Remote Controlled Magnetic Pan Tilt Base Rotates and Tilts with

Mounting Plate

(4) 200 lb Magnets

Instruction Manual

Thank you for your purchase of the Larson Electronics PTB-1-M.

WARNING:

READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY

RELEVANT LOCAL BUILDING CODES.

•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL

SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.

•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP

OBJECTS. SUITABLE FOR DAMP LOCATIONS.

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE PTB-1-M MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL

CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY ALICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING. RISK

OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOTINSTALLED PROPERLY. RISK

OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

WARNING:

USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE. THIS LINE

CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT

READILY AVAILABLE.

IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO

PERSONNEL.

PERIODIC INSPECTION OF THE CORD IS NECESSARY.

THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,

THE CORD MUST BE REPLACED BEFORE RESUMING USE.

The PTB-1-M from Larson Electronics is an Industrial Grade Magnetic Pan Tilt Base that is designed to provide wireless

and hard wired remote control of lights and equipment. This remote control unit allows operators to rotate through from

0° to 355°, tilt from -60° to +30°, and mount equipment weighing up to 100 lbs. The PTB-1-M features one 200 lb magnet

on each corner of the base for a total of four 200 lb magnets for quick and easy temporary mounting of the base and

attached equipment.

Magnetic Warning

•PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.

ELECTROMAGNETIC FIELDS INCLOSE PROXIMITY TOHEART PACEMAKER COULD CAUSE

PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.

•KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING ASINJURY COULD OCCUR.

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

2of 8

•Cord is attached via a weatherproof 2-pin Deutsch connector.

•The cord is detachable by depressing the tab on the top of the connectors. This enables the

operator to remove and store the light while leaving the cord connected to the power source.

•Additional or replacement cords can be ordered from our website. Contact us or visit LarsonElectronics.com for more

information.

INSTALLATION NOTES

•Read this user’s manual thoroughly and retain it for future reference.

•Use a damp cloth to clean the unit.

•Never attach anything to this unit that could lead to danger.

•Do not install this unit to a surface that could become unstable such as a stand, tripod, shelf or table.

•Install the unit in an open area away from heat sources.

•Always use the voltage listed on the unit.

•Keep objects and cables away while the unit is in operation.

•Do not electrically overload this unit to prevent a risk of fire.

•Contact an electrician for installation if you are not familiar with electrical wiring.

How to Mount the Pan/Tilt Base

1. Determine the location you want tomount the base to.

2. Attach the pan/tilt base to your surface using the four corner thru-

holes at the base of the unit. Use the provided bolts to mount the base.

Be sure the unit will move freely and won’t contact the wall, ceiling

or pole during operation.

3. Bolt your device to the mounting plate on top of the unit and secure it tightly.

If necessary, usethe included 8x10” mounting plate.

Optional: Connect your device to one of the individual +/-leads on the base.

Seal off the additional wire if not used.

Warning: Check product label for correct input voltage!

Attach supply line wires to the appropriate light fixture wires as shown

in thediagram 

Secure each pair of wires according to the diagram. Utilize ajunction box

or similar device and take precautionary steps for weatherproofing

all connectionsif installed in alocation where water may come in contact

with the unit. Ensurethe unit is properly grounded and that wiring is done

according to all local and national electrical/building codes.

Standard Cord Cap

This unit comes pre-wired from factory with the selected cord cap. Take

precautionary steps for weatherproofing all connections if installed in a

location where water may come in contact with the unit. All outdoor

installations and indoor installations near awet location require the use of a

GFCI device for safety, according to the National Electrical Code® (NEC).

Ensure the unit is properly grounded.

DETACHABLE CORDS

WIRING

Standard pigtail(flying leads) wiring

We strongly encourage alicensed electrician install this product,in all locations especially in outdoor

areas where weatherproofing may be required. Universal voltage driver permits operation at 12V or 24V DC.

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

3of 8

4. Attach and run the power cables. Take the 25’ cable

w/inline remote and securely attach the female connection

to the base.

5. Attach the hardwired remote to the other end of the cable

by screwing the female end of the remote assembly to the

male end of the wire harness.

6. If your unit will be hardwired, keep the flying leads

attached to the remote and hardwire the unit. Use the pin

tab to remove the flying leads and attach the cigarette

plug adapter if needed.

7. Find a location to mount the base for the hardwired

remote. Use the two screws provided.

8. Apply power to the unit to ensure proper function.

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

4of 8

Remote Control

•ON/OFF – Power’s the unit on or off.

•UP DOWNLEFTRIGHT - Moves the pan/tilt base in the corresponding

direction.

LOCK Remote Functionality

Press the LEFT +RIGHT buttons on the

hardwired remote simultaneously or press the

/button on the wireless remote.

A BLUE backlight on the hardwired remote

indicates the remote functionality is LOCKED. A

RED backlight indicates the remote functionality

is UNLOCKED and both the wired and

hardwired remotes will function.

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

5of 8

HANDHELD WIRELESS REMOTE PROGRAMMING PROCESS:

1. Switch off DC power.

2. Make sure there is NO other transmitter operating at the same time.

3. Switch on DC power, within 5 seconds press the remote's up and down button

once at the same time.

4. Searchlight will flash to acknowledge the remote, connection has been made.

5. To program the second remote (up to 4 remotes may be used with the

searchlight, programming a fifth will replace the first), within five seconds, pres

the second remote's up and down button after the first remote is acknowledged

or repeat step 1.

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

6of 8

Specifications

Materials Aluminum die-casting/Aluminum Plate

Color Black

Rotating angle Pan 0˚to 355˚±5˚, Tilt -60˚to +30˚±5˚

Rotating speed Pan 6.2˚/sec ± 0.6˚, Tilt 3.1˚/sec ± 0.6˚

Loading weight 66 lbs. at 70mm from Tilt table surface to center gravity

Power Consumption Pan: 6W, Tilt: 15W

Operating Temperature -25°C to + 50˚C

Weight 24 lbs.

Dimensions 12" L x 10" H x 8" W

Rating IP54

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

7of 8

Command Protocols

No Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7

1Command FFh Receiver ID 00h 04h DATA1 DATA2 CHECKSUM

Description

2Command FFh Receiver ID 00h 02h DATA1 DATA2 CHECKSUM

Description

3Command FFh Receiver ID 00h 08h DATA1 DATA2 CHECKSUM

Description

4Command FFh Receiver ID 00h 10h DATA1 DATA2 CHECKSUM

Description

5Command FFh Receiver ID 00h 20h 00h 00h CHECKSUM

Description

6Command FFh Receiver ID 00h 40h 00h 00h CHECKSUM

Description

7Command FFh Receiver ID 01h 00h 00h 00h CHECKSUM

Description

8Command FFh Receiver ID 00h 80h 00h 00h CHECKSUM

Description

9Command FFh Receiver ID 00h 00h 00h 00h CHECKSUM

Description

10 Command FFh Receiver ID 00h 03h 00h PRESETID CHECKSUM

Description

11 Command FFh Receiver ID 00h 05h 00h PRESETID CHECKSUM

Description

12 Command FFh Receiver ID 00h 07h 00h PRESETID CHECKSUM

Description

13 Command FFh Receiver ID 00h 0Fh 00h 00h CHECKSUM

Description

14 Command FFh Receiver ID 00h 09h 00h 01~02h CHECKSUM

Description

15 Command FFh Receiver ID 00h 0Bh 00h 01~02h CHECKSUM

Description

Command

PAN LEFT

DATA1:PAN SPEED(00~3Fh),DATA2:TILTSPEED(00~3Fh)

PAN RIGHT

TILT DOWN

DATA1:PAN SPEED(00~3Fh),DATA2:TILTSPEED(00~3Fh)

TILT UP

AUX OFF

AUX ON

ZOOM TELE

ZOOM WIDE

FOCUS NEAR

SETPRESET

PRESET ID=00~7Fh

FOCUS FAR

P/T/Z/F STOP

GOTO PRESET

PRESET ID=00~7Fh

CLEAR

PRESET PRESETID=00~7Fh

REMOTE

RESET

PTB-1-M

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

8of 8

MAINTENANCE

There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the

fixture for proper function.

•Disconnect power running to the lamp and be sure the fixture is cool to the touch.

•Use a non-abrasive glass cleaning solution to clean the lens.

Note: It is notnecessary toopen the fixture and clean or touch the LED’s.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The PTB-1-M is designed to provide years of reliable performance. Should the need for replacement parts arise, please

contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.

Inhaltsverzeichnis

Andere Larson Electronics Scheinwerfer Handbücher

Larson Electronics

Larson Electronics GL-9100H-S Handbuch

Larson Electronics

Larson Electronics GL-30675-F Bedienungsanleitung

Larson Electronics

Larson Electronics HL.RL-85-LED-36W-CPR-1227 Bedienungsanleitung

Larson Electronics

Larson Electronics The LE-9 Series Bedienungsanleitung

Larson Electronics

Larson Electronics LE-217 Bedienungsanleitung

Larson Electronics

Larson Electronics Golight RadioRay GL-7 GT Series Bedienungsanleitung

Larson Electronics

Larson Electronics Golight GL-2 GT Series Handbuch

Larson Electronics

Larson Electronics RL-85-3W1 Bedienungsanleitung

Larson Electronics

Larson Electronics HUL-P10WR-DM-ILS-1227 Bedienungsanleitung

Larson Electronics

Larson Electronics GL-3100-S-12-E Handbuch

Larson Electronics

Larson Electronics LE Series Bedienungsanleitung

Larson Electronics

Larson Electronics HL-85-LED-CPR Bedienungsanleitung

Larson Electronics

Larson Electronics GL-2110-F Handbuch

Larson Electronics

Larson Electronics EXPRA-06R-LED Bedienungsanleitung

Larson Electronics

Larson Electronics GL-30514-S-E Handbuch

Larson Electronics

Larson Electronics RL-14 Bedienungsanleitung

Larson Electronics

Larson Electronics GL-2000-24 Handbuch

Larson Electronics

Larson Electronics GL-52893 Handbuch

Larson Electronics

Larson Electronics PML-90LED-DP-120 Bedienungsanleitung

Larson Electronics

Larson Electronics WALTP-Q500 Bedienungsanleitung

Larson Electronics

Larson Electronics IL-LED-27R Bedienungsanleitung

Larson Electronics

Larson Electronics HL-85-LED-CPR-NC Bedienungsanleitung

Larson Electronics

Larson Electronics GL-9901 Handbuch

Larson Electronics

Larson Electronics Golight 51494 Handbuch

Beliebte Scheinwerfer Handbücher anderer Marken

Guangzhou Yinhe Lighting&Sound Equipment Factory

Guangzhou Yinhe Lighting&Sound Equipment Factory NE-204 Bedienungsanleitung

LIVARNO home

LIVARNO home 375304 2101 Originalbetriebsanleitung

Cameo

Cameo CLQS40WW Bedienungsanleitung

Leviton

Leviton Ellipsoid 5/50 Bedienungsanleitung

Monacor

Monacor img Stage Line PARL-56PDX/CR Bedienungsanleitung

Vector

Vector SL3AKV Bedienungsanleitung

Quantum

Quantum Q262 Betriebshandbuch

Philips

Philips Vari-lite VL3015LT Bedienungsanleitung

EUROSPOT

EUROSPOT C51 Bedienungsanleitung

DTS

DTS MINI BRICK ARC Bedienungsanleitung

Federal Signal Corporation

Federal Signal Corporation VISIBEAM II Handbuch

ACME

ACME LED-MS350B Bedienungsanleitung

EuroLite

EuroLite Akku flat light 1 Bedienungsanleitung

Commercial Electric

Commercial Electric SPTM-1401 Bedienungsanleitung

Vision & Control

Vision & Control SLB-500-W5K7-P-SL Bedienungsanleitung

Teknik

Teknik FLEXI Bedienungsanleitung

Craftsman

Craftsman CMXLSB10 Bedienungsanleitung

EuroLite

EuroLite LED SLS-144 UV Floor Spot Bedienungsanleitung
