OWNER’S REFERENCE

EVOLUTION ONE

MONAURAL POWER AMPLIFIER

EVOLUTION

Evolution One Monaural Power Amplifier Owner’s Reference, v05.0

Krell Industries, Inc.

45 Connair Road

Orange, CT 06477-3650 USA

TEL 203-799-9954

FAX 203-891-2028

E-MAIL krell@krellonline.com

WEBSITE http://www.krellonline.com

This product complies with the EMC directive (89/336/EEC) and the low-voltage directive

(73/23/EEC).

WARNINGS

The amplifier must be placed on a firm, level surface where it is not exposed to dripping or splash-

ing.

The ventilation grids on the top of the amplifier and the space underneath the amplifier must be

unobstructed at all times during operation. Do not place flammable material above or beneath the

amplifier.

Before making connections to the amplifier, ensure that the back panel power switch is down.

Make sure all cable terminations are of the highest quality, free from frayed ends, short circuits,

or cold solder joints.

The differential circuitry employed with an Evolution One Monaural Power Amplifier requires special

attention when connecting speakers. Do not connect the negative speaker terminals together. Do

not connect the negative speaker terminals to ground.

Do not connect an Evolution One Monaural Power Amplifier to a loudspeaker selector device that

employs a common ground scheme, as it may short-circuit the amplifier output.

THERE ARE NO USER SERVICEABLE PARTS INSIDE AN EVOLUTION ONE MONAURAL POWER

AMPLIFIER.

Please contact Krell if you have questions not addressed in this guide.

This product is manufactured in the United States of America. Krell®is a registered trademark of Krell Industries, Inc., and is restricted for use

by Krell Industries, Inc., its subsidiaries, and authorized agents. Evolution Bias™ is a trademark of Krell Industries, Inc. and is a Krell technology

based on U.S. Patent No. 5,331,291. CAST™, Evolution CAST™, and Krell Current Mode™ are trademarks of Krell Industries, Inc. All other

trademarks are registered to their respective companies.

iii

Contents

List of Illustrations, page iv

A Letter from Dan D’Agostino, page 1

SECTION ONE: About Krell, page 3

The Krell Legacy, Revolutionary Krell CAST Technology,

Ensuring Maximum Performance, and Definition of Terms

SECTION TWO: Unpacking and Placement, page 12

Opening the Evolution One Shipping Cartons

SECTION THREE: Anatomy of an Amplifier, page 15

Features and Benefits of the Evolution One Design

SECTION FOUR: Connecting an Evolution One Amplifier to Your System, page 19

CAST and Voltage Connections, Connection Steps,

DC Protection Circuitry, and Remote Control Options

SECTION FIVE: Amplifier Operation, page 22

Powering Up, Adjusting Power Meter Modes,

Switching between CAST and Voltage Connections,

Amplifier Care

SECTION SIX: Amplifier Troubleshooting, page 26

WARRANTY, page 28

RETURN AUTHORIZATION PROCEDURE, page 30

SPECIFICATIONS, page 31

List of Illustrations

Figure 1, page 15

Evolution One Amplifier and

Power Supply Chassis Front Panels

Inset Evolution One Amplifier Channel: Front Panel View

Figure 2, page 16

Evolution One Amplifier and

Power Supply Chassis Back Panels

Figure 3, page 17

Evolution One Amplifier Chassis Top

Figure 4, page 18

Evolution One Power Supply Chassis Top

continued

A Letter from Dan D’Agostino

Dear Audio Enthusiast,

Thank you for your purchase of the Evolution One.

The Evolution One Monaural Power Amplifier represents a watershed in my design

philosophy and in my quest for amplifiers that deliver absolute truth in music

reproduction. This new amplifier operates solely in the current domain, with only

one voltage gain stage at its output. I have always been fascinated by the artistry

inherent in great musical performances, and I believe that no component in an

audio system equates more closely to the full range of musical expression than

the power amplifier. The Evolution One reproduces real-life dynamics and trans-

parency in a manner that I have not experienced prior to this design. It is my

pleasure to make it available to you.

Krell amplifiers are best known for their ability to drive any loudspeaker to sound

its best, without regard to impedance or efficiency. The Evolution One amplifier

joins this awesome current capability with a new, ultra-linear circuit topology. It is a

strong belief of mine that linearity, an amplifier’s ability to output an exact dupli-

cate of the input signal, is the ultimate measure of that amplifiers worth. I drive

Krell amplifier designs toward the common goal of linearity; through the rigorous

application of Krell design principles that focus our efforts on four major perform-

ance factors: distortion, bandwidth, output impedance and current capability. The

Evolution One excels in each of these areas, delivering absolute accuracy from

extremely low levels of output, virtually at preamplifier levels, to astounding, awe-

inspiring amounts of power.

As the foundation of my new Evolution Series, the Evolution One Monaural Power

Amplifier is designed to complement the Evolution Two Monaural Power

Preamplifier perfectly. Combine the Evolution One and Two with my new LAT-1000

loudspeakers, and experience the extraordinary capabilities of the Evolution

System.

I have some exciting news for you. Work on a new source component for the

Evolution Series is ongoing as of this writing. Possessed of the unique Evolution

technologies that power the amplifier and preamplifier, this Evolution source will

expose the real advantages of the latest recording formats while taking compact

disc playback to the next level. I encourage you to audition it as soon as it is

released.

Sincerely,

Daniel D’Agostino

Chief Executive Officer

(A Letter from Dan D’Agostino continued)

continued

SECTION ONE

About Krell

This section describes the Krell Legacy, innovative Krell amplifier design and technol-

ogy, and defines key terms used in this reference.

The Krell Legacy

“I design every Krell component to set the standard

for workmanship, style, and performance.”

Dan D’Agostino

High-end audio is a demanding pursuit—an ongoing quest for excellence in

music reproduction that drives equipment manufacturers to strive for the absolute

in design and performance. With a keen understanding of this passionate drive,

Krell Industries, Inc., was founded in 1980.

Over the past 2-1/2 decades, Krell has earned a distinguished reputation for engi-

neering innovation and product excellence. The company’s history is replete with

product introductions that have deeply impacted the high-end audio industry.

The most discriminating audiophiles and product reviewers have consistently

recognized Krell components for standard-setting performance.

The Evolution One amplifier brings Krell design to a new level, setting a standard for

performance that will not soon be matched. The shear breadth of this amplifier’s

dynamic range capabilities conveys a startling realism that transcends previous

designs. Seemingly unlimited frequency response, combined with unerring accu-

racy and fortitude, extend a tradition that began with the first Krell amplifier — the

KSA-100.

The KSA–100 was the first high-power, high-current, true Class A biased stereo

power amplifier available to audiophiles. It was the first Krell product, and its

resounding success established Krell as an important new technological contrib-

utor to high-end audio.

From the KSA–100 to the present, Krell C.E.O. Dan D’Agostino has continually

“pushed the envelope” of performance in his search for greater amplifier power.

His exploration of new technologies, driven by his never-ending quest to elevate

the standard of excellence, has resulted in breakthrough audio designs. Over the

years, the Krell line of power amplifiers, including benchmark products such as the

KRS–100, KRS–200, and the Audio Standard models, has established a legacy of

unparalleled sonic performance.

The Krell product line has diversified, but Dan’s fundamental research into amplifier

design and performance remains at the core of the company’s achievements. Every

Krell component upholds the legacy, incorporating unique technologies that are the

direct result of Dan’s discoveries in audio amplification.

The Evolution One amplifiers build on the Krell legacy. They provide unprecedent-

ed linearity with the control and accuracy that only comes from superior current

capability. The sound is lively and unconstrained, in a manner that evokes live per-

formance and the true sound of instruments.

Dan D’Agostino remains committed to the development of new designs and

technologies. And the Krell legacy will continue to evolve with products that deliver

innovative engineering, perfection in build quality, and outstanding audio performance.

(SECTION ONE: About Krell continued)

continued

Revolutionary Krell CAST Technology

Current Audio Signal Transmission, termed CAST, is a revolutionary method of con-

necting analog audio components for unparalleled sonic performance. Innovative

engineering combines the new Krell CAST circuitry with existing Krell Current Mode

technology to create entire CAST systems that reproduce music with incredible range,

tonality, and precision.

The Voltage Signal Transmission

and the Traditional Audio System

Traditionally, signal is transmitted in the voltage domain between two components.

In an audio system, each component is a discrete entity with unique characteristics

that act upon the musical signal independently. Each component is unaware of the

other components in the system. The cables that connect the components also

have their own electrical characteristics, which affect the sonic presentation of the

entire system. CAST transmission unifies individual components and interconnects

into an electrically linked whole. The original signal remains unaltered from source to

speaker.

CAST Basics

Here’s how a CAST audio system works. Internally, each CAST source transfers,

or amplifies, current using Krell Current Mode circuitry. This current signal is

then output using CAST circuitry. When the signal is received by a CAST input,

Krell Current Mode circuitry again takes over until the signal reaches the loud-

speaker. By maintaining the musical signal in the current domain from beginning

to end, an entire CAST system behaves as if it is one component. With CAST,

circuit board properties and signal transmission aberrations between compo-

nents are eliminated. Cable impedances and their effects on the transmitted sig-

nal are non-existent.

How CAST and Krell Current Mode Interact

While CAST is a new method of transferring the musical signal between compo-

nents, its origin stems from Krell Current Mode, the technology developed to

transfer the musical signal within a component. CAST combined with Krell Current

Mode takes circuitry signal transmission to the next evolutionary level. In essence,

Krell Current Mode maintains the integrity of the signal within the component and

(How CAST and Krell Current Mode Interact continued)

CAST preserves the transmitted signal between components. Together, CAST and

Krell Current Mode technologies unify separate Krell components into a single

global circuit. Krell Current Mode technology enjoys bandwidth increases up to an

order of magnitude greater than their voltage based counterparts. This dramatic

increase in circuit bandwidth delivers near perfection in the audible band that typi-

cally suffers from phase distortions in voltage circuits.

CAST Cable Construction

A CAST system uses cables manufactured by Krell and other manufacturers spe-

cially licensed by Krell. Thin and flexible CAST cables are constructed with the

same build quality as other Krell components and are aesthetically matched to the

components that Krell manufactures. An all-metal body and locking connectors

with gold contacts are part of the standard no-compromise specification devel-

oped for every CAST cable made.

Evolution CAST

By employing radical current mirror circuitry, the Evolution components elevate the

CAST technology to another level. This advanced use of the technology increases

the linearity, transient speed, and bandwidth of the Evolution components while

reducing the distortion by an order of magnitude.

The Best Musical Performance

When you operate a CAST system, you will hear significant improvements in every

performance area: speed, precision, dynamic range, depth and width of the sound

stage, transient impact, tonal balance, harmonic distortion, and more. The goal for

CAST is the same company goal used for all Krell products. Krell strives for the

delivery of the best performance of a musical event for you, using the full expres-

sion of technology to date.

(SECTION ONE: About Krell continued)

Andere Handbücher für Evolution

Inhaltsverzeichnis

Andere Krell Industries Verstärker Handbücher

Krell Industries

Krell Industries EVOLUTION 222 Kurzanleitung

Krell Industries

Krell Industries Class A Series Bedienungsanleitung

Krell Industries

Krell Industries 300 Bedienungsanleitung

Krell Industries

Krell Industries PHANTOM II Kurzanleitung

Krell Industries

Krell Industries PAM-7 Bedienungsanleitung

Krell Industries

Krell Industries Evolution 302 Bedienungsanleitung

Krell Industries

Krell Industries Evolution Kurzanleitung

Krell Industries

Krell Industries Foundation 4K Kurzanleitung

Krell Industries

Krell Industries KAV-300IL Bedienungsanleitung

Krell Industries

Krell Industries Power Amplifiers MDA-300/500 Kurzanleitung

Krell Industries

Krell Industries EVOLUTION 222 Kurzanleitung

Krell Industries

Krell Industries KAV-280p Bedienungsanleitung

Krell Industries

Krell Industries 200c Bedienungsanleitung

Krell Industries

Krell Industries KRC-HR Kurzanleitung

Krell Industries

Krell Industries KAV-300I Kurzanleitung

Krell Industries

Krell Industries EVOLUTION TWO MONAURAL PREAMPLIFIER Kurzanleitung

Krell Industries

Krell Industries S-1500 Bedienungsanleitung

Krell Industries

Krell Industries Audio + Video Standard Surround... Kurzanleitung

Krell Industries

Krell Industries PAM-1 Bedienungsanleitung

Krell Industries

Krell Industries S-300i Bedienungsanleitung

Krell Industries

Krell Industries Power Amplifier KAV-150a Kurzanleitung

Krell Industries

Krell Industries KSA-i400 Kurzanleitung

Krell Industries

Krell Industries K-300p Kurzanleitung

Krell Industries

Krell Industries Preamplifier PAM-5 Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
