15
ENGLISH
FUNCTIONS/VALUES
SENSITIVITY -- High Medium
High
Me-
dium
Low
Low Obstacle detection activated with L=0 and
motor with ENCODER sensor
AUTOMATIC CLOSURE
(seconds) NO 5 10 15 20 25 30 40 80 120
STEP BY STEP COMMAND
P/P
Open
Stop
close
Open
Close
By activating the step/step function, you avoid passage of the automa-
tion in the stop state. The enabled function may be critical for automa-
tions with high inertia.
% DECELERATION NO 10% 20% 30%
When the deceleration function is activated in the
last seconds of operation of the automation, the
control unit slows the motors based on the selected
%.
ELECTROBRAKE NO YES
By activating the electrobraNe function through the F parameter, a
heavy gate is prevented from continuing its movement, due to its iner-
tia, for a few seconds instead of stopping it instantenously following a
command or a safety action
MAXIMUM WORKING TIME
EXTENSION
(expressed in seconds)
90 180 Maximum worNing time extention 90/180 seconds
CONDOMINIUM
(OPEN ONLY) NO YES Activate the condominium function so that the ¿rst step/step impulse
opens and accepts only re-opening during closing
MOTOR FORCE 100%
Max
10%
Min 20% 30% 40% 50% 60% 70% 80% 90%
CLOSE AFTER TRANSIT NO YES
When you activate the Close After Transit function with automatic clo-
sure activated, the automation is closed in the shortest time possible
without waiting for automatic re-closing.
TIMER/MAGNETIC COIL
ON STEP/STEP NO YES
When you activate the function Timer / Magnetic Coil via parameter P
after terminating total opening if step/step contact N.8 is Nept closed
the automatic closing time is locNed so that the gate never closes until
the step/step contact is opened again, if there are several step/step
impulses during the standby time for automatic closing the time will be
continuously reset
SOFT START DELAYED
START TIME NO YES
When you activate the Soft Start function, during the ¿rst seconds of
movement of the automation the control unit Neeps the motor at redu-
ced speed for a softer start.
MOTOR TYPE -- Type 1 Type 2 Select the desired type of slowdown
DEAD MAN NO YES
When you activate the Man Present function via parameter U, you can
open the automation until step/step contact N.8 is closed and close the
automation until contact PED n.7 is closedwhen the two contacts are
released the automation goes to STOP position.
PRE-FLASHING NO 1sec 2sec 4sec
When the pre-Àashing function is activated, before
any movement the Àasher is activated for the
selected time
N.B.:Once the parameters have been displayed, the total manoeuvres counter are shown in two
different screens, where the thousand units are indicated by the lighting up of the point. To reset
this counter, simultaneously press and hold buttons P1 and P2 (ENTER/UP-DOWN) until 0000 is
displayed
N.B. If the point of the LCD on the left lights up, it means that 10,000 manoeuvres have been ex-
ceeded, which must be added to the value shown.
To exit parameter display, press ENTER several times until automatic closure condition is shown
(- - two dashes).
PROGRAMMING FUNCTIONS
Access the parameter menu by holding the ENTER button until the ¿rst parameter, appears. Press
the ENTER button (P2) repeatedly to advance through the parameters menu. To change the pa-
rameter press ĽUP/DOWN (P1)
N.B. any variation in function must be made with the automation closed
