KodaCloud K40 Bedienungsanleitung
K40 Multi Access AP
Installation Guide
Page 2
Package Contents
Hardware Overview
Bottom
Page 3
Rear
LEDs
Page 4
Step 1 – Prepare Site
A Run the Ethernet Uplink cable through the large hole in the middle of the
mounting bracket. Optionally run an Ethernet Pass Through cable through
the same hole. Ensure the protruding mounting tabs of the mounting
bracket face away from the wall.
This unit must be installed indoors. The unit is not
designed for outdoor use.
Page 5
Step 2 – Attach Mounting Bracket to Wall
A (Preferred) Use the two supplied mounting bolts to attach the mounting
bracket to a gang box. Ensure the bracket’s captive screw is on the left.
B (Optional) Attach the mounting bracket to the wall with the supplied
anchors and screws. Use the mounting bracket as a drill hole template.
Ensure the bracket’s captive screw is on the left.
Page 6
Step 3 – Connect the Access Point
AAttach the Ethernet Uplink cable to the black RJ-45 Uplink port at the
rear of the access point. To use the alternate punch-down block, visit
the Support website (http://KodaCloud.com/support).
Step 4 – Attach Access Point to Bracket
ASlide the two protruding mounting tabs on the right of the bracket into
the matching holes at the rear of the access point.
B Rotate the access point until the anchor hole at the rear aligns with the
captive screw of the bracket. Push any excess cable back into the gang
box or wall.
Page 7
C Use the supplied Torx key to tighten the captive screw thus securing the
access point to the bracket.
Step 5 – Apply Power to the Access Point
Power is supplied through the Ethernet Uplink cable through the black RJ-45
Uplink port at the rear of the access point:
•If using LAN3/PoE, ensure the Ethernet Uplink cable supplies IEEE
802.3at PoE (Power-over-Ethernet).
•Otherwise, ensure the Ethernet Uplink cable supplies IEEE 802.3af PoE
(Power-over-Ethernet).
Page 8
Step 6 - Verify Connectivity
Verify that the K40 access point is connected to your network with either the
KodaCloud website or the KodaCloud mobile device app.
Check the Power LED to determine whether the access point is operating
correctly. The access point is properly installed and connected to the
KodaCloud management services when the LED turns solid green after a few
minutes.
When the access point is powered on, the Power LED should display the
following sequence:
#
Power LED
Description
1
Power LED Solid Orange and all
other LEDs on
(for less than 10 seconds)
Unit has just received power and
has started booting
2
Power LED Solid Orange and all
other LEDs off
(for less than a few minutes)
Unit is starting up.
3
Blinking Green
(for less than a minute)
Access point is negotiating a
connection with KodaCloud
management services in the cloud.
4
Solid Green
Access point is successfully setup
to be managed by KodaCloud
management services in the cloud.
Note 1: The very first time the Access Point is connected, it will self-update
so it will go through this sequence twice.
Note 2: See “Tips and Troubleshooting” if the access point does not reach
solid green.
Page 9
Step 7 - Configure the Access Point
Use your mobile device or the KodaCloud website.
Website
Sign into your account at http://KodaCloud.com and follow the instructions in
the KodaCloud website to complete the process.
Mobile Device
Information about the mobile app is available at http://KodaCloud.com. The
mobile device app includes instructions for completing the process.
If you have any trouble, contact support@kodacloud.com. We’ll be happy to
help!
Tips and Troubleshooting
If your access point Power LED light is flashing orange and all other LEDs
are off for over 10 minutes
The access point cannot connect to the KodaCloud management services. This
usually occurs when the unit cannot get an IP address from your network using
DHCP and has switched to Local Network Configuration mode.
While in this mode, the access point does not pass data through the Uplink
port and broadcasts an SSID that contains a portion of the access point’s MAC
address. You can use any Wi-Fi enabled device to connect to this SSID and
configure the network settings for this access point using a web browser.
To connect to the access point using the Local Network Configuration
interface:
1. Connect your Wi-Fi enabled device to the SSID in the form of “AP-
XX:XX:XX” (where X is a placeholder)). You are successfully
connected when the Power LED on the access point becomes solid
red.
2. Use your web browser to navigate to http://192.168.100.1 (login
using user: admin, password: admin).
3. Follow the on-screen instructions.
Page 10
See the Support website (http://kodacloud.com/support) for information
about Local Network Configuration.
Note: Local Configuration mode only activates if the access point is in factory
default condition and has never connected to the KodaCloud management
services in the cloud.
Resetting to Factory Defaults
If the access point is disconnected from a power source, press and hold the
Reset button, and connect power to the unit. The Power LED turns solid
orange and the 5 GHz LED turns solid green. All other LEDs are off. This
pattern indicates the unit is restoring itself to factory defaults.
OR
If the access point is connected to a power source, press and hold the Reset
button until the Power LED turns solid orange, the 5 GHz LED turns solid green,
and all other LEDs are off. Once the LEDs show this pattern, release the Reset
button. This action restores the unit to the factory default settings.
Learning More, Service, and Support
Online Resources
Our support website (http://kodacloud.com/support) contains links to online
resources available to help you get the most out of your access point.
Copyright and Trademark
Copyright © 2017 KodaCloud, Inc. All rights reserved. The contents of this
Installation Guide are the copyrighted and proprietary property of KodaCloud,
Inc. Reproduction, distribution or modification without the express, written
permission of KodaCloud, Inc. is not permitted. “Art2Wave” and “KodaCloud”
are trademarks of KodaCloud, Inc. All other trademarks are the property of
their respective owners.
