KitchenAid 5KFP0719A Bedienungsanleitung

5KFP0719A

W11279640B.indd 1 10/18/2018 2:23:02 PM

2 | PARTS AND FEATURES

PARTS AND FEATURES

PARTS AND ACCESSORIES

Heavy-duty

base

Power cord and

cord storage

(not shown)

Lid latch

Drive pin

Lid hinge

Handle hinge

Reversible

slicing/shredding

disc

Drive adapter Multipurpose

stainless steel

blade

Work bowl

cover with

2-in-1 feed

tube

2-piece

food pusher

1.7 L (7-cup)

work bowl

Dough blade

Slicing blade

W11279640B.indd 2 10/18/2018 2:23:03 PM

ENGLISH

FOOD PROCESSOR SAFETY | 3

FOOD PROCESSOR SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed, including

the following:

1. Read all instructions. Misuse of appliance may result in

personal injury.

2. To protect against risk of electrical shock, do not put

Food Processor in water or other liquid.

3. Turn the appliance OFF, then unplug from the outlet

when not in use, before assembling or disassembling

parts and before cleaning. To unplug, grasp the plug

and pull from the outlet. Never pull from the power

cord.

4. This appliance is not intended for use by persons,

(including children) with reduced physical, sensory,

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instructions concerning use of the appliance by a

person responsible for their safety.

5. Children should be supervised to ensure they do not

play with the appliance.

W11279640B.indd 3 10/18/2018 2:23:03 PM

4 | PARTS AND FEATURES

FOOD PROCESSOR SAFETY

6. Avoid contacting moving parts.

7. Do not operate any appliance with a damaged cord or

plug, or after the appliance malfunctions, or is dropped

or damaged in any manner. Return appliance to the

nearest Authorised Service Centre for examination,

repair, or adjustment.

8. If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

9. The use of attachments not recommended or sold by

KitchenAid may cause fire, electric shock, or injury.

10. Do not use the appliance outdoors.

11. Do not let cord hang over edge of table or counter.

12. Be careful if hot liquid is poured into the Food

Processor as it can be ejected out of the appliance due

to sudden steaming.

13. Keep hands and utensils away from moving blades or

discs while processing food to reduce the risk of severe

injury to persons or damage to the Food Processor. A

scraper may be used, but must be used only when the

Food Processor is not running.

14. Blades are sharp. Care should be taken when handling

the sharp cutting blades, emptying the jar, and during

cleaning.

15. To reduce the risk of injury, never place cutting blade

or discs on base without first putting bowl properly in

place.

16. Be certain cover is securely locked in place before

operating appliance.

17. Never feed food by hand. Always use the food pusher.

18. Do not attempt to defeat the cover interlock

mechanism.

19. Do not fill the bowl above the marked maximum fill line

(or rated capacity) to avoid risk of injury due to damage

to the cover or bowl.

W11279640B.indd 4 10/18/2018 2:23:03 PM

ENGLISH

PARTS AND FEATURES | 5

FOOD PROCESSOR SAFETY

20. Refer to the “Care and Cleaning” section for

instructions on cleaning the surfaces in contact with

food.

21. This appliance is intended to be used in household and

similar applications such as:

- staff kitchen areas in shops, offices, or other working

environments;

- farmhouses;

- by clients in hotels, motels, and other residential type

environments;

- bed and breakfast-type environments.

SAVE THESE INSTRUCTIONS

ELECTRICAL REQUIREMENTS

Voltage: 220-240 V

Frequency: 50-60 HZ

NOTE: If the plug does not fit in the

outlet, contact a qualified electrician.

Do not modify the plug in any way.

W11279640B.indd 5 10/18/2018 2:23:03 PM

6 | USING THE FOOD PROCESSOR

USING THE FOOD PROCESSOR

ACCESSORIES SELECTION GUIDE

ACTION SETTING FOOD ACCESSORY

Chop 1 or O/Pulse

Cheese

Chocolate

Fruits

Fresh herbs

Nuts

Tofu

Vegetables

Multipurpose stainless steel blade

Mince or Purée 2 or O/Pulse

Mix 1

Pasta Sauce

Pesto

Salsa

Sauces

Batters

Slice

Fruit (soft)

Potatoes

Tomatoes

Vegetables (soft)

Reversible slicing/shredding disc

(slicing side) OR slicing blade

Cheese

Chocolate

Fruits (hard)

Vegetables (hard)

Shred

(ﬁne to medium)

1Potatoes

Vegetables (soft)

Reversible slicing/shredding disc

(shredding side)

Cabbage

Cheese

Chocolate

Fruits (hard)

Vegetables (hard)

Knead O/Pulse or 2 Yeast doughs

Dough blade

W11279640B.indd 6 10/18/2018 2:23:04 PM

ENGLISH

USING THE FOOD PROCESSOR | 7

BEFORE FIRST USE

Lift up the lid latch to unlock the

cover. Tilt the work bowl cover back

and lift it straight up so that the lid

hinge pulls out of the handle hinge.

2Remove all parts and accessories

from the work bowl, and lift the food

pusher out of the feed tube.

Place the work bowl on the base,

aligning the handle with the raised

button on the right side of the base.

The bowl will click into place and

should be flush against the base

when properly aligned.

2Place the drive adapter in the work

bowl, lowering it onto the drive pin.

USING THE FOOD PROCESSOR

Before using your Food Processor for the ﬁrst time, wash all parts and accessories either

by hand or in the dishwasher (see the “Cleaning the Food Processor” section). Your Food

Processor is designed so that all accessories may be stored inside the work bowl.

ASSEMBLING THE FOOD PROCESSOR

IMPORTANT: Place the Food Processor on a dry, level countertop with the controls

facing forward. Do not plug in the Food Processor until it is completely assembled.

W11279640B.indd 7 10/18/2018 2:23:04 PM

8 | USING THE FOOD PROCESSOR

USING THE FOOD PROCESSOR

NOTE: For ease of assembly, install the desired blade or disc before attaching

the work bowl cover.

NOTE: Your Food Processor will not

operate unless the work bowl cover is

fully closed and the work bowl is properly

seated on the base.

3To attach the work bowl cover, push

the lid hinge into the handle hinge on

the work bowl and close the cover.

4Once the work bowl cover is closed,

push the lid hinge down into the

locked position.

INSTALLING THE MULTIPURPOSE BLADE OR DOUGH BLADE

1Place the blade on the drive adapter.

Rotate the blade so it falls down to

the base of the adapter.

2Install the work bowl cover, making

sure the lid latch is pushed down to

the locked position.

W11279640B.indd 8 10/18/2018 2:23:05 PM

ENGLISH

USING THE FOOD PROCESSOR | 9

USING THE FOOD PROCESSOR

INSTALLING THE REVERSIBLE SLICING/SHREDDING DISC OR

SLICING BLADE

To slice: Turn the disc so that the

raised slicing blade is facing up.

To shred: Turn the disc so that the

small, raised shredding blades are

facing up.

The disc can be placed in two different

positions: high at the top of the bowl

for processing, and low in the bowl for

storage.

NOTE: While the disc will operate in

storage position, it will not perform as

well. Make sure the disc is level with the

top of the bowl for best performance.

Hold the disc by its centre hub and

lower it onto the drive adapter,

aligning the marks on the centre

hub of the disc to the marks on the

adapter. The disc should be level with

the top of the bowl. If the disc falls to

the storage position, lift it out, turn it

90°, and lower it again.

3Install the work bowl cover, making

sure the lid latch is pushed down to

the locked position.

Process

Storage

Alignment

marks

W11279640B.indd 9 10/18/2018 2:23:05 PM

10 | USING THE FOOD PROCESSOR

OPERATING THE FOOD PROCESSOR

Before operating the Food Processor, be

sure the work bowl, blades, and work bowl

cover are properly assembled on the base

(see the “Assembling the Food Processor”

section).

Rotating Blade Hazard

Always use food pusher.

Keep ngers out of openings.

Keep away from children.

Failure to do so can result in

amputation or cuts.

USING THE FOOD PROCESSOR

To turn on, press 1 or 2. The Food

Processor will run continuously and

the indicator light will glow.

To turn off, press 1 or 2 again, or

press O/Pulse.

To use the Pulse function:

Press O/Pulse for short bursts,

or press and hold for longer bursts.

The Pulse function runs at high

speed only. The Food Processor will

turn off when the O/Pulse button is

released.
