La Crosse WT470 Bedienungsanleitung

Model: WT470 www.lacrossetechnology.fr Page | 1

Model: WT470

Quick Setup Guide

BLUETOOTH ALARM CLOCK

BUTTONS

FRONT

VIEW

Battery

Compartment

2 “AA” LR6

USB Port

Output 1Amp

BACK

VIEW

BUTTONS

FRONT

VIEW

AC Power Jack

Audio Input

Model: WT470 www.lacrossetechnology.fr Page | 2

Get Started

Step 1: Insert 5 volt AC adapter into the wall then into the back of the

alarm clock.

Step 2: Insert 2 AA LR6 Alkaline batteries (not included) into the alarm

clock. Observe the correct polarity.

Restart: If there is no indoor temperature data after 60 seconds, unplug

the AC adapter and remove batteries from the alarm clock, press any

button 20 times. After 15 minutes, return to Step 1 above.

LCD Features

Set Time, Date, Temperature Unit, Language

1. Hold the REG button to enter time set mode.

2. Press the +or -buttons to adjust values.

3. Press the REG button to confirm adjustments and move to the next

item.

4. Press the SNOOZE/LUM. button at any time to exit.

TIME SET ORDER:

1. Beep ON/OFF

2. Time format (24h/12h)

3. Hour

4. Minutes

5. Year

6. Month

7. Date

8. Date/Month Format (D/M or M/D)

9. Fahrenheit/Celsius

Weekday Date/Month

Moon

Phase

Indoor

Humidity

Indoor

Temperature

Indoor

Temperature

Two Alarms

Model: WT470 www.lacrossetechnology.fr Page | 3

Press the SNOOZE/LUM. button at any time to exit, or wait 20 seconds

without pressing buttons to return to the normal time display.

Model: WT470 www.lacrossetechnology.fr Page | 4

USB Charging Port, Audio IN

Charge a smart phone, camera or other devices when the alarm clock is

plugged into a power outlet with the included 5V AC adapter.

Note: This is a power-output charging port (SORTIE). It does not supply

power to the alarm clock.

Connect your external device’s USB charging cable

(not included) to the USB charging port.

Charging times will vary.

USB Power Output: 1A maximum current. Charge

1A devices or devices that are self-regulating.

3.5mm AUDIO IN, when audio in, the BT will

disconnect

Bluetooth Operation

1. Press and hold BLUETOOTH®POWER to turn on the Bluetooth

function.

2. Activate the Bluetooth® function on your mobile

device to pair with the clock.

3. The purple LED will flash until there is connection

with your mobile device. Once there is connection,

the purple LED will change to blue and will be solid.

4. Use the ▲ or ▼ buttons on top to adjust the volume.

5. If a phone call is made or received, the Bluetooth®

connection will be temporarily interrupted. It will

automatically reconnect after the call.

6. Press Bluetooth Power to pause and repress and continue to

play

7. Press and hold the BLUETOOTH®POWER button again to turn off

BT.

Note: If the clock is unplugged briefly and is plugged in again, the clock

may lose Bluetooth connectivity.

Adjust Backlight HI/LOW/OFF

For a constant backlight you must use the AC adapter.

When using A/C power:

Press the SNOOZE/LUM. button to adjust the backlight between bright,

dim and off.

Model: WT470 www.lacrossetechnology.fr Page | 5

When using battery power only:

Press the SNOOZE/LUM. button for 10 second backlight

Time Alarm Options-Single, M-F or Weekend

Your clock has two separate

alarms (1& 2).

Each alarm can be set one time

(Day Alarm), Monday-Friday, or

for Weekends.

Set Time Alarm 1 & Alarm 2

Setting the alarm and activating the alarm are separate actions.

Alarm Time setting order: 1. Hours, 2. Minutes

Alarm 1:

1. Hold the ALARM button for 3 seconds to enter alarm

time set mode.

2. Press the +or -buttons to adjust the alarm hour.

3. Press the ALARM button to confirm and set the minutes.

4. Press the +or -buttons to adjust the alarm minutes.

5. Press the ALARM button to confirm and set the ALARM TYPE

6. Press the +or -buttons to choose alarm type

7. Press the ALARM button to confirm and set the ALARM SOUND

8. Press the ALARM button to confirm.

Alarm 2:

Repeat steps 1-8 using ALARM 2 button.

ALARM1 HOUR ALARM1 MINUTES

Alarm Type

Words

One Time

ALARME

Monday-Friday

LUN-VEN

Weekend only

WEEKEND

Model: WT470 www.lacrossetechnology.fr Page | 6

ALARM1 TYPE ALARM1 SOUND

Deactivate Time Alarm 1 or Time Alarm 2

Press and release the ALARM 1 or ALARM 2 button to deactivate the

specific alarm.

Snooze (Silences Alarm Temporarily)

When alarm sounds, press the SNOOZE/LUM. button to silence

either alarm for 10 minutes.

Note: The alarm sounds for 2 minutes and then shut off completely.

Low Battery Icon

When the icon is displayed below the time,replace

batteries in the alarm clock.

MOON PHASE

The moon phase is based on the lunar calendar and the year, month and

date set. Most Internet moon phase calculations are based on the lunar

calendar.

ALARM CLOCK CARE AND MAINTENANCE

Do not mix old and new batteries

Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

Low

Battery

Icon

Model: WT470 www.lacrossetechnology.fr Page | 7

Always purchase the correct size and grade of battery most suitable

for intended use.

Replace all batteries of a set at the same time.

Clean the battery contacts and also those of the device prior to

battery installation.

Ensure the batteries are installed with correct polarity (+and -).

Remove batteries from equipment which is not to be used for an

extended period of time.

Remove expired batteries promptly.

Do not expose to extreme temperature, vibration or shock.

Clean with a soft damp cloth. Do not use solvents or scouring

agents.

The alarm clock is not a toy. Keep it out of reach of children.

The alarm clock is not to be used for medical purpose or for public

information. It is intended for home use only.

The specs of this alarm clock may change without prior notice.

Improper use or unauthorized opening of housing voids warranty.

If the alarm clock is not working properly, change the batteries and/or

check the A/C adapter connection.

SPECIFICATIONS

Indoor:

Temperature Range: +32°F to +122°F (0°C to 50°C)

Humidity Range: 1% to 99% RH

Power:

Alarm Clock: A/C power adapter (included) 5.0V

HX18-0502000-AG

Battery backup; 2-AA, IEC, LR6 batteries (not included)

Battery Life:

Battery Backup: Battery life is over 24 months when using the

AC adapter for primary power

USB:

Output: 1 Amp maximum current (charging cable not

included)

Dimensions:

Alarm Clock: 143 x 75 x 70 mm (5.63” L x 2.95" D x 2.76 " H)

Model: WT470 www.lacrossetechnology.fr Page | 8

LIABILITY DISCLAIMER

The electrical and electronic wastes contain hazardous substances.

Disposal of electronic waste in wild country and/or in unauthorized

grounds strongly damages the environment.

Please contact your local or/and regional authorities to retrieve the

addresses of legal dumping grounds with selective collection.

All electronic instruments must from now on be recycled. User shall

take an active part in the reuse, recycling and recovery of the

electrical and electronic waste.

The unrestricted disposal of electronic waste may do harm on public

health and the quality of environment.

As stated on the gift box and labeled on the product, reading the

“User manual” is highly recommended for the benefit of the user.

This product must however not be thrown in general rubbish

collection points.

The manufacturer and supplier cannot accept any responsibility for

any incorrect readings and any consequences that occur should an

inaccurate reading take place.

This product is designed for use in the home only as indication of the

temperature.

This product is not to be used for medical purposes or for public

information.

The specifications of this product may change without prior notice.

This product is not a toy. Keep out of the reach of children.

No part of this manual may be reproduced without written

authorization of the manufacturer.

R&TTE Directive 1999/5/EC

Summary of the Declaration of Conformity : We hereby declare that

this wireless transmission device does comply with the essential

requirements of R&TTE Directive 1999/5/EC.
