Flail Mowers

Features and Benefits

Designs, speciﬁcations, features and information are subject to change without notice.

FM20

Features Benefits

Key widths 60”, 72”

6 1/4” Right,

centered offset hitch The two position hitch for offsetting the mower allows closer cutting along buildings, fences

or roadsides.

Gearbox HP rating 25 - 55 HP to fit a large array of tractors

3/4” – 4” Cutting height Low cutting height allows for scalping in grasses such as Bermuda prior to overseeding.

Gearbox Warranty One year on all components

1” Cutting capacity Can cut small saplings.

4 1/4” Rotor diameter Large rotor diameter protects against obstructions.

Reverse rotor rotation Reverse rotation brings the cut grass up and over the rotor for a cleaner discharge.

Cat. 4 driveline with over-

running clutch Upon disengaging the PTO, the over-running clutch allows the driveline to quit turning, while

the clutch yoke, gearbox and rotor shaft slow down by their own inertia.

3 - “B” Section belts “B” Section belts fit snug in the sheaves, and the multiple belts ensure positive transfer of

power.

3 Fine cut knives per hanger Helps eliminate the peak and valley cut left with many fine cut blade arrangements.

High knife tip speed Knife tip speed of 8,705 fpm for cleaner cut.

Adjustable rear panel Rear panel adjusts to allow stronger discharge of material. Also aids in cleaning underside

of deck.

Bafﬂes on the top inside of the

deck Keeps the cut material from clumping together, ensuring an even distribution of clippings.

Height adjusting roller Rear height adjusting roller with greaseable bearings and tapered ends to prevent gouging

during turns.

Scrapers Standard scraper on rear height adjusting roller.

Flail Mowers

309-100F

4/08/08
