2 BRIGGSandSTRATTON.com.au
Equipment Description
Table of Contents
Equipment Description .........................2
Features and Controls .........................4
Operation....................................6
Maintenance ................................13
Storage ....................................15
Troubleshooting/Specifications .................16
Warranty ...................................20
Symbols and Meanings
Signal Meaning
DANGER Indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING Indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a hazard which, if not avoided,
could result in minor or moderate injury.
NOTICE Indicates information considered important,
but not hazard-related
Symbol Name Explanation
Safety Alert
Symbol
Indicates a potential personal injury
hazard.
Operator’s
Manual
Failure to follow warnings,
instructions and operator’s manual
could result in death or serious
injury.
Toxic Fumes
Engine exhaust contains carbon
monoxide, a poisonous gas that
could kill you in minutes. You
cannot smell it or see it.
Fire
Fuel and its vapors are extremely
flammable which could cause
burns or fire resulting in death or
serious injury.
Engine exhaust could cause fire
resulting in death or serious injury.
Electric
Shock
Generator could cause electrical
shock resulting in death or serious
injury.
Hot Surface Muffler could cause burns or
resulting in serious injury.
Equipment Description
Read this manual carefully and become familiar
with your product. Know its applications, its
limitations, and any hazards involved. Save these
original instructions for future reference.
The inverter generator is an engine–driven, revolving
field, alternating and direct current (AC & DC) generator.
It was designed to supply electrical power for operating
compatible electrical lighting, appliances, tools and
motor loads. The generator’s revolving field is driven
at about 4,350 rpm (with QPT™ (QUIET POWER
TECHNOLOGY™) switch off) by a single-cylinder engine.
The inverter generator produces power that can be used for
outdoor items using extension cords or an optional parallel
kit. This inverter generator is not intended to restore power to
a home.
Extension cords running directly into the home
increase your risk of carbon monoxide poisoning through
openings. Install carbon monoxide alarm(s).
Every effort has been made to ensure that the information in this
manual is both accurate and current. However, the manufacturer
reserves the right to change, alter or otherwise improve the
generator and this documentation at any time without prior notice.
NOTICE If you have questions about intended use, contact an
authorized service dealer. This equipment is designed to be used
with Briggs & Stratton authorized parts only.
System Ground
The generator has a system ground that connects the
generator frame components to the ground terminals on the
AC output receptacles. The generator neutral is floating,
which means that the AC stator winding is isolated from
the grounding fastener and the AC receptacle ground pins.
Electrical devices, such as RCD, requiring a grounded
neutral may not operate properly from this generator.
Earthing of the generator is not required.
Special Requirements
There may be regulations, local codes, or ordinances that
apply to the intended use of the generator. Please consult
a qualified electrician, electrical inspector, or the local
agency having jurisdiction.
This generator is not intended to be used at a construction
site.
