Kyocera Mita FS-C5016N Bedienungsanleitung

FS-C5016N

Color Page Printer

Quick Reference Guide

Kyocera Mita Corporation

2-28, 1-Chome, Tamatsukuri, Chuo-ku

Osaka 540-8585, Japan

Phone: (06) 6764-3555

2003.3

7KKTA80E++RX

Printed in Japan

FS-C5016N

Notice

NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY

IMPROPER INSTALLATION OF THE PRODUCT.

SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE

PRINTER’S NATIVE MODE OR ONE OF ITS EMULATION

MODES.

The information in this manual is subject to change without notifi-

cation. Additional pages may be inserted in future editions. The

user is asked to excuse any technical inaccuracies or typographi-

cal errors in the present edition.

No responsibility is assumed if accidents occur while the user is

following the instructions in this manual. No responsibility is

assumed for defects in the printer’s firmware (contents of its read-

only memory).

This manual, any copyrightable subject matter sold or provided

with or in connection with the sale of the page printer, are pro-

tected by copyright. All rights are reserved. Copying or other repro-

duction of all or part of this manual, any copyrightable subject

matter without the prior written consent of Kyocera Mita Corpora-

tion is prohibited. Any copies made of all or part of this manual,

any copyrightable subject must contain the same copyright notice

as the material from which the copying is done.

The names of actual companies and products mentioned herein

may be the trademarks of their respective owners.

FSC5016N_QG.fm 0 ページ２００３年３月２４日　月曜日　午後１時４７分

FS-C5016N

Quick Reference

Guide

FSC5016N_QG.fm 1 ページ２００３年３月２４日　月曜日　午後１時４７分

Contents

Guide to the information about the printer .................................3

Understanding the Error Messages ...........................................4

Loading Paper .........................................................................14

Clearing Paper Jams ...............................................................22

Jam at the Paper Cassette .........................................23

Jam at the Paper Transfer Unit ...................................23

Jam at the Rear Cover ................................................25

Jam at the MP Tray .....................................................26

Toner Container Replacement ................................................27

Replacing the Toner Container ...................................28

Replacing the Waste Toner Box .................................32

Cleaning the Printer .................................................................35

Cleaning the Main Charger Unit ..................................35

Cleaning the Paper Transfer Unit ...............................40

FSC5016N_QG.fm 2 ページ２００３年３月２４日　月曜日　午後１時４７分

Guide to the information about the printer

The following documentation and CD-ROM are sup-

plied:

Installation Guide This guide provides information on installing

the printer before starting to use.

Quick Reference

Guide (This booklet)

This guide provides common information

about the printer such as loading paper,

understanding messages, etc.

Operation Guide This guide is supplied as an online manual

(PDF) in the CD-ROM. This guide fully details

the information on the printer features, hard-

ware, troubleshooting, printer driver handling,

etc.

KX Printer Drivers

Operation Guide

This guide is supplied as an online manual

(PDF) in the CD-ROM. This guide explains

how to install and configure the printer driver.

Software and Docu-

ment CD-ROMs

These CDs include the printer software for

Kyocera Mita printers such as printer drivers,

network printer monitors, and various soft-

ware utilities. Also, these CDs include the

Operation Guides and other documents.

Web site The latest versions of printer drivers and utili-

ties are available for downloading at:

http://www.kyoceramita.com/download/

FSC5016N_QG.fm 3 ページ２００３年３月２４日　月曜日　午後１時４７分

Understanding the Error Messages

These messages appear on the printer’s message dis-

play when the printer needs the operator’s attention.

For more details, refer to chapter 4 of the Operation

Guide.

Message Corrective Action

Add paper MPTray

The paper has run out in the paper source

displayed. Supply paper according to the

paper source (paper cassettes, MP tray,

optional paper feeders, or optional enve-

lope feeder).

This message is displayed alternately with

messages indicating the printer status,

such as, Ready, Please wait, Pro-

cessing, Waiting, and Form Feed

Time Out. If the number of copies to

print is 2 or more, only the Add paper

message is displayed.

Call service

F###:

F### represents a controller error (#=0, 1,

2, ...). Call a service. The printer does not

operate when this message is displayed.

Call service

####:0123456

#### represents a mechanical error (#=0,

1, 2, ...). Call a service. The printer does

not operate when this message is dis-

played. The total number of pages printed

is also indicated, e.g. 0123456.

Call service

Person F0

This message means an error in data

communications between the printer con-

troller and the operator panel. Call a ser-

vice.

Cassette #

not loaded

The corresponding paper cassette is not

installed. Install the cassette. The cassette

number can be 1 (topmost) to 4 (bottom).

FSC5016N_QG.fm 4 ページ２００３年３月２４日　月曜日　午後１時４７分

Check waste

toner box

This message warns following two cases.

Install the new waste toner box.

• The waste toner box is not installed.

• The waste toner box is almost full.

Clean printer

Press GO

Please clean the inside of the printer. See

Cleaning the Printer on page 35.

This message will be displayed when

replacing the toner container after the

message Replace toner C, M, Y, Kis

displayed. After cleaning the inside of the

printer, press the GO key and the printer

will be ready for printing.

If Auto Continue is set to On, printing will

be automatically resumed after a preset

period of time. For details on Auto Con-

tinue, refer to chapter 3 of the Operation

Guide.

Close duplexer

rear unit

The rear unit of the optional duplexer is

open. Close the duplexer rear unit.

Close duplexer

top cover

The top cover of the optional duplexer is

open. Close the duplexer top cover.

Close paper

transfer unit

The paper transfer unit is open. Close the

paper transfer unit.

left cover

The left cover of the printer is open. Close

the printer left cover.

rear cover

The rear cover of the printer is open. Close

the printer rear cover.

Message Corrective Action

FSC5016N_QG.fm 5 ページ２００３年３月２４日　月曜日　午後１時４７分

top cover

The top cover of the printer is open. Close

the printer top cover.

Duplex disabled

Press GO

You attempted to print with a paper size

and paper type that cannot be used for

duplex printing. Press the GO key to print

onto one-side of the paper only.

Face-down tray

paper full

The face-down tray has become full

(approx. 250 pages). You must remove all

printed pages from the face-down tray.

When the printer detects that the face-

down tray is empty again, the printer will

continues printing into the face-down tray.

File not found

Press GO

You have attempted to print a job that is

not contained in the specified virtual mail-

box, or the specified virtual mailbox is not

found.

If Auto Continue is set to On, printing will

be automatically resumed after a preset

period of time. For details on Auto Con-

tinue, refer to chapter 3 of the Operation

Guide.

Format error

Hard disk

The hard disk installed in the printer is not

formatted, and therefore cannot be read or

written. To format the hard disk, follow the

procedure in the Installation Guide of the

hard disk.

Format error

Memory card

The memory card inserted in the printer is

not formatted, and therefore cannot be

read or written. To format a memory card,

follow the procedure in chapter 3 of the

Operation Guide.

Message Corrective Action

FSC5016N_QG.fm 6 ページ２００３年３月２４日　月曜日　午後１時４７分

Hard disk err

Press GO

A hard disk error has occurred. Look at the

error code given in place of ## and refer to

chapter 4 of the Operation Guide. To ignore

the hard disk error, press the GO key.

I/F occupied

This message is displayed when you

attempt to use the printer’s operator panel

to change the environmental settings on

the interface from which data are presently

being received.

ID error

The user ID entered for a private job, or a

stored job is not correct. Check the user ID

that you specified on the printer driver.

Insert the same

memory card

You have inserted the wrong memory card

when the Insert again message was

displayed. Remove the wrong memory

card from the printer’s memory card slot

and insert the correct memory card. The

printer again reads it from the beginning of

the data.

Install MK

Replace Maintenance Kit which is dis-

played on the message display. Replace-

ment of the maintenance kit is necessary

at every 200,000 images of printing and

requires professional servicing. Contact

your Kyocera Mita dealer.

Message Corrective Action

FSC5016N_QG.fm 7 ページ２００３年３月２４日　月曜日　午後１時４７分

KPDL error ##

Press GO

Current print processing cannot continue

because of occurrence of KPDL error

which is categorized by ##. To print out an

error report, display > Print KPDL

err(s) from the menu system, and select

On. Press the GO key to resume printing.

You can abandon printing by the CANCEL

key.

If Auto Continue is set to On, printing will

be automatically resumed after a preset

period of time. For details on Auto Con-

tinue, refer to chapter 3 of the Operation

Guide.

Load Cassette #

(

)

(

PLAIN

)

†

The paper cassette matching the paper

size and paper type of the print job is

empty. Load paper into the paper cassette

indicated by #. Press the GO key to

resume printing.

If you want to print from a different paper

source, press the Vor Ukey to display

Use alternative and you can change

the source for paper feeding. After select-

ing a paper source and pressing the

MENU key, Paper Handling >

appears. By pressing the Ukey, the paper

type settings menu appears. After setting

the correct paper type, press the ENTER

key and printing starts. For details, see

chapter 3 of the Operation Guide.

Message Corrective Action

FSC5016N_QG.fm 8 ページ２００３年３月２４日　月曜日　午後１時４７分

Andere Handbücher für FS-C5016N

Inhaltsverzeichnis

Andere Kyocera Mita Drucker Handbücher

Kyocera Mita

Kyocera Mita FS-C5016N Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS-9100DN Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-6020 Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-P4845w Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1010 Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-6020 Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS-C5016N Bedienungsanleitung

Kyocera Mita

Kyocera Mita S-9100DN Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-C8008DN Series Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1900 Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1010 Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-P4845w Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1010 Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS-C5016N Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-4530 Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-1505 Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1800+ Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-1500 Bedienungsanleitung

Kyocera Mita

Kyocera Mita KM-P4850w Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS 8000C - Color Laser Printer Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-1000+ Bedienungsanleitung

Kyocera Mita

Kyocera Mita Ecosys FS-6020 Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS-1000 Bedienungsanleitung

Kyocera Mita

Kyocera Mita FS-9500DN Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
