annual PreventiveMaintenance Check at your

request – no extra charge

Fast help by phone –phone supportfrom a Sears

technician on productsrequiring in-home repair, plus

convenient repair scheduling

Power surge protection against electrical damage

due to power fluctuations

Rental reimbursement if repair of your covered

product takes longer than promised

Once you purchase the Agreement, a simple phone

call is all that it takesfor you to schedule service. You

can call anytime day or night, or schedule a service

appointment online.

Sears has over 12,000 professional repair specialists,

who have access to over 4.5 million quality parts and

accessories. That’s the kind of professionalism you

can count on to help prolong the life of your new

Protection Agreements

purchase for years to come. Purchase your Master

Protection Agreement today!

Some limitations and exclusions apply. For prices

and additional information, call 1-800-827-6655.

Sears Installation Service

For Sears professional installation of home appliances,

garage door openers, water heaters, and other major

home items, in the USA call 1-800-4-MY-HOME®

(1-800-469-4663).

In Canada

Maintenance Agreements

Your purchase has added value because you can

depend on Sears HomeCentral®for service. With over

2,400 Service Technicians and more than a million

parts and accessories, we have the tools, parts,

knowledge and skills to back our pledge: We Service

What We Sell.

Your Kenmore®product is designed, manufactured and

tested to provide years of dependable operation. But

like all products, it may require service from time to

time. The Sears Maintenance Agreement offers you an

outstanding service program, affordably priced.

Sears Maintenance Agreement

• Is your way to buy tomorrow’s service at today’s price

• Eliminates repair bills resulting from normal wear and

tear

• Provides phone support from a Sears technician on

productsrequiring in-home repair

•Even if you don’t need repairs, provides an annual

Preventive Maintenance Check, at your request, to

ensure that your product is in proper running

condition

Some limitations apply. For information about

Sears Canada Maintenance Agreements, call

1-800-361-6665.

Installation

Your refrigerator was packed carefully for shipment.

Remove and discard shelf packaging and tape. Do not

remove the serial plate.

Location

•Do not install refrigerator near oven, radiator or

other heat source. If not possible, shield refrigerator

with cabinet material.

•Do not install where temperature falls below 55° F

(13° C) or rises above 110° F (43° C). Malfunction

may occur at this temperature.

•Refrigerator is designed for indoor household

application only.

Measuring the Opening

When installing your refrigerator, allow 1⁄2”space at top

and 1⁄2”space behind machine compartment cover

(located in the rear) for proper air circulation. If the

refrigerator is placed with the door hinge side against

awall, you may want to allow additional space so the

door can be opened wider.

Subflooring or floor coverings (i.e. carpet, tile, wood

floors, rugs) may make your opening smaller than

anticipated.

Some clearance may be gained by using the leveling

procedure under Leveling, pg. 9.

Important: If refrigerator is to be installed into a

recess where the top of the refrigerator is completely

covered, use dimensions from floor to top of hinge cap

to verify proper clearance.

Transporting Your Refrigerator

•NEVER transport refrigerator on its side. If an

upright position is not possible, lay refrigerator on its

back. Allow refrigerator to sit upright for

approximately 30 minutes before plugging it in to

assure oil returns to the compressor. Plugging

refrigerator in immediately may cause damage to

internal parts.

• Use an appliance dolly when moving refrigerator.

ALWAYS truck refrigerator from its side or

back–NEVER from its front.

• Protect outside finish of refrigerator during transport

by wrapping cabinet in blankets or inserting padding

between the refrigerator and dolly.

• Secure refrigerator to dolly firmly with straps or

bungee cords. Thread straps through handles when

possible. Do not over-tighten. Over-tightening

restraints may dent or damage outside finish.

Installation

To avoid severe personal injury or death,

observe the following:

• Disconnect power to refrigerator before removing

doors. Connect power only after replacing doors.

• Green ground wire must be attached to top hinge

while performing door removal and replacement.

• Tape decorative panels (select models) securely

into place before removing door handles.

WARNING

To avoid property damage, observethe following:

• Protect vinyl or other flooring with cardboard, rugs

or other protective material prior to moving

refrigerator.

CAUTION

Door and Hinge Removal

Some installations require door removal to get

refrigerator to final location.

1. Unplug power cord from power source.

2. Remove toe grille.

• Open both doors 180°,or as wide as possible.

• If tube end is damaged, cut off 5⁄8”before

reconnecting.

• If leaking occurs, disconnect and reconnect the

line.

To Disconnect the Water Line:

•Push in white collar (A) and hold.

•Pull the door-side tube from the connector (B).

To Reconnect the Water Line:

• Firmly push tube 5⁄8”into the connector. Use

lines on the tube as a guide for full insertion.

Note: For refrigerators in operation, shut off water

before removing water line from the door.

6. Detach main wire connector harness and red wire

harness.

•To detach main wire

harness, use a flat blade

tool or fingernail to press

junction point between two

connectors to release.

• To detach red wire harness,

press tab on underside of

connector to release.

7. Remove top hinges along with doors.

8. Remove bottom hinges with a 3⁄8”hex head driver.

3. Close doors.

4. Remove top hinge covers by

removing Phillips screws.

5. Unscrew 5⁄16”hex head screws

from top hinges.

•Do not remove screw

connecting green ground

wire.

Replacing the Doors

To replace the doors, follow the steps in Door and

Hinge Removal in opposite order.

Important: If water line tube end is damaged, cut off

5⁄8”before reconnecting.

Installation

Leveling

To protect personal property and refrigerator

from damage, observe the following:

• Protect vinyl or other flooring with cardboard, rugs,

or other protective material.

•Do not use power tools when performing leveling

procedure.

CAUTION

To enhance the appearance and maintain performance,

the refrigerator should be level.

Materials Needed:

•3⁄8”hex head driver

• Carpenter’s level

1. Remove toe grille.

• Grasp firmly and pull outward

to unclip.

2. Using hex head driver, turn front adjustment

screws (A) clockwise to raise and counterclockwise

to lower the front of the refrigerator.

Notes:

•Complete any required door reversal, panel

installation and/or a water supply connection

before leveling.

•Some models only have adjustment screws (A).

3. Turn both rear adjustment screws (B) clockwise to

raise and counterclockwise to lower the rear of the

refrigerator.

4. Using the carpenter’s level, make sure front of

refrigerator is 1⁄4”(6 mm) or approximately 1⁄2bubble

higher than back of refrigerator and that the

refrigerator is level from side to side.

5. If doors are uneven, do the following:

• Determine which door needs to be raised.

• Turn front roller adjustment screw (A) clockwise

to raise front corner of door.

• If one refrigerator

door has reached

the limit of its

adjustment range

and doors are still

not level, raise or

lower the opposite

door by turning roller

adjustment screw

clockwise or counterclockwise.

• Check with level to verify 1⁄4”tilt to the back for

proper door closure.

• If refrigerator is aligned and stable, replace toe

grille.

• Align the toe grille mounting clips with the lower

cabinet slots.

• Push the toe grille firmly until it snaps into place.

Installation

Connecting the Water Supply

To reduce the risk of injury or death, follow basic

precautions, including the following:

• Read all instructions before installing ice maker.

•Do not attempt installation if instructions are not

understood or if they are beyond personal skill level.

• Observe all local codes and ordinances.

•Do not service ice maker unless specifically

recommended in this Use & Care Guide or

published user-repair instructions.

• Disconnect power to refrigerator before installing

ice maker.

• Water damage due to an improper water

connection may cause mold/mildew growth. Clean

up spills or leakage immediately!

WARNING

To avoid property damage or possible injury,

follow basic precautions, including the

following:

• Consult a plumber to connect 1⁄4”O.D. copper

tubing to household plumbing to assure

compliance with local codes and ordinances.

• Water pressure to water valve must be between 35

and 100 pounds per square inch to function

properly. A minimum pressure of 35 pounds per

square inch is recommended for refrigerators with

water filters.

•Do not use a self-piercing, or 3⁄16”saddle valve.

Both reduce water flow, can become clogged over

time, and may cause leaks if repair is attempted.

• Tighten nuts by hand to prevent cross threading.

Finish tightening nuts with pliers and wrenches. Do

not over-tighten.

• Wait two to three hours before placing refrigerator

into final position to check and correct any water

leaks. Recheck for leaks after 24 hours.

• Verify the copper tubing under the sleeve is smooth

and free from defects. Do not reuse an old sleeve.

CAUTION

Materials Needed:

•1⁄4”outer diameter flexible copper tubing

• Shut-off valve (requires a 1⁄4”hole to be drilled into

water supply line before valve attachment)

•Adjustable wrench (2)

•1⁄4”hex nut driver

• Brass nut and sleeve

Notes:

• Use copper tubing only for installation. Plastic is

less durable and can cause damage.

• Add 8’ to tubing length needed to reach water

supply for creation of service loop.

1. Create service loop with

copper tubing (minimum 2’

diameter). Avoid kinks in the

copper tubing when

bending the service loop. Do

not use plastic tubing.

2. Remove plastic cap from water valve

inlet port.

2’ diameter

minimum

3. Place brass nut (A) and sleeve (B)

on copper tube end as illustrated.

Reminder: Do not use an old

sleeve. The nut and sleeve are

provided in the Use and Care

packet.

5. Slide brass nut over sleeve and

screw nut into inlet port.

Place adjustable wrench on nut

(1) attached to plastic waterline

and maintain position.

Using second adjustable wrench

turn the lower nut (2)

counterclockwise and fully

tighten while holding the upper

nut in place.

Important: Do not over-tighten. Cross threading

may occur.

4. Place end of copper tubing into

water valve inlet port. Shape

tubing slightly. Do not kink – so

that tubing feeds straight into inlet

port.
