Ver: 1.0

DVD Duplicator

User’s Guide

DVD Duplicator Series

Ver: 1.0 Page - 1 of 34 User’s Guide

This optical duplication device is to be used exclusively for the purpose of copying personal

audio and data. This optical duplication device is sold and intended strictly for the purposes of

legal copying. It is a violation of International Copyright Laws to use for any other purpose and

subject to criminal charges. Kingdom is not responsible for any illegal use or any damages

resulting from the sale, use, or performance of this device.

Safety Precautions

Duplicator products are high-precision electronic devices. Do not use them in any manner

other than as specified in this manual. Please read this manual in its entirety before using the

system.

To prevent fire or shock, do not expose the unit to moisture or rain.

To prevent electronic shock, do not attempt to disassemble the duplicator or any of its internal

components. Refer servicing to authorized personnel.

The internal drives utilize a laser beam that can be harmful to the eyes. Do not disassemble

the unit. Do not attempt to look through the front panel or into the unit while the power is turned

on.

A user who changes or modifies the unit or operation procedures specification herein without

express written approval by the manufacturer will void manufacturer’s warranty.

Specifications and features are subject to change without notice or obligation.

Attention:

You should wait 10 seconds to power on after shutdown to prevent the abnormal

operation of system.

DVD Duplicator Series

Ver: 1.0 Page - 2 of 34 User’s Guide

TABLE OF CONTENTS

SAFETY PRECAUTIONS ......................................................................................................... 1

CHAPTER 1 INTRODUCTION................................................................................................. 4

INTRODUCING THE DVD DUPLICATOR SYSTEMS......................................................................... 4

FEATURES ............................................................................................................................... 4

SYSTEM SPECIFICATION ........................................................................................................... 4

UNPACKING YOUR NEW DUPLICATOR ........................................................................................ 5

CLEANING AND MAINTENANCE .................................................................................................. 6

FOR BEST PERFORMANCE........................................................................................................ 6

WARRANTY INFORMATION......................................................................................................... 6

TECHNICAL SUPPORT ............................................................................................................... 7

CHAPTER 2 GETTING STARTED .......................................................................................... 8

TURNING ON THE SYSTEM......................................................................................................... 8

ABOUT THE LCD PANEL DISPLAY .............................................................................................. 8

CHAPTER 3 SIMPLE BASICS ................................................................................................ 9

OVERVIEW ............................................................................................................................... 9

COPYING A MASTER DVD......................................................................................................... 9

LOADING A DVD ONTO THE HARD DRIVE ................................................................................. 10

COPYING FROM A PARTITION ON THE HARD DRIVE.................................................................... 12

SELECTING THE SOURCE TO COPY FROM (DVD-RW OR HARD DRIVE) ..................................... 14

SELECTING A SPECIFIC HARD DRIVE PARTITION AS THE SOURCE .............................................. 16

CHAPTER 4 ADVANCED FUNCTIONS ................................................................................ 18

TESTING (SIMULATING)THE COPY PROCESS ........................................................................... 18

TESTING AND COPYING DVDS................................................................................................ 18

VERIFYING THE TARGET (DUPLICATE)DVDS............................................................................ 18

COMPARING THE SOURCE AND TARGET AFTER COPYING .......................................................... 19

PRESCANNING THE MASTER (SOURCE)DVD........................................................................... 19

VIEWING THE DISC INFO OF THE MASTER (SOURCE)DVD........................................................ 20

SELECT SOURCE.................................................................................................................... 20

CHAPTER 5 USING THE HARD DRIVE PARTITION AS THE SOURCE ............................ 21

OVERVIEW ............................................................................................................................. 21

LOADING A DVD (IMAGE)INTO A PARTITION OF THE HARD DRIVE .............................................. 22

DELETE THE CONTENTS OF A HARD DRIVE PARTITION .............................................................. 22

REVIEW THE CONTENTS OF A PARTITION.................................................................................. 22

COMPARE THE PARTITION TO THE DVD.................................................................................... 23

DVD Duplicator Series

Ver: 1.0 Page - 3 of 34 User’s Guide

SELECTING A HARD DRIVE PARTITION...................................................................................... 23

SELECTING THE IMAGE SOURCE DRIVE ................................................................................... 23

CHAPTER 6 EDITING TRACKS WHEN USING CDS (FOR CD ONLY) .............................. 24

OVERVIEW ............................................................................................................................. 24

COPYING TRACKS,MASTER CD TO TARGET CD ...................................................................... 24

PLAYING AN AUDIO TRACK ...................................................................................................... 24

CLOSING A SESSION............................................................................................................... 25

CHAPTER 7 ABOUT THE SETUP OPTIONS ....................................................................... 26

OVERVIEW ............................................................................................................................. 26

LANGUAGE............................................................................................................................. 26

CD BURN SPEED ................................................................................................................... 26

DVD BURN SPEED................................................................................................................. 26

READ SPEED ......................................................................................................................... 26

AUTO START DRIVE ................................................................................................................ 26

STARTUP MENU ..................................................................................................................... 26

AUTO VERIFY......................................................................................................................... 26

AUTO COMPARE..................................................................................................................... 26

AUTO PRESCAN ..................................................................................................................... 26

EJECT DISC ........................................................................................................................... 26

BURN ON THE FLY.................................................................................................................. 27

BURN MODE .......................................................................................................................... 27

DISPLAY TIME ........................................................................................................................ 27

BUTTON SOUND ..................................................................................................................... 27

DEVICE INFO.......................................................................................................................... 27

SYSTEM INFO......................................................................................................................... 27

QUICK ERASE ........................................................................................................................ 27

FULL ERASE........................................................................................................................... 27

AUTO CLOSE TRAY................................................................................................................. 27

QUICK COMPARE.................................................................................................................... 27

AUDIO BURN SPEED............................................................................................................... 27

CHAPTER 8 TROUBLESHOOTING...................................................................................... 28

APPENDIX 1: OVERVIEW OF THE FUNCTIONS ................................................................ 29

APPENDIX 2: LCD MESSAGES ........................................................................................... 31

GENERAL MESSAGES: ............................................................................................................ 31

HARD DISK DRIVE WITH IMAGE LOADING MESSAGES:............................................................... 31

FIRMWARE UPDATE MESSAGES: ............................................................................................. 32

APPENDIX 3 TECHNICAL SUPPORT INFORMATION........................................................ 34

DVD Duplicator Series

Ver: 1.0 Page - 4 of 34 User’s Guide

Chapter 1 Introduction

Introducing the DVD Duplicator Systems

This Kingdom One touch™ is a high speed, multi copy DVD Recordable duplication

system, enabling you to copy DVDs up to 16X speed. It provides efficient duplication of

compact disk with excellent accuracy. With its professional design and multi-function

LCD panel, the unit is particularly easy to operate.

If your system includes a hard drive, you can load an original DVD onto the hard drive

and use all of the available DVD-RW drives to duplicate multiple DVDs all at once. The

hard drive has partitions of five gigabytes each. You can load up to 1 DVD in each

partition on the hard drive and duplicate from one partition at a time. You can also use

each partition in the hard drive to load selected tracks from any number of DVDs and

then duplicate the loaded tracks to multiple DVDs.

If your system does not include a hard drive, you can use the first DVD drive as the

reader, and the remaining drives for duplication.

Features

•Stand alone IDE to IDE DVD controller

•Self system diagnostics when power is turned on

•Easy to use, informative LCD command display

•Auto format detection

•Supports high speed 16X DVD recording speed

•Supports Hard Drive images

•Industrial cooling fans and Heavy Duty power supply

•Firmware upgrade via DVD-RW

System Specification

Power: 115/230 VAC 0.5 Amp 400W 50/60 Hz

Write Speeds: CD Write Speeds: 48x,40x (CAV/Z-CLV), 32x,24x

(P-CAV/Z-CLV), 16x,8x (CLV), CD Rewrite Speeds 24x (Z-CLV),

16x,10x,4x (CLV), DVD+R Write Speeds 16x,13x (CAV),

12x,8x,6x (Z-CLV), 4x,2.4x (CLV), DVD+RW Write Speeds 8x

(Z-CLV), 6x 4x,2.4x (CLV), DVD-R Write Speeds 16x,13x (CAV),

12x,8x,6x (Z-CLV), 4x,2x (CLV), DVD-RW Write Speeds 6x

(Z-CLV), 4x,2x,1x (CLV), DVD+R DL Write Speeds 4x,2.4x

DVD Duplicator Series

Ver: 1.0 Page - 5 of 34 User’s Guide

(CLV), DVD-R DL Write Speeds 4x, 2x (CLV).

Read Speeds: CD Read Speeds 48x Max (CD-ROM/CD-R), 32x Max (CD-RW),

DAE Speeds 32x Max DVD Read Speeds 16x Max (DVD-ROM

Single Layer), 7 Max (DVD-ROM Dual Layer), 16x Max (DVD±R),

8x Max (DVD±RW), 5x Max (DVD+R DL), 5x Max (DVD-Video).

Formats: Support for multiple formats Including CD Formats: CD-ROM,

CD-ROM/XA, CD-R, CD-RW, Photo CD, Video CD, CD-Extra,

CD-I, CD-Bridge, Hybrid-CD, CD-Text.

DVD Formats: DVD-ROM, DVD-R/RW, DVD+R/RW, DVD+R DL,

DVD-R DL.

Unpacking Your New Duplicator

Unpack the system in a clean working area with a moderate temperature control.

Confirm that the following items have been shipped with the system: power cable, user

manual.

Confirm that the voltage setting (AC 115/230V) is correct.

Confirm that the power input is stable and consistent. Install an uninterruptible power

supply (UPS) if necessary.

Make sure that the system is on a level and stable surface away from direct sunlight and

free from any vibration.

Make sure that the environment for the system is properly ventilated and free of dust,

excessive heat and humidity and electronic interference.

Make sure the system is properly grounded. Do not attempt to defeat the third ground

prong on the power cable.

The system is shipped in professionally designed, form-based packaging. If your

system is damaged during shipment, please contact the freight carrier first, and then

contact your Kingdom dealer.

IMPORTANT: Please keep and store this packaging for future transport or

storage of the system. If your system ever needs to be sent in for service, it must

be returned in the original packing or the warranty will be voided.

DVD Duplicator Series

Ver: 1.0 Page - 6 of 34 User’s Guide

Cleaning and Maintenance

The best maintenance for your system is preventive maintenance. Using a system in an

area with excessive dust, smoke or other contaminants is not recommended because it

will increase error rates and reduce hardware life expectancy. Some light exterior

cleaning can be performed, but there is no substitute for a clean environment.

For Best Performance

For best results always use high quality media. Kingdom One touch™ duplicators

have been thoroughly tested with most major optical media makers for

maximum compatibility. Kingdom Platinum media is our first recommendation

for excellent results. Please visit us at www.kingdom.com.

Warranty Information

Kingdom, Inc. warrants to the original purchaser that this product is free from defects in

material and workmanship. Kingdom, Inc. will for one year, at its option, repair or

replace at no charge for parts and labor from the date you purchase the product from

Kingdom, Inc. Kingdom, Inc. reserves the right to determine the validity of all warranty

claims. Warranty is void if the product serial number has been altered or removed.

Warranty is void if the product has been misused or damaged or if evidence is present

that the product was altered, modified or serviced by unauthorized service people.

THE ABOVE STATED WARRANTY IS EXCLUSIVE AND REPLACES ALL OTHER

WARRANTIES EXPRESSED OR IMPLIED INCLUDING THOSE OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KINGDOM INC.

WILL NOT BE HELD LIABLE FOR ANY OTHER DAMAGES OR LOSS INCLUDING

INCIDENTIAL OR CONSEQUENTIAL DAMAGES AND LOSS OF PROFITS OR

REVENUES FROM WHATEVER CAUSE, INCLUDING BREACH OF WARRANTY OR

NEGLIGENCE.

KINGDOM INC. RESERVES THE RIGHT TO MODIFY OR UPDATE ITS PRODUCT

OBLIGATION TO REPLACE ANY EQUIPMENT DELIVERED PRIOR TO ANY SUCH

CHANGE.

DVD Duplicator Series

Ver: 1.0 Page - 7 of 34 User’s Guide

Technical Support

For detailed technical support or questions regarding the DVD Duplicator, contact Kingdom

Technical Support at 1-800-296-2312.

Note: This duplicator has a serial number located on the rear panel. Please record the Model

Number and Serial Number and retain them for your records. It will be necessary to provide

this information to Technical Support personnel in order for them to provide you with the best

technical support possible.

Model Number: _____________________________________

Serial Number: _____________________________________

DVD Duplicator Series

Ver: 1.0 Page - 8 of 34 User’s Guide

Chapter 2 Getting Started

Turning on the System

Plug the AC cord into the system and then into a wall outlet. NOTE: Make sure that the

voltage setting is correct (115v or 230v). Switch the ON/OFF rocker-switch located on the

back of the system (below the power outlet). The LCD display will light up, indicator lights

on each of the DVD disc drives will flash momentarily and the system will go through a

short self test routine.

About the LCD Panel Display

When you first turn the system on, after a short self test routine the information

displayed in the LCD panel will indicate the copy function is selected:

Press the down arrow button to scroll through the functions that are available in the

system. They appear in the following order:

1. Copy

2. Test

3. Test & Copy

4. Verify

5. Compare

6. Prescan

7. Disc Info

8. Select Source

9. Image (When a hard drive is installed in the duplicator)

10. Edit Track

11. Setup

Press the up arrow button to scroll through the functions in the opposite order.

Pressing the ENT (Enter) button starts the function that you have selected.

Press the ESC (Escape) button stops/cancels any function that you have started or

selected.

DVD Duplicator Series

Ver: 1.0 Page - 9 of 34 User’s Guide

Chapter 3 Simple Basics

Overview

This chapter covers procedures for the most frequently used functions of the DVD

Duplicator, which are as follows:

•Duplicating (Copying) a DVD

•Copying a DVD to the Hard Drive

•Duplicating from the Hard Drive

•Copying Selected Tracks to the Hard Drive

•Burning Composite DVDs from a Hard Drive Partition

•Selecting or Changing the Source (Master DVD or Hard Drive)

•Selecting a Specific Hard Drive Partition as the Source

Copying a Master DVD

Duplicating (Copying) from DVD to DVD is the most frequently used function of the system.

This procedure provides step-by-step instructions for making duplicates from a Master DVD.

1. Turn on the system. Note that the 1.Copy command is displayed. Your LCD display should

look like this:

2. Place the Master DVD in the top drive. This is the drive that functions as Master or “source”

drive.

3. Place one or more blank DVDs in the remaining drives. It doesn’t matter which drive(s) you

use; the system will automatically detect which slave or “destination” drives have blank

discs in them ready to be copied to.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere KINGDOM Disc-Duplikator Handbücher

KINGDOM

KINGDOM One touch Bedienungsanleitung

Beliebte Disc-Duplikator Handbücher anderer Marken

Riso

Riso CV Series Handbuch

MicroBoards Technology

MicroBoards Technology GX-2 Bedienungsanleitung

Addonics Technologies

Addonics Technologies HDUS325DX Bedienungsanleitung

Carry

Carry Pro118 Bedienungsanleitung

CopyPro

CopyPro PowerPro II Bedienungsanleitung

Primera

Primera Max Bedienungsanleitung

Logicube

Logicube EchoPlus-NG Bedienungsanleitung

Silca

Silca Delta 2000 SA Bedienungsanleitung

Reflex7

Reflex7 Daisy Chain Series Bedienungsanleitung

Vinpower Digital

Vinpower Digital SharkCopier DC Bedienungsanleitung

Codonics

Codonics Virtua E Bedienungsanleitung

Octave

Octave Copy Master II Bedienungsanleitung

Kanguru

Kanguru U2-DVDDUPE-S Bedienungsanleitung

StarTech.com

StarTech.com 8STSATDUP11 Bedienungsanleitung

DUPLO SEIKO CORPORATION

DUPLO SEIKO CORPORATION Duprinter DP-460 Bedienungsanleitung

Addonics Technologies

Addonics Technologies UDFH7 Bedienungsanleitung

Vinpower Digital

Vinpower Digital MiniLoader VDX-1 Bedienungsanleitung

Addonics Technologies

Addonics Technologies CFASTD5 Bedienungsanleitung
