KTI Networks KFC-241 Bedienungsanleitung

KFC-241

Industrial

10/100BASE-T to 100BASE-FX

Media Converters

Installation Guide

DOC.110516

-1-

or by any means or used to make any directive work (such as translation or transformation) without permission

from KTI Networks Inc.

KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to

time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change.

For more information, contact:

United States KTI Networks Inc.

P.O. BOX 631008

Houston, Texas 77263-1008

Phone: 713-2663891

Fax: 713-2663893

E-mail: [email protected]

URL: http://www.ktinet.com/

International Fax: 886-2-26983873

E-mail: [email protected]

URL: http://www.ktinet.com.tw/

-2-

The information contained in this document is subject to change without prior notice.

TRADEMARKS

Ethernet is a registered trademark of Xerox Corp.

FCC NOTICE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) This device must accept any interference received,

including the interference that may cause undesired operation.

CE NOTICE

Marking by the symbol “CE” indicates compliance of this equipment to the EMC directive of the European

Community. Such marking is indicative that this equipment meets or exceeds the following technical

standards:

EMC Class A

EN 61000-6-3:2007 IEC 61000-6-3:2007

EN 55022:2006/A1:2007 CISPR 22:2005 Class A

EN 61000-3-2:2006 IEC 61000-3-2:2005

EN 61000-3-3:2008 IEC 61000-3-3:2008

EN 55024:1998/A1:2001/A2:2003 CISPR 24:1997

EN 61000-4-2:2009 IEC 61000-4-2:2008

EN 61000-4-3:2006/A1:2008 IEC 61000-4-3:2006

EN 61000-4-4:2004 IEC 61000-4-4:2004

EN 61000-4-5:2006 IEC 61000-4-5:2005

EN 61000-4-6:2009 IEC 61000-4-6:2008

EN 61000-4-8:1993/A1:2001 IEC 61000-4-8:1998/A1:2000

EN 61000-4-11:2004 IEC 61000-4-11:2004

-3-

-4-

Table of Contents

1. Introduction......................................................................................................................................................5

1.1 Features.................................................................................................................................6

1.2 Specifications.........................................................................................................................7

1.3 Model Specifications............................................................................................................11

1.4 Special Functions.................................................................................................................11

2. Installation......................................................................................................................................................13

2.1 Unpacking............................................................................................................................ 13

2.2 Safety Cautions.................................................................................................................... 13

2.3 DIN-Rail Mounting................................................................................................................14

2.4 Mounting on a Plane Surface...............................................................................................18

2.5 Applying Power.................................................................................................................... 21

2.6 Making Copper Port Connection.......................................................................................... 22

2.7 Making Fiber Port Connection..............................................................................................23

3. LED Indicators...............................................................................................................................................24

3.1 States and Indications.......................................................................................................... 24

Appendix. On-board Configuration.................................................................................................................25

1. Introduction

The industrial 10/100BASE-TX to 100BASE-FX media converter series provides industrial strength Ethernet

copper-to-fiber media conversion, allowing for 10Base-T-100Base-FX or 100Base-TX-100Base-FX over

multi-mode or optional single-mode fiber optical media.

In addition to the basic media conversion functions, the converters also provide some special functions to

enhance the flexibility for wide application needs as follows:

AUTO-NEGO FUNCTION

The copper port is featured this function which performs a negotiation process for the speed and duplex

configuration with the connected device automatically when each time a link is being established.

AUTO-CROSS FUNCTION

The copper port is featured this function that allows to auto-detect the twisted-pair signals and adapts itself to

form a valid MDI to MDI-X connection with the remote connected device automatically.

FAR END FAULT FUNCTION

The fiber port is facilitated with this function, which conforms to IEEE 802.3u 100BASE-FX specifications.

When the port detects a link failure on its receiving circuitry, it will send out an FEFI (Far End Fault Indication)

signal to the remote connected device to indicate a remote fault is detected. It also is capable to receive FEFI

signal sent from the remote link partner. Upon receiving an FEFI signal, it indicates a link failure occurred on

the transmitting path. This function allows the converter to report a fiber link fault even when a link failure

occurred on transmitting fiber cable.

SMART-FORWARDING FUNCTION

-5-

The converter uses store-and-forward mechanism for packet forwarding normally when both media ends

-6-

operate at different speed, but switches to direct conversion automatically and with the least latency when both

media ends operate at the same speed.

LINK FAULT PASS THROUGH FUNCTION

The function allows the link fault status passes through from one media end to another media end transparently.

INDUSTRIAL ENHANCEMENT

For industrial environment, the converters are designed with the following enhanced features exceeding that of

commercial media converters:

zHigh and wide operating Temperature

zWide operating voltage range for DC power input

zPower input interfaces: Terminal block for industrial power supply and DC jack for typical power adapter

zDIN-Rail mounting support for industrial enclosure

zScrew plane mounting support for industrial enclosure

zIndustrial-rated Emission and Immunity performance

1.1 Features

zConvert speed and media type

zSupport full wire speed conversion

zSupport 10Mbps and 100Mbps speed on the copper connections

zAuto MDI/MDI-X detection function on the copper port

zAuto-negotiation function on the copper port

zLink fault pass through function

zPlug and play with no complicated configuration

zTransparent conversion to 802.1Q VLAN tagged packets

zFar End Fault function on the fiber port

zSupport wide range of fiber options on the fiber port

zLow power consumption

zTwo power interface types: screw terminal block and DC jack

zWide operating voltage input range

zSupport DIN rail mounting

zSupport plane mounting

zHigh and wide operating temperature range

zIndustrial-rated Emission and Immunity performance

1.2 Specifications

This figure shows the important components of the converters:

Model KFC-241-L

Model KFC-241-H

-7-

-8-

Copper Port (Twisted-Pair Interface)

Connector Shielded RJ-45

Pin Assignments Auto MDI/MDI-X detection

Signal Compliance IEEE 802.3 10BASE-T, 802.3u 100BASE-TX

Data Speed 10Mbps or 100Mbps

Duplex Mode Half-duplex or Full-duplex

Configuration Auto-negotiation capable for speed and duplex

Cable Types 10Mbps - Category 3, 4, or 5 UTP

100Mbps - Category 5 UTP

Supported Link Distance Up to 100 meters

FX Port (Fiber Optic Interface)

Signal Compliance IEEE 802.3u 100BASE-FX

Connector SC, ST, or Single SC (model dependent)

Data Speed 100Mbps

Duplex Mode Full-duplex and optional half duplex

Cable Types Multimode (MMF) - 50/125, 62.5/125μm

Single mode (SMF) - 9/125μm

Supported Link Distance MMF up to 2km

SMF, single SMF (model dependent)

Eye Safety compliance IEC825 Class 1

DC Power Input

KFC-241-L

Interfaces Screw-type Terminal Block 3P (TB-3P)

DC Jack (-D 6.3mm /+D 2.0mm)

Operating Input Voltages +4.5VDC ~ +50VDC

Power Consumption 1.6W @+7.5VDC input

1.6W @+12VDC input

2W @+48VDC input

KFC-241-H

Interface Screw-type Terminal Block 3P (TB-3P)

Operating Input Voltage +110VDC

Power Consumption 2.9W @+110VDC input

-9-

LED Indicators

LED Name Display function

PWR Power status

LINK Link status

100M Copper port operating speed

OL Fiber port optical link

Mechanical

Dimension (base) KFC-241-L - W 34mm x D 49mm x H 56mm

KFC-241-H - W 45.5mm x D 49mm x H 56mm

Weight KFC-241-L - 132g

KFC-241-H - 164g

Housing Enclosed metal with no fan

Mounting Support DIN-rail mounting, Plane mounting

Environmental

Operating Temperature Ambient -20oC ~ 70oC

Storage Temperature -30oC ~ 85oC

Relative Humidity 5% ~ 90%

Basic Information

Forwarding Throughput Full wire speed at 100M full duplex

10Mbps - 14,880pps at 64-byte packets

100Mbps - 148,800pps at 64-byte packets

Packet Types Transparent and no modification for

- IEEE 802.3 standard packets

- IEEE 802.1Q VLAN tagged packets

Packet Length Up to 1600 bytes under 100Mbps-10Mbps conversion

No limit under 100Mbps to 100Mbps conversion

Flow Control Back-pressure for half-duplex mode

802.3x pause-frame base for full duplex mode

Certificate

FCC Part 15 Class A

CE/EMC EMI EN50081-1 Class A

EMS EN55024

CE/LVD Safety EN 60950

-10-

EN 50081-1:

EN55022 CISPR Class B

EN61000-3-2 Device <75W

EN61000-3-3 Clause 5

EN 55024 Severity Level

IEC 61000-4-2 ESD Test Contact +/-6KV/Air +/-8KV

IEC 61000-4-3 RS Test Power/Data Ports Level 1, 2, 3

IEC 61000-4-4 EFT/Burst Test DC IN +/-1KV/Data Ports +/-0.5KV

IEC 61000-4-5 Surge Test DC IN +/-0.5KV/Data Ports +/-1KV

IEC 61000-4-6 CS Test DC IN Level 3

IEC 61000-4-8 PFMF Test Continuous, 100A/m, XY, 30 sec.

IEC 61000-4-11 Voltage Int. Dips Interruption 100% 250 periods

Dips 30% 25 periods

Dips 60% 0.5 period
