Press “MODE” button and select “cooling” or “heating” mode, then press the temperature
setting button once, the pre-set temperature will be raised or lowered by 1 degree. .
3-2 Air Direction Setting
Press the air “DIRECTION” button, the ventilating door will move as follows:
static up and down swing
close
Note: If you need a different static angle. Press “DIRECTION” button when the
louver is in the position you want.
3-3 Lock Operation
Press “LOCK”button to turn the display off, press again to return display to normal.
4.
Operation
of theTimer
In “cooling”, “dehumidifying” or “heating” mode, press “TIMER” button to select “timer off” or
“timer on”, then press “-” or “+” to set the time you need.
Note: The initial setting of time is 1 hour.
The pre-setting time range is 1-18 hours.
5.
Running
Mode
5-1 Cooling
Press “MODE” button, select cooling mode.
Press pre-set temperature buttons, set the temperature you need.
Press “SPEED” button, choose the fan speed you need.
Press “DIRECTION.” button choose the air direction you want.
Stop, press “ ” button.
Attention: Before maintenance, keep the indoor unit running more than half an hour
(method: In cooling mode, set temperature at 20 ).
Note: When running lamp turns off this indicates the pre-set temperature has been
reached.
5-2 Dehumidifying
Press “MODE” button, choose dehumidifying mode.
Press “DIRECTION” button, choose the suitable air direction.
Stop, press “ ” button.
Note: 1. To dehumidify: Keep the outdoor unit running for 10 minutes, then stop for 5 minutes,
repeat in cycles, the fan speed of indoor unit should be at low speed.
2. The temperature can’t be pre-set when in dehumidifying mode.
5-3 Heating
Press “MODE” button, choose heating mode.
Press pre-set temperature buttons, set the temperature you need.
