Kitchen Monkey KMSG-811 Bedienungsanleitung
KMSG-811,KMSG-811/F, KMSG-811E
KMSG-811E/F, KMSG-813
Panini/Sandwich Grills
This manual contains important information regarding your
KM Kitchen Monkey unit. Please read this manual thoroughly prior to
equipment set-up, operation and maintenance. Failure to comply
with regular maintenance guidelines outlined in this manual may
void the warranty. PLEASE READ!
handle
WARNINGS
•Do not touch any hot surfaces
•Do not immerse unit, cord or plug in liquid at any time
•Unplug cord from outlet when not in use and before cleaning
•Plug only into a 3-hole grounded electrical outlet
•Do not operate unattended
•Do not use this unit for anything other than intended use
•Do not use outdoors
•Keep children and animals away from unit
•Always cook on a firm, dry and level surface at least 12” from walls or any other obstruction
•Do not use unit with a damaged cord or plug, in the event the appliance malfunctions, or has been damaged in any
manner
•Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to property loss and injury.
All repairs should be done by authorized professionals only
•Ensure that the power supply you are using is adequate for continual grill usage and the voltage is correct.
•Do not jam materials or place heavy objects on grill, as this may cause damage.
In order to protect the plates of your new grill during transportation, a layer of food-
safe wax was coated on the surface prior to shipment. This wax is harmless, but must
be removed before you begin to use. To remove, preheat the grill until the wax
liquefies. Next, carefully wipe away the melted wax with a clean, soft cloth. Once all
of the wax is removed you can begin to use your grill.
TO USE
1. Plug the power cord into the appropriately rated outlet.
2. The power light will illuminate.
3. Once desired temperature is set, the Heating Indicator will come on. Warm-up time is approximately 7-8 minutes. The
Heating indicator will cycle at set temperature.
4. For normal use, it is recommended that the temperature range be 392℉-482℉.
5. When the surface reaches the designated temperature, lift top grill using black handle and lightly grease grill plates
with vegetable oil. Place food on grill and lightly press handle down. Excess oil will collect in the oil collection tray.
Remove food when cooked. The heaters will automatically cycle as needed.
CLEANING – NOTE: To maintain cleanliness and increase service life, the grills should be cleaned daily. Do not immerse
the grill in water or any other liquid.
1. Before cleaning or attempting to move grill, unplug and let the unit cool completely.
2. Wipe the entire unit with a clean soft cloth until it is completely dry.
3. To avoid damage, do not use abrasive cleaners or scouring pads.
4. If soap or chemical cleaners are used, be sure they are completely rinsed away with clear water immediately
after cleaning. Chemical residue could damage or corrode the surfaces of the unit.
5. Store in a dry clean area when not in use.
TROUBLESHOOTING
Problem Possible Causes Action
1. Grill plates do not heat
even though power
indicators are lit.
1. Defective
controller.
2. Defective heater(s).
1. Replace controller 2.
Replace heater(s).
2. Temperature cannot be
controlled.
1. Defective
temperature
controller.
1. Replace temperature
controller
3. Heating indicator
appears normal, but power
indicators are not lit.
1. Defective power
indicator(s)
1. Replace power
indicator(s)
Grill KMSG-811EB
Circuit diagram
Grill KMSG-811B
Circuit diagram
Grill KMSG-813B
Circuit diagram
SG-811E
SG-811
SG-811E
VER811
SG-813
VER811VER811
Sandwich Grills - KMSG-811, KMSG-811/F, KMSG-811E, KMSG-811E/F, KMSG-813
Reference
Number
KMSG-811/F and
KMSG-811
Part Number
KMSG-811E/F and
KMSG-811E Part Number
KMSG-813
Part Number Description
1 DF6SG-1 DF6SG-1 DF6SG-1 Heat Indicator - Orange
2TH-1201 TH-1201 TH-1201 Thermostat Regulator
3 DF6SG-3 DF6SG-3 DF6SG-3 Power Indicator - Green
4Body
5 SG-5 SG-5 SG-5 Torsional Spring w/Screws
6 SG-6 SG1E-6 SG-6 Back Axis
7 SG-7 SG-7 SG-7 Adjustbale Tension Base w/Screw
8SG1-8 SG1E-8 SG3-8 Axis Cover
9 SG-9 SG-9 SG-9 Axis Holding Pin
10 SG-10 SG-10 SG-10 Power Supply Cord
11 Bottom Plate - Cast Iron
12 Top Plate Cover w/ Screws
13 Upper Mounting Plate
14 Top Plate - Cast Iron
15 SG-15 SG1E-15 SG-15 Upper Heating Element
16 SG-16 SG-16 SG-16 Wire Tube
17 SG-17 SG1E-17 SG-17 Upper Axis w/Clips
19 SG-19 SG1E-19 SG-19 Handle Frame with Grip
20 SG1-20 SG1E-20 SG3-20 Oil Collector
21 Lower Mounting Plate
22 SG-22 SG-22 SG-22 Rubber Foot
23 Element Plate
24 SG-24 SG1E-24 SG-24 Bottom Heating Element
25 Bottom Cover w/Screws
26 SG-26 SG-26 SG-26 Thermostat Knob
27 SG-27 SG-27 SG-27 Screw for Back Axis/Handle
