LAVAZZA ESPRESSO MAXI POINT

OPERATION MANUAL

COMPONENTS

Power light

Coffee dispenser button

Cartridge insertion opening

See following pages for detailed images

Cartridge load lever grip

Water tank window

Dispensing spout

Cup-support rack

Used cartridge/drop

collection drawer

Rear tank cover

Steam/hot water

dispenser LED

Steam/hot water

dispenser knob

Steam/hot water arm

Power cord

On/off switch

Power cord point

Service & Sales:

1300 622 126

supported by

The Blue Pod Coffee Co.

Position the machine on a ﬂat and stable

surface well away from water, ﬂames and sourc-

es of heat. Unplug from the electricity mains if

plugged in. When on, never cover the machine

with tea towels or similar.

PREPARING THE MACHINE

Service & Sales:

1300 622 126

supported by

The Blue Pod Coffee Co.

Congratulations on selecting the Lavazza

Espresso Point Maxi coffee machine. With years

of experience and relentless attention to detail

Lavazza are now the world leaders in coffee

pods, producing over 20 million a day.

The Espresso Point Capsule used in this machine

is an innovative vacuum packed system. It seals

in the freshness and quality of superior Lavazza

coffee beans and produces fresh, rich tasting

coffee every time. Used with Lavazza’s state-

of- the-art Italian designed coffee machines - it

enables anyone to enjoy an excellent Italian es-

presso, at any time, anywhere.

We trust you will enjoy.

TURNING ON THE MACHINE

iUsing a water ﬁlter (optional accessory) improves

the quality of the water and increases the life of

the machine. Use the AquaAroma Crema Brita®

ﬁlter for Lavazza. To insert the ﬁlter follow the

instructions booklet that comes with the acces-

sory. It is advisable not to modify the ﬁlter default

setting.

The water must never go above the MAX

indicator line and should always remain above

the MIN marking. Only use fresh drinkable, non-

sparkling water. Warm water and other liquids

may damage the tank. Do not attempt to use the

machine if there is no water in the tank. Check that

the water level is above the MIN level indicated.

Fill the water tank up to the MAX level indicated

using only fresh non-sparkling drinkable water.

The tank may only be ﬁlled via the side opening.

Plug the power cord into the electricity mains

and turn on/off switch to the ON position.

Wait until the power light remains lit and the ma-

chine emits an acoustic sound.

To remove the

tank lift it and

turn slightly.

Rinse with

clean water &

replace.

PREPARING THE MACHINE

Service & Sales:

1300 622 126

supported by

The Blue Pod Coffee Co.

iRegulating the dispensing spout:

Espresso coffee: dispensing spout out, facing

down

Large cup of coffee: dispensing spout back,

facing up

Only Lavazza ESPRESSO POINT MAXI car-

tridges may be inserted into the cartridge slot

ENERGY SAVING

1After a period of inactivity, the machine will go

into stand-by mode and the power light will

ﬂash.

To re-start the machine simply lift and lower the

cartridge load lever.

The machine is ready for use when it emits an

acoustic signal and the power light remains lit.

PREPARING A COFFEE

iRegulating the cup-support rack:

Espresso coffee: rack rotate 180˚

Large cup: rack down (standard position)

TECHNICAL CHARACTERISTICS

• Voltage: 220 - 240V 50Hz

• Total power: 1000W

• Capacity water tank: 1.4L

• Dimensions: Height: 36cm

Width: 23cm

Depth: 34cm

• Weight: 5,6kg

• Collection drawer capacity: 12 capsules

• Materials used for the machine body:

Thermoplastic

PREPARING COFFEE

Service & Sales:

1300 622 126

supported by

The Blue Pod Coffee Co.

Step1 - Using the lever grip,

open cartridge lever

Step2 - view empty cartridge

opening

Step3 - insert new coffee pod Step4 - close lever, coffee pod

will drop into place

DISPENSING COFFEE

1Position the cup in the centre of the rack.

Lift the cartridge load lever and insert the coffee

pod into the slot.

REMOVE USED PODS

iIf the cartridge does not enter, empty the used

cartridge/drop collection drawer

Always use the grip.

Do not put your ﬁngers

or other objects

into the cartridge slot

Press the coffee dispensing button: the light

ﬂashes.

When you have the desired quantity of coffee

in your cup, press the coffee dispenser button

again to stop the machine.

1Gently unclip the cartridge/drop collection

drawer.

2Remove the lid and remove the used coffee

pods. Place the drawer back into place.

TROUBLE SHOOTING

Service & Sales:

1300 622 126

supported by

The Blue Pod Coffee Co.

Problem

The machine doesn’t turn on.

LEDs ﬂash quickly.

The cartridge load lever will not

return to a central position.

The pump is noisy.

The machine doesn’t dispense any

coffee.

Coffee is not hot enough.

The coffee does not come out or

comes out in drops.

The coffee comes out too quick-

ly, the espresso crema does not

form.

Milk or cappuccino froth doesn’t

form.

No hot water or steam

dispensed.

Possible causes Solution

Machine not plugged into the elec-

tricity source.

The machine has broken down.

Used cartridge/drop collection

drawer is full.

Incorrectly inserted cartridge.

The tank needs ﬁlling with water.

Filter inserted incorrectly.

Unsuitable temperature.

Hot water/ steam option selected.

Cartridge load lever in raised posi-

tion.

Cups are cold.

The machine was not at the cor-

rect temperature when the coffee

dispenser button was pressed.

Blocked dispensing spout.

The cartridge has already been

used.

Milk unsuitable.

Milk is not cold enough.

Steam dispensing spout is

clogged.

Clogged steam/hot water arm.

Insufﬁcient water in the tank.

Filer not inserted correctly.

Check it is plugged in correctly.

Contact customer services or a service

centre.

Empty the used cartridge/drop collec-

tion drawer.

Lift the cartridge load lever and cor-

rectly insert the cartridge.

Reﬁll with fresh drinkable water.

Check that the Brita® ﬁlter is correctly

inserted (see instructions supplied with

ﬁlter)

Wait until the ideal temperature has

been reached.

Return the hot/steam dispenser button

to a central position.

Lower the cartridge load lever.

Pre-heat the cups using hot water.

Wait until the machine light remains lit.

Clean the dispensing spout.

Insert a new cartridge.

Use fresh semi-skimmed milk.

Use milk at refrigerated temperature.

Clean the steam dispensing spout with

a needle and clean the arm.

Clean the arm. If the problem per-

sists clean the dispenser hole with a

thin needle, making sure that it is free

of blockages. Then turn on the ma-

chine and dispense a small quantity of

steam.

Reﬁll with fresh drinkable water.

Check that the Brita® ﬁlter is correctly

inserted (see instructions supplied with

ﬁlter).

•
