Kia Carens 2016 Bedienungsanleitung

Kia, THE COMPANY

Enjoy your vehicle and Kia’s “Family-like Care” experience!

Thank you for becoming the owner of a new Kia vehicle.

As a global car manufacturer focused on building high-quality, value for

money prices, Kia Motors is dedicated to providing you with a customer

service experience that exceeds your expectations.

At all of our Kia dealerships you will be treated with warmth, hospitality

and professionalism by people who care based on our “Family-like Care”

promise.

All information contained in this Owner’s Manual was accurate at the

time of publication. However, Kia reserves the right to make changes

at any time so that our policy of continual product improvement can be

carried out.

This manual applies to all models of this vehicle and includes descrip-

tions and explanations of optional as well as standard equipment. As a

result, you may encounter material in this manual that is not applicable

to your specific Kia vehicle.

Thank you for choosing a Kia vehicle.

This manual will familiarize you with operational, maintenance and safety information about your new vehicle. It is

supplemented by a Warranty and Maintenance book that provides important information on all warranties regarding

your vehicle. Kia urges you to read these publications carefully and follow the recommendations to help assure

enjoyable and safe operation of your new vehicle.

Kia offers a great variety of options, components and features for its various models. Therefore, some of the equip-

ment described in this manual, along with the various illustrations, may not be applicable to your particular vehicle.

The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the

right to discontinue or change specifications or design at any time without notice and without incurring any obliga-

tion. If you have questions, always check with your authorized Kia dealer.

Kia assures you of our continuing interest in your motoring pleasure and satisfaction in your Kia vehicle.

any information storage and retrieval system or translation in whole or part is not permitted without written author-

ization from Kia MOTORS Corporation.

Printed in Korea

FFoorreewwoorrdd

Introduction

Your vehicle at a glance

Safety features of your vehicle

Features of your vehicle

Driving your vehicle

What to do in an emergency

Maintenance

Specifications & Consumer information

Appendix

Index

table of contents

Introduction

How to use this manual . . . . . . . . . . . . . . . . . . . . . . 1-2

Fuel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

• Gasoline engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

• Diesel engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Vehicle break-in process . . . . . . . . . . . . . . . . . . . . . 1-7

Introduction

We want to help you get the greatest

possible driving pleasure from your

vehicle. Your Owner’s Manual can

assist you in many ways. We strong-

ly recommend that you read the

entire manual. In order to minimize

the chance of death or injury, you

must read the WARNING and CAU-

TION sections in the manual.

Illustrations complement the words

in this manual to best explain how to

enjoy your vehicle. By reading your

manual, you will learn about fea-

tures, important safety information,

and driving tips under various road

conditions.

The general layout of the manual is

provided in the Table of Contents.

Use the index when looking for a

specific area or subject; it has an

alphabetical listing of all information

in your manual.

Chapters: This manual has eight

chapters plus an index. Each chapter

begins with a brief list of contents so

you can tell at a glance if that chap-

ter has the information you want.

You will find various WARNINGS,

CAUTIONS, and NOTICES in this

manual. These were prepared to

enhance your personal safety. You

should carefully read and follow ALL

procedures and recommendations

provided in these WARNINGS, CAU-

TIONS and NOTICES.

✽✽NOTICE

A NOTICE indicates interesting or

helpful information is being provided.

HOW TO USE THIS MANUAL

WARNING

A WARNING indicates a situa-

tion in which harm, serious bod-

ily injury or death could result if

the warning is ignored.

CAUTION

A CAUTION indicates a situation

in which damage to your vehicle

could result if the caution is

ignored.

Introduction

Gasoline engine

Unleaded

For Europe

For the optimal vehicle performance,

we recommend you use unleaded

gasoline which has an octane rating of

RON (Research Octane Number) 95 /

AKI (Anti Knock Index) 91 or higher.

(Do not use methanol blended fuels.)

You may use unleaded gasoline with

an octane rating of RON 91-94 / AKI

87-90 but it may result in slight per-

formance reduction of the vehicle.

Except Europe

Your new vehicle is designed to use

only unleaded fuel having an Octane

Rating of RON (Research Octane

Number) 91 / AKI (Anti-Knock Index)

87 or higher. (Do not use methanol

blended fuels.)

Your new vehicle is designed to

obtain maximum performance with

UNLEADED FUEL, as well as mini-

mize exhaust emissions and spark

plug fouling.

Leaded (if equipped)

For some countries, your vehicle is

designed to use leaded gasoline.

When you are going to use leaded

gasoline, we recommend that you

ask an authorized Kia dealer

whether leaded gasoline in your

vehicle is available or not.

Octane Rating of leaded gasoline is

same with unleaded one.

FUEL REQUIREMENTS

CAUTION

NEVER USE LEADED FUEL. The

use of leaded fuel is detrimental

to the catalytic converter and

will damage the engine control

system’s oxygen sensor and

affect emission control.

Never add any fuel system

cleaning agents to the fuel tank

other than what has been speci-

fied. (We recommend that you

consult an authorized Kia dealer

for details.)

WARNING

• Do not "top off" after the noz-

zle automatically shuts off

when refueling.

• Always check that the fuel cap

is installed securely to pre-

vent fuel spillage in the event

of an accident.

Introduction

Gasoline containing alcohol and

methanol

Gasohol, a mixture of gasoline and

ethanol (also known as grain alco-

hol), and gasoline or gasohol con-

taining methanol (also known as

wood alcohol) are being marketed

along with or instead of leaded or

unleaded gasoline.

Do not use gasohol containing more

than 10% ethanol, and do not use

gasoline or gasohol containing any

methanol. Either of these fuels may

cause drivability problems and dam-

age to the fuel system, engine control

system and emission control system.

Discontinue using gasohol of any

kind if drivability problems occur.

Vehicle damage or driveability prob-

lems may not be covered by the

manufacturer’s warranty if they result

from the use of:

1. Gasohol containing more than

10% ethanol.

2. Gasoline or gasohol containing

methanol.

3. Leaded fuel or leaded gasohol.

Other fuels

Using fuels such as;

- Silicone (Si) contained fuel,

- MMT (Manganese, Mn) contained

fuel,

- Ferrocene (Fe) contained fuel, and

- Other metallic additives contained

fuels,

may cause vehicle and engine dam-

age or cause plugging, misfiring,

poor acceleration, engine stalling,

catalyst melting, abnormal corrosion,

life cycle reduction, etc.

Also, the Malfunction Indicator Lamp

(MIL) may illuminate.

✽✽NOTICE

Damage to the fuel system or per-

formance problem caused by the use

of these fuels may not be covered by

your New Vehicle Limited Warranty.

CAUTION

Never use gasohol which con-

tains methanol. Discontinue use

of any gasohol product which

impairs drivability.

Introduction

Use of MTBE

Kia recommends avoiding fuels con-

taining MTBE (Methyl Tertiary Butyl

Ether) over 15.0% vol. (Oxygen

Content 2.7% weight) in your vehicle.

Fuel containing MTBE over 15.0%

vol. (Oxygen Content 2.7% weight)

may reduce vehicle performance and

produce vapor lock or hard starting.

Do not use methanol

Fuels containing methanol (wood

alcohol) should not be used in your

vehicle. This type of fuel can reduce

vehicle performance and damage

components of the fuel system,

engine control system and emission

control system.

Fuel Additives

Kia recommends that you use

unleaded gasoline which has an

octane rating of RON (Research

Octane Number) 95 / AKI (Anti Knock

Index) 91 or higher (for Europe) or

Octane Rating of RON (Research

Octane Number) 91 / AKI (Anti-Knock

Index) 87 or higher (except Europe).

For customers who do not use good

quality gasolines including fuel addi-

tives regularly, and have problems

starting or the engine does not run

smoothly, one bottle of additives

added to the fuel tank at every

15,000km (for Europe)/ 5,000km

(except Europe). Additives are avail-

able from your authorized Kia dealer

along with information on how to use

them. Do not mix other additives.

CAUTION

Your New Vehicle Limited

Warranty may not cover damage

to the fuel system and any per-

formance problems that are

caused by the use of fuels con-

taining methanol or fuels con-

taining MTBE (Methyl Tertiary

Butyl Ether) over 15.0% vol.

(Oxygen Content 2.7% weight.)

Introduction

Operation in foreign countries

If you are going to drive your vehicle

in another country, be sure to:

• Observe all regulations regarding

registration and insurance.

• Determine that acceptable fuel is

available.

Diesel engine

Diesel fuel

Diesel engine must be operated only

on commercially available diesel fuel

that complies with EN 590 or compa-

rable standard. (EN stands for

"European Norm"). Do not use

marine diesel fuel, heating oils, or

non-approved fuel additives, as this

will increase wear and cause dam-

age to the engine and fuel system.

The use of non-approved fuels and /

or fuel additives will result in a limita-

tion of your warranty rights.

Diesel fuel of above cetane 51 is

used in your vehicle. If two types of

diesel fuel are available, use summer

or winter fuel properly according to

the following temperature conditions.

• Above -5°C (23°F) ... Summer type

diesel fuel.

• Below -5°C (23°F) ... Winter type

diesel fuel.

Watch the fuel level in the tank very

carefully : If the engine stops through

fuel failure, the circuits must be com-

pletely purged to permit restarting.

CAUTION

Do not let any gasoline or water

enter the tank. This would make

it necessary to drain it out and

to bleed the lines to avoid jam-

ming the injection pump and

damaging the engine.

CAUTION - Diesel Fuel

(if equipped with DPF)

It is recommended to use the

regulated automotive diesel fuel

for diesel vehicle equipped with

the DPF system.

If you use diesel fuel including

high sulfur (more than 50 ppm

sulfur) and unspecified addi-

tives, it can cause the DPF sys-

tem to be damaged and white

smoke can be emitted.

Introduction

Biodiesel

Commercially supplied Diesel blends

of no more than 7% biodiesel, com-

monly known as "B7 Diesel" may be

used in your vehicle if Biodiesel meets

EN 14214 or equivalent specifications.

(EN stands for "European Norm"). The

use of biofuels exceeding 7% made

from rapeseed methyl ester (RME),

fatty acid methyl ester (FAME), veg-

etable oil methyl ester (VME) etc. or

mixing diesel exceeding 7% with

biodiesel will cause increased wear or

damage to the engine and fuel sys-

tem. Repair or replacement of worn or

damaged components due to the use

of non approved fuels will not be cov-

ered by the manufactures warranty.

No special break-in period is needed.

By following a few simple precautions

for the first 1,000 km (600 miles) you

may add to the performance, econo-

my and life of your vehicle.

• Do not race the engine.

• While driving, keep your engine

speed (rpm, or revolutions per

minute) between 2,000 rpm and

4,000 rpm.

• Do not maintain a single speed for

long periods of time, either fast or

slow. Varying engine speed is need-

ed to properly break-in the engine.

• Avoid hard stops, except in emer-

gencies, to allow the brakes to seat

properly.

• Don't tow a trailer during the first

2,000 km (1,200 miles) of operation.

CAUTION

• Never use any fuel, whether

diesel, B7 biodiesel or other-

wise, that fails to meet the lat-

est petroleum industry speci-

fication.

• Never use any fuel additives

or treatments that are not rec-

ommended or approved by the

vehicle manufacturer.

VEHICLE BREAK-IN

PROCESS

Inhaltsverzeichnis

Andere Kia Automobil Handbücher

Kia

Kia FORTE 2022 Bedienungsanleitung

Kia

Kia Soul 2020 Montageanleitung

Kia

Kia Picanto 2016 Bedienungsanleitung

Kia

Kia Magentis 2002 Bedienungsanleitung

Kia

Kia Automobile Bedienungsanleitung

Kia

Kia Optima hybrid 2012 Kurzanleitung zur Einrichtung

Kia

Kia 2014 rondo Bedienungsanleitung

Kia

Kia Sorento Stücklistenhandbuch

Kia

Kia Soul 2009 Bedienungsanleitung

Kia

Kia 2012 Sorento Stücklistenhandbuch

Kia

Kia Cerato 2022 Bedienungsanleitung

Kia

Kia 2014 Sportage Bedienungsanleitung

Kia

Kia RIO Bedienungsanleitung

Kia

Kia Optima Stücklistenhandbuch

Kia

Kia Sorento 2021 Bedienungsanleitung

Kia

Kia Cerato 2021 Bedienungsanleitung

Kia

Kia VISTO Bedienungsanleitung

Kia

Kia 2020 Telluride Montageanleitung

Kia

Kia 2013 Cerato Bedienungsanleitung

Kia

Kia 2014 rondo Betriebsanleitung

Kia

Kia Soul 2011 Bedienungsanleitung

Kia

Kia Carnival 2009 Konfigurationshandbuch

Kia

Kia stinger 2021 Stücklistenhandbuch

Kia

Kia Ceed 2017 Bedienungsanleitung

Beliebte Automobil Handbücher anderer Marken

Toyota

Toyota 2000 Tundra Bedienungsanleitung

CITROËN

CITROËN DS4 DSign Bedienungsanleitung

Lexus

Lexus 2015 CT 200h Bedienungsanleitung

Cadillac

Cadillac CTS 2008 Bedienungsanleitung

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Bedienungsanleitung

Porsche

Porsche Boxster S Bedienungsanleitung

GMC

GMC 2010 Savana 1500 Cargo Bedienungsanleitung

KIAM

KIAM SPORTAGE 2014 Stücklistenhandbuch

GMC

GMC 2013 Terrain Montageanleitung

GMC

GMC T-Series 1999 Bedienungsanleitung

Mercury

Mercury 1998 Mystique Bedienungsanleitung

Mercury

Mercury 2007 Mariner Bedienungsanleitung

Mazda

Mazda 2007 Mazdaspeed 3 Leitfaden

Mazda

Mazda 2014 CX-5 Bedienungsanleitung

GMC

GMC Chevrolet Express 2022 Bedienungsanleitung

GMC

GMC 1997 Jimmy Bedienungsanleitung

Chevrolet

Chevrolet 2012 Malibu Bedienungsanleitung

Cadillac

Cadillac 2010 Escalade Bedienungsanleitung
