Lefroy Brooks TT 4969 Bedienungsanleitung

TT 4969

TEN TEN WALL MOUNTED BRUSH AND POT

INSTALLATION GUIDE

2

DIMENSIONS

TOOLS REQUIRED

Powered drill with Ø6mm drill bit Flat blade screwdriver Spirit level

109mm

113.5mm

414mm

277mm

57mm

Front view or bracket with hole centres

32mm

31.5mm 31.5mm

3

INSTALLATION

1 Remove the brush and pot from the holder.

2 Use a spirit level to ensure the holder is level

then mark the hole positions on the mounting

surface.

3 Drill holes using a Ø6mm drill bit.

4 Insert the wall plugs into the holes then

secure the holder using the screws supplied.

Alternative wall plugs should be used subject

to mounting surface construction (not

supplied).

5 Place the pot and brush into the holder.

(6 o)

(6 o)

CUSTOMER SUPPORT

+44 (0)1992 708 316

LEFROYBROOKS.CO.UK

Whilst every effort is made to ensure the accuracy of these, they are subject to change without notice as part

of the company’s product development process. The use of trademarks, product design and artwork is subject to

licence or agreement with LBIP Ltd. The design registrations, trademark registrations and copyrights are protected

by law and the use or reproduction outside the terms of an agreement is prohibited. The right to modify designs

and dimensions is reserved. LBIP Ltd is a member of ACID (Anti Copying in Design).

© LBIP Ltd 2016

20.065.248A / OCTOBER 2016
