KSMSFTA

W11221344A_EN_v08.indd 1 5/31/18 11:03 AM

PARTS AND FEATURES

PARTS AND ACCESSORIES

Ingredient hopper

Swivel chute

On/off

button Weight unit

toggle

Tare button

Sifter

Screen

Collar

Sifter assembly

(see detail below)

Sifter housing

Lid/scale plate

Digital scale

Digital scale display and control panel Sifter assembly detail

Ingredient valve

lb/oz/g

gozlb

W11221344A_EN_v08.indd 2 5/31/18 11:03 AM

ENGLISH

SIFTER+SCALE ATTACHMENT SAFETY | 3

SIFTER+SCALE ATTACHMENT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience or

knowledge, unless they are closely supervised and instructed concerning use

of the appliance by a person responsible for their safety. Close supervision is

necessary when any appliance is used by or near children. Children should be

supervised to ensure that they do not play with the appliance.

3. Turn the Stand Mixer OFF (and detach Sifter+Scale attachment from the Stand

Mixer) after each use of the attachment and before cleaning. Make sure motor

stops completely before disassembling.

4. Avoid contacting moving parts.

5. The use of attachments not recommended or sold by KitchenAid may cause

re, electric shock, or injury.

6. Also see the Important Safeguards section included in the Stand Mixer Use and

Care Guide.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

W11221344A_EN_v08.indd 3 5/31/18 11:03 AM

4| USING THE SIFTER+SCALE ATTACHMENT

USING THE SIFTER+SCALE ATTACHMENT

VOLUME-TO-WEIGHT CONVERSION GUIDE

Ingredients such as ﬂour can vary widely in density. In order to achieve the most consistent

results, we recommend measuring these ingredients by weight, not volume.

For recipes that only provide volume measurements, the chart below provides a good starting

point for converting to grams. As you repeat a recipe, you can adjust as needed to ﬁnd the

optimal weight measurement for each dry ingredient to get the best results, every time.

INGREDIENT

APPROXIMATE CONVERSION*

1 TEASPOON

(TSP)

1 TABLESPOON

(TBSP) 1 CUP

All-Purpose Flour 2.6 g 7.8 g 125 g

Bread Flour 2.9 g 8.6 g 137 g

Cake Flour 2.9 g 8.6 g 137 g

Whole-Grain Flour 2.5 g 7.5 g 120 g

Baking Powder

(Sodium Aluminum Sulfate) 4.6 g 13.8 g 221 g

Baking Soda 4.6 g 13.8 g 221 g

Salt (Table) 6.1 g 18.3 g 292 g

Brown Sugar (Packed)** 4.6 g 13.8 g 220 g

Granulated Sugar 4.2 g 12.5 g 200 g

Powdered Sugar 2.5 g 7.5 g 120 g

FOR DETAILED INFORMATION ON USING THE SIFTER+SCALE ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes, and

tips on how to use your Sifter+Scale attachment.

*Approximate imperial values based on USDA (US Department of Agriculture) ﬁgures. Your

ingredients may differ. Other countries may use non-imperial measurement standards with

different conversions. The included digital scale will measure to the nearest whole gram.

**NOTE: Do not feed brown sugar through the sifter, as it may clog the sifter screen.

W11221344A_EN_v08.indd 4 5/31/18 11:03 AM

ENGLISH

USING THE SIFTER+SCALE ATTACHMENT | 5

USING THE SIFTER+SCALE ATTACHMENT

SIFTER+SCALE CONFIGURATIONS

The Sifter+Scale attachment is compatible with all household KitchenAid Stand Mixers,

including all accessory stainless steel, glass, and ceramic bowls. It is not compatible with the

Precise Heat Mixing Bowl, Ice Cream Maker, or the Pouring Shield.

The Sifter+Scale attachment can be used in multiple ways: to weigh and sift ingredients while

slowly feeding them into the mixer bowl or into a separate container, to weigh and feed

ingredients without sifting, and to weigh ingredients on your countertop.

To weigh, sift, and slowly feed ingredients into

mixer bowl or separate container: Use the complete

attachment for recipes calling for ingredients to be

sifted and fed slowly into the mixer bowl or a separate

container.

To weigh and feed ingredients into bowl without

sifting: Use the attachment without the sifter when

weighing and feeding larger ingredients, such as whole

oats, that do not need to be sifted. To add those

ingredients slowly, you can limit the ﬂow by using the

ingredient valve.

To use as a countertop scale: Set the scale on your

countertop or table and place the lid/scale plate on

top.

ATTACHING THE SIFTER HOUSING TO THE STAND MIXER

Before using your Sifter+Scale for the ﬁrst time, wipe the ingredient hopper, sifter assembly,

and swivel chute with a warm damp cloth, then wipe clean with a damp cloth. Do not wash the

sifter housing or digital scale. Dry with a soft cloth. See the “Care and cleaning” section for

complete instructions.

1 Turn the Stand Mixer off and unplug.

For Stand Mixers with a hinged attachment hub

cover: Flip up to open.

For Stand Mixers with a removable attachment hub

cover: Turn the attachment knob counterclockwise to

remove attachment hub cover.

W11221344A_EN_v08.indd 5 5/31/18 11:03 AM

6| USING THE SIFTER+SCALE ATTACHMENT

USING THE SIFTER+SCALE ATTACHMENT

ASSEMBLING THE SIFTER+SCALE ATTACHMENT

To install the swivel chute: Lower the swivel chute

into the sifter housing at an angle, aligning the marks

on the swivel chute with the marks above the notches

on the inside of the sifter housing. Properly installed,

swivel chute will be seated securely in the sifter

housing and will rotate easily.

TIP: Aligning the handle tab on the chute with one of the notches as you lower the swivel

chute into the sifter housing will help you to line up the marks.

To install the sifter assembly: Lower the sifter into the

sifter housing at an angle so that the drive shaft can

be inserted into the sifter housing. Once the shaft is

inserted all the way, press down on the sifter, opposite

of the shaft, to click it into place.

To install the scale: Place the scale on top of the sifter

housing with the digital scale display facing away from

the Stand Mixer, and slightly left of center. Twist the

scale counterclockwise until it locks into place.

4 To install the ingredient hopper: Align the ingredient

valve with the corresponding notch on the scale, and

lower the hopper onto the scale until fully seated.

Insert the attachment shaft housing into the

attachment hub, making certain the power shaft ﬁts

into the square hub socket. If necessary, rotate the

attachment back and forth. The pin on the attachment

housing will ﬁt into the notch of the hub rim when in

the proper position.

4 Tighten the Stand Mixer attachment hub knob

clockwise until the attachment is completely

secured to the Stand Mixer.

W11221344A_EN_v08.indd 6 5/31/18 11:03 AM

ENGLISH

USING THE SIFTER+SCALE ATTACHMENT | 7

USING THE SIFTER+SCALE ATTACHMENT

WEIGHING AND SIFTING INGREDIENTS

1 lb/oz/g

gozlb Press (On/off), then press (Tare) until the

display reads 0.

Before adding ingredients to the hopper, be sure the

ingredient valve is in the closed position and swivel

chute is pointed into the mixer bowl or an appropriate

container.

NOTE: If desired, the scale and hopper can sit on the countertop, and ingredients can be

added until the target weight is achieved. The full scale and hopper can then be installed onto

the attachment.

lb/oz/g

gozlb OPTIONAL: Press the lb/oz/g button to choose

between pounds, ounces, and grams. The default

setting is grams.

3 Add your ingredients to the ingredient hopper until

you reach the target weight.

TIP: Make sure your dry ingredients have no large or hard clumps before feeding them

through the sifter. As with any sifter, large or hard clumps may not be broken up during the

sifting process.

0 Stir 2 4 6 8 10

Turn on the Stand Mixer to the desired speed, then

open the ingredient valve. The ingredients will be

sifted and ﬂow into the bowl according to the selected

speed.

NOTE: The sifter can operate at any speed, so select

the speed that works best for your recipe.

TIP: If your recipe calls for multiple dry ingredients, press between adding ingredients for

weighing, and stir them in the hopper before opening the ingredient valve.

NOTE: Once you’ve weighed your ingredients, you may turn off the scale at any time by

pressing . The scale will also shut off automatically after 5 minutes of non-use.

W11221344A_EN_v08.indd 7 5/31/18 11:03 AM

8| TROUBLESHOOTING

TIPS FOR GREAT RESULTS

TROUBLESHOOTING

HELPFUL HINTS

• If the ingredients are sifting faster than

desired, you can use the ingredient valve

to limit the rate at which ingredients ﬂow

into the sifter.

• When releasing ingredients, it may be

necessary to ﬂip the valve back and forth

1-2 times or tap the hopper to ensure all

ingredients are released.

• The maximum capacity of the scale is

1,000g / 2.2lbs / 2lbs 3oz, and the scale

measures in increments of 1g / 0.002lb /

0.05oz.

• Do not feed brown sugar through the

sifter, as it may clog the sifter screen.

• If ingredients become jammed in the

sifter, turn the mixer off and use a spoon

to clear the jam.

• Use dry ingredients only with the

Sifter+Scale attachment.

• Make sure your dry ingredients have

no hard or large clumps before feeding

them through the sifter. As with any sifter,

clumps will not be broken up during the

sifting process.

• The ingredient hopper does not lock

into place. If using a tilt-head Stand

Mixer with the sifter attached, be sure

to remove the ingredient hopper before

lifting the mixer head to avoid the

ingredient hopper tipping or falling off of

the sifter.

• You may wish to place the lid/scale plate

on top of the hopper to reduce dust

when sifting.

FOR DETAILED INFORMATION ON USING THE SIFTER+SCALE ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes, and

tips on how to use your Sifter+Scale attachment.

USING THE SIFTER+SCALE ATTACHMENT

5 Once sifting appears to be complete, tap the housing

and then the chute to release all residual ingredients.

While using the Sifter+Scale attachment, you may see the following messages displayed:

Err

The scale has exceeded its weight limit. Remove ingredients from hopper, and try again with a

smaller amount.

- - - Err1

Tare error. Remove ingredients and turn off power. Then, turn power back on. If Err1 is still

present, call customer service.

W11221344A_EN_v08.indd 8 5/31/18 11:03 AM

ENGLISH

CARE AND CLEANING | 9

CARE AND CLEANING

CLEANING THE SIFTER+SCALE ATTACHMENT AND ACCESSORIES

The following parts are dishwasher-safe, top rack only:

ingredient hopper, sifter assembly, swivel chute, and

scale plate.

TIP: When placing the ingredient hopper on the rack,

be sure it is lying on its side with the ingredient valve

facing down.

Do not immerse the scale or sifter housing in water

or other liquid. Wipe clean with a warm, damp cloth,

and dry thoroughly with a soft cloth before re-use or

storing.

3 To disassemble the sifter assembly: Turn the collar to

the left to loosen and release the screen for cleaning,

if desired.

REPLACING THE BATTERIES

The digital scale of your Sifter+Scale attachment is powered by 2 AAA batteries (included).

1 Flip the digital scale over, and use a Phillips-head

screwdriver to remove the screw on the compartment

cover. Lift the compartment cover as shown.

2 Replace the 2 AAA batteries in the compartment.

Make sure to replace the screw when reattaching the

compartment cover.

FOR DETAILED INFORMATION ON CLEANING THE SIFTER+SCALE ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes, and

tips on how to clean your Sifter+Scale attachment.

W11221344A_EN_v08.indd 9 5/31/18 11:03 AM

10 | WARRANTY AND SERVICE

WARRANTY AND SERVICE

KITCHENAID SIFTER+SCALE ATTACHMENT WARRANTY FOR THE

50 UNITED STATES, THE DISTRICT OF COLUMBIA, PUERTO RICO,

AND CANADA

This warranty extends to the purchaser and any succeeding owner for Sifter+Scale attachments

operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada.

Length of Warranty: One Year Full Warranty from date of purchase.

KitchenAid Will Pay

for Your Choice of: Hassle-Free Replacement of your Sifter+Scale attachment. See

the next page for details on how to arrange for service, or call

the Customer eXperience Center toll-free at 1-800-541-6390.

The replacement parts and repair labor costs to correct defects

in materials and workmanship. Service must be provided by an

Authorized KitchenAid Service Center.

KitchenAid Will

Not Pay for: A. Repairs when your Sifter+Scale attachment is used in other

than normal single family home use.

B. Damage resulting from accident, alteration, misuse or

abuse.

C. Any shipping or handling costs to deliver your

Sifter+Scale attachment to an Authorized Service Center.

D. Replacement parts or repair labor costs for Sifter+Scale

attachments operated outside the 50 United States, District

of Columbia, Puerto Rico, and Canada.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED

TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY

BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD

ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS

OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY

TO YOU.

IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND

EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE

TERMS OF THIS LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA

DO NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL

DAMAGES. This warranty gives you speciﬁc legal rights and you may also have other

rights which vary from state to state or province to province.

W11221344A_EN_v08.indd 10 5/31/18 11:03 AM

Andere Handbücher für KSMSFTA

Inhaltsverzeichnis

Andere KitchenAid Küchengerätezubehör Handbücher

KitchenAid

KitchenAid 5KSMSFTA Bedienungsanleitung

KitchenAid

KitchenAid 5KGM Bedienungsanleitung

KitchenAid

KitchenAid KSM2APC Bedienungsanleitung

KitchenAid

KitchenAid 5KRAV Bedienungsanleitung

KitchenAid

KitchenAid KSMFGA Bedienungsanleitung

KitchenAid

KitchenAid Architect Series II KCMS1555SSS Bedienungsanleitung

KitchenAid

KitchenAid 5KGM Bedienungsanleitung

KitchenAid

KitchenAid FT Bedienungsanleitung

KitchenAid

KitchenAid KCMS1655BSS Bedienungsanleitung

KitchenAid

KitchenAid 5KSMSCA Bedienungsanleitung

KitchenAid

KitchenAid KSMFGA Bedienungsanleitung

KitchenAid

KitchenAid 12884405 Handbuch

KitchenAid

KitchenAid 5KSMSSA Bedienungsanleitung

KitchenAid

KitchenAid Glass Bowl Bedienungsanleitung

KitchenAid

KitchenAid 5KSMFVSP Bedienungsanleitung

KitchenAid

KitchenAid 5KSM1JA Bedienungsanleitung

KitchenAid

KitchenAid KCMS1555SSS - Countertop Microwave Oven Bedienungsanleitung

KitchenAid

KitchenAid 5KSMICM Bedienungsanleitung

KitchenAid

KitchenAid 5FGA Bedienungsanleitung

KitchenAid

KitchenAid KSMFGA Bedienungsanleitung

KitchenAid

KitchenAid 5KSMFVSP Bedienungsanleitung

KitchenAid

KitchenAid KSMSIA Bedienungsanleitung

KitchenAid

KitchenAid 5KGB Bedienungsanleitung

KitchenAid

KitchenAid 5KSMFGA Bedienungsanleitung

Beliebte Küchengerätezubehör Handbücher anderer Marken

JUNO

JUNO SCC2635BR Gebrauchs- und Pflegehandbuch

Bosch

Bosch ErgoMixx MSM6 IN Series Bedienungsanleitung

Viking

Viking VGC530 Bedienungsanleitung

Maytag

Maytag AG202MG - Gas Burner Module Bedienungsanleitung

Orava

Orava BN-30 Bedienungsanleitung

TurboChef

TurboChef ENCORE Bedienungsanleitung

TurboChef

TurboChef CON-3002 Stücklistenhandbuch

Kenwood

Kenwood KAT91.000CL Bedienungsanleitung

Bosch

Bosch VeggieLove Bedienungsanleitung

Miele

Miele DUU 1000-2 Bedienungsanleitung

Bosch

Bosch MUZ8MX2 Bedienungsanleitung

Tramontina

Tramontina 80202/005DS Kurzanleitung

Dualit

Dualit Tamper Bedienungsanleitung

Kenmore

Kenmore 22009 Bedienungsanleitung

Bosch

Bosch MSMS CN Series Bedienungsanleitung

Maytag

Maytag 4396395T Bedienungsanleitung

eta

eta 0028 96000 Bedienungsanleitung

Pro-Fondi

Pro-Fondi Pro-Fondi Bedienungsanleitung
