Technical Data - LEICA S

(Last revised September 2012 / We reserve the right to make technical changes)

Camera Leica S (Type 006)

Order number 10803

Camera type Digital medium format SLR camera

Lens mount LEICA S bayonet

Compatible lenses LEICA S lenses

Image sensor CCD sensor

Sensor size Leica Pro format

45 x 30 (mm)

Aspect ratio 3:2

Sensor resolution 37.5 MP

7500 x 5000 pixel

Pixel size 6µm

Microlenses on sensor Yes, with microlens shift

Dynamic range 12 f-stops

Low-pass filter No, for maximum detail transfer

IR filter on sensor

Color depth 16 bit

Working color space (JPEG) sRGB

AdobeRGB

ECI-RGB V2

Image settings (JPEG) Contrast

Sharpness

Saturation

ISO range autoISO

ISO100

ISO200

ISO400

ISO800

ISO1600

White balance autoWB

daylight 5200K

cloudy 6000K

shade 7000K

tungsten light 3200K

HMI 5600K

Neon warm 4000K

Neon cool 4500K

Flash 5400K

Gray card

Color temperature 2000K to 13100K

Page 2

Exposure modes Single

Continuous

Self-timer 2s with mirror-up function

Self-timer 12s with mirror-up function

Mirror-up function Yes

Exposure modes M (manual)

P (program automatic)

T (time pre-select)

A (aperture priority)

B (BULB with time pre-select)

Image data format DNG

DNG lossless compressed

JPEG fine/standard

37.5 MP, 9.3 MP 2.3 MP

DNG+JPEG

File sizes DNG: approx. 72MB

DNG lossless compressed: 42MB

JPEG: approx. 1MB-16MB (depending on image content,

compression ratio and resolution)

Storage media SD (SDXC)

CF (UDMA7)

external (PC)

Memory 2GB RAM

Frame rate max. 1.5 fps

Buffer memory DNG: up to 28 consecutive images

DNG lossless compressed: up to 32 consecutive images

JPEG: unlimited

Menu languages English, French, German, Spanish, Italian, Japanese,

Chinese traditional and simple, Russian

Computer interface High-speed USB2.0

Exposure metering Open aperture measurement through lens

TTL

Exposure metering method Multi-pattern

center-weighted

spot (3.5 %)

AE lock Shutter release or

AF/AE memory button (on back of camera)

Exposure compensation + /- 3 EV in 1/2 f-stops

Bracketing Yes

3 or 5 images

1/2EV, 1EV, 2EV, 3EV

automatic mode (all images captured with a single press

of the shutter release)

Light metering range Spot (ISO100, f=2.5 ) +2.1EV to +20EV

Multi-pattern/center-weighted (ISO100, f=2.5 ) +1.1EV

to +20EV

Shutter Slot shutter (microprocessor-controlled shutter)

Central shutter (with Leica S central shutter lenses)

Shutter speeds 1/4000s to 125s

Page 3

Flash control SCA 3502

max. compatibility LEICA SF58 (order number. 14488)

TTL

TTL-HSS (up to 1/4000s)

Strobe

start or end of exposure

Flash synchronization Focal plane shutter: 1/125s

with Leica SF58 in HSS (high-speed sync) up to 1/4000s

central shutter: 1/1000s

Flash synchronization point Start of exposure

End of exposure

Flash sockets Accessory shoe with middle and control contacts

Flash sync socket

LEMO® synchronous flash

Focus Central cross type sensor (phased autofocus)

Focus methods AFs (sharpness priority)

AFc (shutter release priority)

AF (can be can be corrected at any time by manual

focus)

MF (manual focus with focus indicator on back panel

display)

Focus memory 2. Shutter release pressure point

AF/AE memory button

Viewfinder Pentaprism type

Diopter compensation -3 dpt to +1dpt

Viewfinder coverage approx. 98%

Viewfinder magnification 0.86

at 70mm, infinity, 0dpt.

Eyepieces Mag. Viewfinder shutter (included in package content)

Viewfinder information Horizon, exposure time, exposure metering mode,

aperture, flash status, exposure balance, flash

synchronization indicator, focus indicator, exposure

metering method, exposure compensation, remaining

shots (on storage medium), buffer, warnings, ISO

Top plate display Colored OLED

Back panel display 3" brilliant TFT LCD

Resolution: 921,600 pixels

Color space: sRGB

16 million colors

Frame coverage: 100%

View angle: 170 °

Cover glass: Corning®Gorilla®Glass

Power supply Leica Battery S Lithium-ion battery, 7.4V, 2100mAh

Leica AC Adapter S

Charger Leica Quick Charger S

Inputs: 100-240V AC, 50/60Hz, 12/24V DC

Output: 4.2V DC, 800mA

Leica Professional Charger S

Page 4

Camera body Magnesium body

anti-slip rubberized

magnesium top plate

brass bayonet

Operating conditions: 0°-45° C

15-80% rel. humidity

Interfaces Hotshoe

HDMI jack

Flash sync socket

LEMO® USB2.0 HiSpeed jack

LEMO® flash sync socket/LEMO® cable release socket

Contact bar for Leica Multifunctional Handgrip S (for

Leica S (Typ 006))

Controls Main switch (off/fps/cs)

Clickwheel

Shutter speed dial

Shutter release

Depth-of-field button

Lens release button

Diopter adjustment ring

4 function keys

Joystick/AF+AE memory button

Tripod thread 1/4" and 3/8" with anti-twist locking pins

Dimensions approx. 160x80x120 mm (LxWxH)

Weight Approx. 1260g with battery

Scope of delivery

(Products & software)

Leica S (type 006) (order no. 10803)

Leica Battery S (order no. 14429)

Leica Quick Charger S (including adapter for EU,UK,US,

car)

(order no. 16009)

Leica Camera Strap S (order no. 16037)

Leica Eyepiece Cap (order no. 16015)

Leica Camera Cap (order no. 16021)

Leica USB Cable S (order no. 16014)

Leica Flash Sync Cable S (for Leica S (Type 006) (order

no. 16031)

Software: Leica Image Shuttle, Adobe® Photoshop®

Lightroom®

(download after registration in customer area)

Optional accessories Leica Multifunctional Handgrip S (for Leica S (Type 006))

(order no. 16028)

Leica Wrist Strap S (order no. 16004)

Leica Professional Charger S (order no. 16011)

Leica SF58 (order no. 14488)

Leica HDMI Cable (order 14491/ JP+TW 14492)

Leica Grid Screen S (order no. .16002)

Leica Microprism Screen S (order no. 16001)

Leica AC Adapter S (order no. 16022)

Leica Standard Screen S (order no. 16000)

Leica Cable Release S (for Leica S (of type 006)) ( Order

no. 16029)

Page 5

Leica S Adapter V/M645/P67/H (order

16024/16025/16026/16030)

Leica Case S (order no. 16010)
