Evolution 222 Stereo Preamplifier

Owner’s Reference, v06.0

Krell Industries, Inc.

45 Connair Road

Orange, CT 06477-3650 USA

This product complies with the EMC directive (89/336/EEC) and the low-voltage directive

(73/23/EEC).

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions.

2. Keep these Instructions.

3. Heed all Warnings.

4. Follow all Instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-

ratus (including amplifiers) that produce heat.

8. Unplug this apparatus during lightning storms or when unused for long periods of time.

9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way,such as a power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

10. The Evolution 222 preamplifier must be placed on a firm, level surface where it is not exposed

to dripping or splashing.

11. The ventilation grids on the top of the Evolution 222 preamplifier and the space underneath the

Evolution 222 preamplifier must be unobstructed at all times during operation. Do not place

flammable material above or beneath the preamplifier.

12. Before making connections to the Evolution 222 preamplifier, ensure that the power is off and

other components arein mute or stand-by mode. Make sureall cable terminations are of the

highest quality, free from frayed ends, short circuits, or cold solder joints.

13. Do not connect an RS-232 cable to the phono power port. Output from the phono power port

can seriously damage your computer.

14. Do not connect the cable from a Krell KPE phono stage to the RS-232 port.

15. THERE ARE NO USER SERVICEABLE PARTS INSIDE AN EVOLUTION 222 PREAMPLIFIER.

Please contact Krell if you have questions not addressed in this guide.

This product is manufactured in the United States of America. Krell®is a registered trademark of Krell Industries, Inc., and is restricted for use by

Krell Industries, Inc., its subsidiaries, and authorized agents. Evolution Bias™is a trademark of Krell Industries, Inc. and is a Krell technology

based on U.S. Patent No. 5,331,291. CAN Link™, CAST™, Evolution CAST™, and Krell Current Mode™are trademarks of Krell Industries,

Inc. All other trademarks are registered to their respective companies.

TEL 203-298-4000

FAX 203-891-2028

E-MAIL [email protected]

WEBSITE http://www.krellonline.com

Contents

List of Illustrations, page 4

ALetter from Dan D’Agostino, page 5

SECTION ONE: Evolution 222 Features and Technology, page 6

Features, Revolutionary Krell CAST Technology,

Definition of Terms

SECTION TWO: Unpacking and Placement, page 11

Opening the Evolution 222 Shipping Carton

SECTION THREE: Quick Start, page 13

Connecting the Evolution 222 to Your System,

Operating the Evolution 222

SECTION FOUR: Anatomy of the Evolution 222, page 15

Front Panel Description, Remote Control Description,

Battery Installation, and Back Panel Description

SECTION FIVE: Connecting the Evolution 222 to Your System, page 26

Input and Output Connections, Connection Steps

SECTION SIX: Evolution 222 Operation, page 28

On/Off and Stand-by Operation

SECTION SEVEN: Customizing the Evolution 222, page 29

Navigation Conventions, Menu Functions

SECTION EIGHT: Troubleshooting System Noise, page 43

WARRANTY, page 44

RETURN AUTHORIZATION PROCEDURE, page 46

SPECIFICATIONS, page 47

List of Illustrations

Figure 1, page 15

Evolution 222 Preamplifier Front Panel

Figure 2, page 19

Evolution 222 Remote Control

Figure 3, page 22

Evolution 222 Preamplifier Back Panel

ALetter from Dan D’Agostino

Dear Audio Enthusiast,

Thank you for your purchase of the Krell Evolution 222 preamplifier.

The preamplifier plays a vital role in audio playback by mediating the line-level out-

put of a wide variety of source components in preparation for the amplifier’s input.

At no other point in the reproduction process is music so vulnerable to change, as

the signal level is small, and susceptible to noise and distortion.

Having always valued the role of the preamplifier in fine audio systems, I take pre-

amplifier design very seriously.Irealize that, no matter how impressive an amplifi-

er’s performance; it can be no better than that of the preamplifier driving it.

My new Evolution 222 preamplifier employs balanced Krell Current Mode gain

stages from input to output, and Current Audio Signal Transmission (CAST)

receivers and transmitters. Utilizing these powerful technologies, the Evolution 222

conveys the complete range of timbre and dynamics that comprise the foundation

musical performance. Typical of my latest preamplifier designs, the Evolution 222

preamplifier includes a thoughtful suite of menu options, and can be customized

for the greatest ease of operation.

Ihope that you enjoy your new Evolution 222 preamplifier.

Sincerely,

Daniel D’Agostino

Chief Executive Officer

SECTION ONE

Evolution 222 Features and Technology

This section describes the innovative features and technology of the Evolution 222

preamplifier, and defines CAST and other key terms used in this reference.

Features

The Evolution 222 has an open loop bandwidth that exceeds 1 MHz and a

balanced Krell Current Mode design, terminating in Evolution CAST ™. CAST

inputs and outputs drive a newly designed current mode balanced input stage.

Class A, balanced circuitry is used throughout the preamplifier. Cascoded, current

mirror input and output stages utilize an LED voltage reference to achieve an

exceptionally linear state of operation. There are 310 transistors utilized in each

channel, and all are Class A biased. A robust power supply is on board for excep-

tional audio performance.

Revolutionary Krell CAST Technology

Current Audio Signal Transmission, termed CAST, is a revolutionary method of

connecting analog audio components for unparalleled sonic performance.

Innovative engineering combines the new Krell CAST circuitry with existing Krell

Current Mode technology to create entire CAST systems that reproduce music

with incredible range, tonality, and precision.

The Voltage Signal Transmission

and the Traditional Audio System

Traditionally, signal is transmitted in the voltage domain between two components.

In an audio system, each component is a discrete entity with unique characteris-

tics that act upon the musical signal independently. Each component is unaware

of the other components in the system. The cables that connect the components

also have their own electrical characteristics, which affect the sonic presentation

of the entire system. CAST transmission unifies individual components and inter-

connects into an electrically-linked whole. The original signal remains unaltered

from source to speaker.

CAST Basics

Here is how a CAST audio system works. Internally, each CAST source transfers,

or amplifies, current using Krell Current Mode circuitry. This current signal is then

output using CAST circuitry. When the signal is received by a CAST input, Krell

Current Mode circuitry again takes over until the signal reaches the loudspeaker.

By maintaining the musical signal in the current domain from beginning to end, an

entire CAST system behaves as if it is one component. With CAST, circuit board

properties and signal transmission aberrations between components are eliminat-

ed. Cable impedances and their effects on the transmitted signal are non-existent.

How CAST and Krell Current Mode Interact

While CAST is a new method of transferring the musical signal between compo-

nents, its origin stems from Krell Current Mode, the technology developed to

transfer the musical signal within a component. CAST combined with Krell Current

Mode takes circuitry signal transmission to the next evolutionary level. In essence,

continued

Krell Current Mode maintains the integrity of the signal within the component and

CAST preserves the transmitted signal between components. Together, CAST and

Krell Current Mode technologies unify separate Krell components into a single

global circuit. Krell Current Mode technology enjoys bandwidth increases up to an

order of magnitude greater than their voltage based counterparts. This dramatic

increase in circuit bandwidth delivers near perfection in the audible band that typi-

cally suffers from phase distortions in voltage circuits.

CAST Cable Construction

A CAST system uses cables manufactured by Krell and other manufacturers spe-

cially licensed by Krell. Thin and flexible CAST cables are constructed with the

same build quality as other Krell components and are aesthetically matched to the

components that Krell manufactures. An all-metal body and locking connectors

with gold contacts are part of the standard no-compromise specification devel-

oped for every CAST cable made.

Evolution CAST

By employing radical current mirror circuitry, the Evolution 222 components ele-

vate the CAST technology to another level. This advanced use of the technology

increases the linearity, transient speed, and bandwidth of the Evolution compo-

nents while reducing the distortion by an order of magnitude.

The Best Musical Performance

When you operate a CAST system, you will hear significant improvements in every

performance area: speed, precision, dynamic range, depth and width of the sound

stage, transient impact, tonal balance, harmonic distortion, and more. The goal for

CAST is the same company goal used for all Krell products. Krell strives for the

delivery of the best performance of a musical event for you, using the full expres-

sion of technology to date.

(SECTION ONE: Evolution 222 Features and Technology continued)

Definition of Terms

The following are definitions of key terms used in this owner’s reference:

Inputs and Outputs

Balanced

A symmetrical input or output circuit that has equal impedance from both input

terminals to a common ground reference point. The industry standard for profes-

sional and sound recording installations, balanced connections have 6 dB more

gain than single-ended connections and allow the use of long interconnect cables.

Balanced connections are completely immune to induced noise from the system

or the environment.

CAST and Evolution CAST

Krell Current Audio Signal Transmission, or CAST, is a proprietary Krell circuit tech-

nology for connecting analog components, transmitting the audio waveform

between components in the current domain rather than in the voltage domain. The

speed and bandwidth provided by Krell CAST and its circuitry update, Evolution

CAST, yield accurate, realistic music reproduction, enabling connected compo-

nents to perform as if they are all part of a single circuit.

Single-ended

A two-wire input or output circuit. Single-ended connections are not recommend-

ed for connections requiring long cable runs. Use care when using single-ended

connections, because the ground connection is made last and broken first. Turn

the system off/on prior to making or breaking single-ended connections.

Operation

Off

When the stand-by/power LED is not illuminated, the preamplifier is off.

Stand-by

A low-power-consumption status that keeps the audio and regulator circuits at

idle. The stand-by/power LED is illuminated in red, when the preamplifier is in

stand-by mode. Krell recommends leaving the preamplifier in stand-by mode when

it is not playing music.

Operation

When the standby/power LED is illuminated in blue, the preamplifier is in opera-

tional mode and ready to play music.

continued

Technology

Krell Current Mode

A proprietary Krell circuit topology in which the audio gain stages of a component

operate in the current rather than voltage domain. This unique technology provides

the component with exceptional speed, and a wide bandwidth.

(SECTION ONE: Definition of Terms continued)

Andere Handbücher für EVOLUTION 222

Inhaltsverzeichnis

Andere Krell Industries Verstärker Handbücher

Krell Industries

Krell Industries KRC-3 Kurzanleitung

Krell Industries

Krell Industries PAM-5 Bedienungsanleitung

Krell Industries

Krell Industries Monaural Amplifiers KMA-160 Bedienungsanleitung

Krell Industries

Krell Industries PHANTOM Bedienungsanleitung

Krell Industries

Krell Industries KAV-500 Kurzanleitung

Krell Industries

Krell Industries KPE Bedienungsanleitung

Krell Industries

Krell Industries KSA-100S Kurzanleitung

Krell Industries

Krell Industries S-300i Bedienungsanleitung

Krell Industries

Krell Industries Power Amplifiers MDA-300/500 Kurzanleitung

Krell Industries

Krell Industries Illusion Bedienungsanleitung

Krell Industries

Krell Industries KRC-HR Kurzanleitung

Krell Industries

Krell Industries S-550i Bedienungsanleitung

Krell Industries

Krell Industries Evolution 707 Kurzanleitung

Krell Industries

Krell Industries Evolution Kurzanleitung

Krell Industries

Krell Industries Class A Series Bedienungsanleitung

Krell Industries

Krell Industries S-1500 Bedienungsanleitung

Krell Industries

Krell Industries Preamplifier KBL Bedienungsanleitung

Krell Industries

Krell Industries HTS 2 Bedienungsanleitung

Krell Industries

Krell Industries Three-Channel Power Amplifier KAV-250a/3 Bedienungsanleitung

Krell Industries

Krell Industries Power Amplifier KAV-150a Kurzanleitung

Krell Industries

Krell Industries 2250e Bedienungsanleitung

Krell Industries

Krell Industries KAV-500 Kurzanleitung

Krell Industries

Krell Industries Amplifier KAV-250a Kurzanleitung

Krell Industries

Krell Industries PAM-7 Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
