Kitsound BoomBar+ Bedienungsanleitung

USER MANUAL

JB. 5585-b / KSBBP / Made in China.

All trademarks are acknowledged as the property of their respective owners.

Unless otherwise stated their use does not imply that the trademark owner is

aliated with KitSound or endorses the products herein.

Your product and batteries must be recycled or disposed of properly.

Please contact your local recycling centre for more information on proper disposal.

BOOMBAR+

WIRELESS

SPEAKER

kitsound.co.uk

2 3

Please read this manual carefully before use

Box contents

• KS BoomBar+

• Battery

• Micro USB charge cable

• 3.5 mm aux cable

• Carry pouch

• User manual

Functions

1. Multi Function Button (MFB)

2. LED indicator

3. Aux input

4. Micro USB charge port

5. Microphone

4 5

Instructions for use

Charging the battery

The BoomBar+ has a removable rechargeable lithium battery. Make sure the BoomBar+ is

switched o. Connect one end of the Micro USB charge cable to the Micro USB charge port (4)

on the BoomBar+ and connect the other end to your PC or USB mains adaptor. The battery

will start charging.

• It takes up to 3 hours to fully charge the battery

• Whilst charging, the LED indicator (2) will light up red

• When fully charged, the LED indicator (2) will turn o

Battery protection mode

To keep the rechargeable battery in good condition, please discharge and recharge speaker

every 3 months, especially if you are not using the speaker for long periods of time.

Getting started

• To turn the BoomBar+ on, press and hold the MFB (1) for 3 seconds

• To turn the BoomBar+ o, press and hold the MFB (1) for 3 seconds whilst it is on

6 7

Wireless setup

Pairing a wireless device

1. With the BoomBar+ turned o, press and hold the MFB (1) for 3 seconds

2. The LED indicator (2) will quickly ash blue to indicate power on. Shortly after powering on

the LED indicator (2) will ash red/blue, indicating pairing mode has been entered

3. Turn on your iOS, Android, or Windows device’s Bluetooth ON and search for new devices

4. Select ‘KS Boombar+’ from the list of found devices. If asked for a passcode, enter ‘0000’

or ‘1234’ and the speaker will then be connected to your device

5. After pairing successfully, the LED indicator (2) will change to a slow ashing blue

Note: If your device is not connecting automatically, it’s because it is not the last paired device.

Simply delete ‘BoomBar+’ from the list of wireless devices on your device and re-pair.

Note: ‘Bluetooth’ is a trademark of Bluetooth SIG, Inc. This product is in no way aliated or

endorsed by Bluetooth SIG Inc.

Re-pairing or pairing new devices

1. The next time the BoomBar+ is turned on, it will automatically search for and attempt to

connect to the last paired device

2. Make sure the wireless connectivity is turned o on any previously paired devices

3. Follow ‘Pairing a wireless device’ instructions from step 1

8 9

Playing audio wirelessly

1. Follow the instructions in the ‘Pairing a wireless device’ section

2. Use the controls on your device to select content

3. Audio played through the connected wireless device will now be heard through the speaker

4. To play or pause the selected track, use the controls on your device or press the MFB (1)

5. To skip to the next track, use the controls on your device or press the MFB (1) twice.

Previous track can only be controlled using your device

6. The volume can be adjusted on your device only

Note: Track control functions from the MFB (1) on the BoomBar+ will require your device to

have Bluetooth prole AVRCP. Please check your device’s manual if unsure.

Using the aux-in

1. With the BoomBar+ turned on, insert the 3.5 mm aux cable into the Aux input (3)

on the BoomBar+

2. The LED indicator (2) will turn solid green and any active wireless connection will disconnect

3. Plug the other end of the aux cable into the audio/headphone output on an MP3 player or

other audio source

4. Audio played through the connected device will now be heard through the speaker

5. The volume can be adjusted on your device only

Note: The MFB (1) does not operate in Aux input mode.

10 11

PLEASE NOTE:

Your device will have an internal amplier and if it is playing digital les like MP3s it will also have

an integrated DAC (Digital Audio Converter). If you turn up the volume to 100%, your device will

be sending distorted signals to the BoomBar+. To avoid this and to get the best sound quality

from the speaker, we recommend that you do not run your device any higher than 95% volume.

Call handling

Answer a call When a call comes through, the BoomBar+ will play your ringtone.

Press the MFB (1) to answer

End call During a call, press the MFB (1) to end the call

If using an Android phone, you can disable the hands free function. To do this:

1. Go to the wireless menu and press the settings icon next to ‘BoomBar+’

2. Uncheck the ‘Call Audio’ box

Calls are now controlled and played through the phone as normal.

12 13

Specications

Works with Bluetooth® V4.1

Wireless connectivity range up to 10 m

S/N 85 dB

Frequency response 20 Hz – 20 kHz

Driver 2 x 40 mm

Output RMS 6 W

Aux-in 3.5 mm

Play time up to 20 hours

Charging time up to 3 hours

Battery Li-ion, 1120 mAh

Care for your BoomBar+

Please DON’T:

• Get the BoomBar+ wet

• Drop the BoomBar+ as this will invalidate your warranty

• Open up the BoomBar+ as there are no user serviceable parts inside

• Expose the BoomBar+ to extreme temperatures or rapid changes of hot to cold or vice versa

Please DO:

• Clean the BoomBar+ with a soft dry cloth and no detergents

14 15

We hope you’ve now got all the information you need to get started, but if you’re having problems

with anything, please feel free to contact us at: suppor[email protected].uk

Hereby, Kondor Ltd declares that the radio equipment type,

KSBBP BoomBar+ Wireless Speaker, is in compliance

with Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the

following internet address: http://kondor.co.uk/product-documents.

The use and operation of this speaker is beyond our control. Warranty of the BoomBar+ is limited to defects caused by faulty

manufacture or defects in materials only. No warranty whatsoever is given or implied for damage caused by the user under

any circumstances.

This does not aect your statutory rights.

Please do not attempt to open this product. There are no user serviceable parts inside, in particular if your product has an

embedded, non-replaceable battery, do not attempt to access or remove the battery as this may cause personal injury and

will damage the product.

Making any attempt to open the product or carry out repair voids any and all warranties.

We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a result of

product improvement and development.
