KAC900

TABLE OF CONTENTS

INTRODUCTION...........................................................................................................................................3

COMPONENT LIST.....................................................................................................................................4

PRODUCT SAFETY.................................................................................................................................... 5

OPERATING INSTRUCTIONS.................................................................................................................6

MAINTENANCE AND CLEANING..........................................................................................................9

STORAGE.........................................................................................................................................................9

TROUBLESHOOTING................................................................................................................................9

TECHNICAL DATA ....................................................................................................................................10

INTRODUCTION

Dear Customer,

Thank you for buying this Kress Commercial product. We are dedicated to developing

high quality products to meet your commercial landscaping requirements.

The Kress brand is synonymous with premium quality service. Over the years of your

product's life, if you have any questions or concerns about your product, please

contact your dealer or our Customer Service Team for assistance.

We are condent you will enjoy working with your Kress product for years to come.

INTENDED USE

This harness allows the capability to connect to select Kress 60V handheld tools,

like a string trimmer, edger, or hedge trimmer, this harness gives you the exibility to

tackle big jobs and allowing longer runtime for larger jobs

COMPONENT LIST

1. BATTERY ADAPTOR

2. CABLE

3. CHEST BUCKLE

4. SHOULDER STRAP

5. WAIST BUCKLE

6. BATTERY MOUNTING BASE

7. LOAD LIFT STRAP

8. CABLE MANAGEMENT FASTENER

9. FRAME HEIGHT ADJUSTMENT RELEASE

10. HEIGHT ADJUSTMENT SYMBOL

11. WEIGHT KIT*

12. BATTERY RELEASE BUTTON

Not all the accessories illustrated or described are included in standard delivery.

ORIGINAL INSTRUCTIONS

PRODUCT SAFETY

GENERAL POWER TOOL

SAFETY WARNINGS

WARNING Read all safety warnings,

instructions, illustrations and speciﬁcations

provided with this power tool.

Failure to follow all

instructions listed below may result in electric shock,

re and/or serious injury.

Save all warnings and instructions for future

reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-

operated (cordless) power tool.

SYMBOLS

To reduce the risk of injury, user must

read instruction manual

Warning

Remove battery from the harness

before carrying out any adjustment,

servicing or maintenance.

Waste electrical products must

not be disposed of with household

waste. Please recycle where

facilities exist. Check with your local

authorities or retailer for recycling

advice.

OPERATING INSTRUCTIONS

NOTE: Before using the tool, read the

instruction book carefully.

WARNING: This battery harness can only be

used with Kress cordless handheld tools.

BEFORE OPERATION

Note: Check the Kress batteries carefully to make

sure that no parts are damaged or missing. If any

damage occurred, please contact Service Agent.

OPERATION

Adjusting height of Frame(See Fig. A1,A2)

Press

Note: It is possible to adjust frame height based on

user height &weight. The Kress harness features

three height(S/M/L) for your choice.

1. Depress the button and release the slider from

the frame;

2. Find the suitable height, match the "-"symbol

as shown, t the slide and lift up to nish the

assembly, and you should hear a "click".

Install/Remove the battery pack (See Fig.

B1, B2,B3)

1. Align the battery pack to the battery mounting

base, then slide it into the base to install the battery.

2. Press the battery pack release button, then lift the

battery pack along the mounting base to remove the

battery.

Fix the cable into harness positions.(See

Fig C)

It is suggested to x the cable into the cable clips

during operation so as to avoid obstrucions by

cluttered cables.The cable clips are designed along

the shoulder belt and waist belt, which provides you

with two different ways to organize the cables.

Adjust the harness (See Fig. E1, E2,E3)

1. Snap the waist buckle(d). Adjust the length of

waist strap(e) in order to make sure it is securely

positioned in your hips.(See Fig E2)

2. Tighten the shoudler strap(a)and remember to

leave a small gap over the shoulder to distribute

weight of battery over shoulders to balance weight.

(See Fig E3)

3. Snap the chest buckle(b) and adjust chest strap(c)

before work .(See Fig E3)

WARNING: Do not wear other shoulder straps when

using this backpack harness.

Connect the harness with your

machine(See Fig F1, F2)

1. Insert the battery adaptor into the Kress cordless

handheld tool. Follow the instructions in the tool’s

manual to start the tool.Remove the adaptor from

the tool after use.

NOTE: For better weight distribution, a weight kit

is supplied with the backpack harness.

1. LIft the ring and rotate the screw in a

counterclockwise direction, then push the weight kit

along the battery adaptor.(See Fig F2)

2. Rotate the screw in a clockwise direction to nish

the assembly of weight kit and battery adaptor. Then

insert the battery adaptor into the Kress handheld

tools.(See Fig F3)

WARNING: Before connection, make sure your

machine is turned off. When operating, wear

protective gloves.

REMOVE AND FIT HARNESS

Disassembly and assembly of the waist belt.

(See Fig G1,G2)

1. Open the velcro and remove the belt from the frame

ap.(See Fig G1)

2. Insert the frame ap into the pocket on the belt.

Rotate the belt until the whole of the frame ap is in

the pocket. Secure with the velcro tab.(See Fig G2)

Disassembly and assembly of the shoulder belt.

(See Fig H1,H2)

Press

1. Press the button and release sliders from frame.

(See Fig H1)

2.To remove the shoulder strap, push the strap

through the slot to release the toggle. Turn the

toggle triangle 90o and pass back through the slot to

remove.(See Fig H2)

3. Match the "-" symbol between the frame and the

slider, then lift the slider up to assemble the harness.

(See Fig I1)

Note: The harness is designed with three height

(S/M/L) for you to choose the suitable height.

4.Turn the toggle so that it lies 90oalong the strap.

Pass the toggle and strap through the slot in the

frame. Release the toggle and pull back towards the

frame. Ensure that the shoulder strap is not twisted.

(See Fig I2)

MAINTENANCE AND

CLEANING

Use soft brush to clean the debris on the surface of

harness. Never use water or chemical cleaners to

clean your harness. Wipe off any moisture with a soft

dry cloth as moisture can cause a shock hazard.

WARNING:Remove the battery and adaptor from

the harness before carrying out any adjustment,

servicing or maintenance.

STORAGE

Always store your harness in an enclosed space that

is inaccessible to children. Keep all working controls

free of dust. Keep away from corrosive agents. Do

not place any objects on top of the harness and put

the harness on the at oor.

TROUBLE SHOOTING

The following table gives problems and actions that

you can perform if your machine does not operate

correctly.

WARNING: Switch the machine off

and remove the battery prior to any

troubleshooting.

Problem Possible cause Solution

The tool

fails to

operate

1. Battery

not (properly)

inserted

2. No electrical

contact between

the battery pack

and backpack

harness

3. The battery

pack is depleted

4. No electrical

contact between

the adaptor and

tool

1. Properly

insert battery

into backpack

harness.

2. Remove the

battery pack

and check the

contact. Then

reinstall the

battery pack.

3. Charge the

battery pack.

4. Disconnect

the adaptor

from the tool,

then reconnect

them.

TECHNICAL DATA

KAC900

Suitable battery pack Kress 60V battery pack (KAC804 KAC810)

Weight (Without battery) 2.25 kg

We recommend that you purchase your accessories from the same Dealer that sold you the tool. Refer to the

accessory packaging for further details. Your Dealer can assist you and offer advice.
