LENCO SCD-39 USB Bedienungsanleitung

CD/MP3 PLAYER WITH PLL FM RADIO

AND USB READER

SCD-39 USB

Users guide

Please read and follow these instructions before using your unit.

For information and support, www.lenco.com

EN-1

Dear customer,

Thank you for buying this Lenco product. Quality and usability is our top priority. In order to

let you fully enjoy this product, we have manufactured this product using high quality

standards, materials, components and care.

SAFETY INSTRUCTIONS

Read carefully before use.

CAUTION - RISK OF ELECTRICAL SHOCK - DO NOT OPEN

CAUTION: TO PREVENT AN ELECTRICAL SHOCK, DO NOT REMOVE ANY

COVER SCREWS. THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REQUEST A QUALIFIED SERVICE PERSON TO PERFORM SERVICING.

Keep these instructions in mind:

Although this device is manufactured with the utmost care and checked several times

before leaving the factory, it is still possible that problems may occur, as with all

electrical appliances. If you notice smoke, an excessive build-up of heat or any other

unexpected phenomena, you should disconnect the plug from the main power socket

immediately.

Do not use this device near water.

Clean only with a slightly damp cloth.

Do not cover or block any ventilation opening. When placing the device on a shelf, leave

5 cm (2”) free space around the whole device.

Install in accordance with the supplied user manual.

Don’t step on or pinch the power cord. Be very careful, particularly near the plugs and

the cable’s exit point. Do not place heavy items on the power cord, which may damage it.

Keep the entire device out of children’s reach! When playing with the power cable, they

can seriously injure themselves.

Unplug this device during lightning storms or when unused for a long period.

Keep the device away from heat sources such as radiators, heaters, stoves, candles

and other heat-generating products.

Avoid using the device near strong magnetic fields.

ESD can disturb normal usage of this device. If so, simply reset and restart the device

following the instruction manual. During file transmission, please handle with care and

operate in a static-free environment.

Never insert an object into the product through the vents or openings. High voltage flows

thru the product and inserting an object can cause electric shock and/or short circuit

internal parts. For the same reason, do not spill water or liquid on the product.

Do NOT use in wet or moist areas such as bathrooms, steamy kitchens or near

swimming pools.

Do not use this device when condensation may occur.

EN-2

This device must operate on a power source as specified on the specification label. If

you are not sure of the type of power supply used in your home, consult your dealer or

local power company.

The socket outlet must be installed near the equipment and must be easily accessible.

Do not overload AC outlets or extension cords. Overloading can cause fire or electric

shock.

Devices with Class 1 construction should be connected to a main socket outlet with a

protective earthed connection.

Devices with Class 2 construction do not require a earthed connection.

Keep away from rodents. Rodents enjoy biting on power cords.

Always hold the plug when pulling it out of the main supply socket. Do not pull the power

cord. This can cause a short circuit.

Avoid placing the device on any surfaces that may be subject to vibrations or shocks.

When the device is not in use for long periods, unplug the AC power cable for safety

reasons.

To clean the device, use a soft dry cloth. Do NOT use solvents or petrol based fluids. To

remove severe stains, you may use a damp cloth with dilute detergent.

The supplier is not responsible for damage or lost data caused by malfunction, misuse,

modification of the device or battery replacement.

The marking plate is located at the bottom of the apparatus.

WARNING: Prolonged exposure to loud sounds from personal music players

may lead to temporary or permanent hearing loss.

The USB memory stick should be plugged into the unit directly. Don’t use an

USB extension cable because it can cause interference resulting in failing of

data.

EN-3

OVERVIEW OF THE PLAYER

1. FOLDING HANDLE

2. FM TELESCOPIC ANTENNA

3. CD DOOR

4. CD DOOR OPEN AREA

5. SKIP/SEARCH DOWN BUTTON

6. SOURCE BUTTON

7. STANDBY INDICATOR

8. STOP/CH- BUTTON

9. PLAY/PAUSE/CH+ BUTTON

10. LCD DISPLAY

11. ON/STANDBY BUTTON

12. SKIP/SEARCH UP BUTTON

13. SPEAKERS

14. MEM/MODE/PROG BUTTON

15. VOLUME - BUTTON

16. USB PORT

17. VOLUME + BUTTON

18. FOLDER/10+ BUTTON

19. BATTERY COMPARTMENT

20. DC IN JACK

21. PHONE JACK

22. AUX IN JACK

1234

5678 9101112

13 14 15 16 17 18 13

19 20 21 22

EN-4

POWER SUPPLY



BATTERY OPERATION

1. Remove the battery compartment cover gently.

2. Install 6 x 'C' size batteries (UM-2 or equivalent) while observing the correct polarities.

3. Replace the battery compartment cover.

NOTE:

yThe AC/DC adapter must be detached from the DC IN jack of the player for battery

operation.

yLeaking batteries may damage the battery cabinet and the player as a whole, so they

should be removed from the cabinet when becoming flat or when the player is not to be

played on batteries for some time.



DC INPUT OPERATION

Plug the supplied adapter to the DC IN jack on the unit and the main power.

NOTE:

If not any audio signal inputs to the unit in about one hour, the unit will enter to standby

mode automatically (except at FM radio mode).

FM RADIO

TUNING THE FM RADIO

1. The standby indicator will light once connect the main unit to the main power. Press the

ON/STANDBY button to turn the unit on (the standby indicator will be off).

2. Press the SOURCE button repeatedly to switch the unit to radio mode if necessary.

3. To launch the auto-searching, press and hold the SKIP/SEARCH DOWN button or

SKIP/SEARCH UP button several seconds and then release it.

4. Press the SKIP/SEARCH DOWN button or SKIP/SEARCH UP button to tune the radio

stations manually.

5. Adjust the volume level to a comfortable listening level via pressing the VOLUME +/-

buttons.

6. Press the ON/STANDBY button to turn off the unit.

NOTE:

yThe FM telescopic antenna is directional. When you are receiving an FM broadcast, fully

extend the telescopic antenna and rotate it for the best reception.

STORING YOUR FAVORITE RADIO STATION

1. Tune to your favorite station first; press the MEM/MODE/PROG button for storing the

current station until memory cell number flashes on the screen.

2. Use the STOP/CH- button or the PLAY/PAUSE/CH+ button to select the corresponding

memory cell among P01-P20.

3. Confirm your selection by pressing the MEM/MODE/PROG button.

4. During radio playback, press the STOP/CH- button or the PLAY/PAUSE/CH+ button

repeatedly to recall the preset stations.

EN-5

HANDLING AND MAINTENANCE OF A DISC

Follow the instructions below to handle and maintain your disc in

order that long time and trouble free performance can possibly be

obtained:

Ensure not to caress the rain bow side of the disc; handle the

disc by the edge.

Long time exposure to sunshine, high temperatures and

humidity will damage the disc. And keep storage area clean.

Avoid sticking labels on both sides of a disc. Writing with

pointed articles on the disc should be strictly avoided.

Clean the disc wiping the centre and then working out to the

edge with a dry & soft cloth or a disc brush. Avoid any

cleansing lotion or chemical eradicator.

Store them in their cases when they are not to be used.

LOAD A DISC

1. Open the CD door by the Door open area.

2. Load a disc on the disc tray with the label side facing up.

3. Close the CD door.

PLAY A DISC (CD/MP3)

1. Press the ON/STANDBY button to turn the unit on (the standby indicator will be off).

2. Press the SOURCE button repeatedly to switch to CD mode.

3. Follow the steps above to load a disc.

4. The player begins reading disc immediately.

5. When the disc is successfully read, the playback will start from the first track

automatically.

6. Press the PLAY/PAUSE/CH+ button once to halt music playback, press the button again

to resume the normal playback; press the STOP/CH- button to cease music playback.

EXTERNAL MEMORY MEDIA OPERATION (USB)

1. Press the ON/STANDBY button to turn the unit on (the standby indicator will be off).

2. Insert an USB to the USB port.

3. Press the SOURCE button repeatedly to switch to USB mode.

4. When the inserted USB is detected and read, the first track will be played automatically.

5. Press the PLAY/PAUSE/CH+ button to pause or resume the playback.

6. Press the STOP/CH- button to cease the playback.

SKIP TRACKS AND SEARCH FOR A SPECIFIC POINT TO PLAY (CD/MP3/USB)

1. Press once the SKIP/SEARCH UP button in music play to skip to the next track; press

once the SKIP/SEARCH DOWN button in music play to go back to beginning of the

current track, press the button twice continuously to skip to the previous track.

2. Press and hold the SKIP/SEARCH UP button or the SKIP/SEARCH DOWN button in

music play to search at quick rate for a specific point to play.

HANDLE DISC ONLY AS SHOWN

CLEAN FROM CENTER TO EDGE

DO NOT STORE NEAR HEAT

EN-6

3. Press the FOLDER/10+ button once in play to skip to the track 10 tracks ahead, twice to

skip to the track 20 tracks ahead. You can reach the last track of the disc using this

button.

SKIP TO THE PREVIOUS/NEXT FOLDER (MP3/USB)

1. During playback, press and hold the FOLDER/10+ button until the folder number flashes

on the screen.

2. Press the SKIP/SEARCH DOWN button or SKIP/SEARCH UP button to select the folder

you want.

3. Wait several seconds or press the FOLDER/10+ button to confirm, the playback starts

from the selected folder.

REPEAT PLAYBACK (CD/MP3/USB)

During playback, press the MEM/MODE/PROG button to repeat play a single track; press

the button twice to repeat play all tracks; press the button three times to enter the

introduction play mode; press the button four times to enter the random play mode; press

the button five times to exit.

PROGRAMMED PLAY (CD/MP3 DISC/USB)

1. In stop mode, press the MEM/MODE/PROG button once, the program’s icon shows with

a program sequence indication "P01" first, then a track number flickers on the LCD with

the program’s icon.

2. Select the first track to be programmed using the SKIP/SEARCH UP button or the

SKIP/SEARCH DOWN button, and then press the MEM/MODE/PROG button again to

store and advance to the next programming step (If there are several folders on the MP3

disc or USB, it is necessary to program folders first and then the tracks. The method of

the folders programming is the same as the tracks programming.).

3. Repeat the above steps to program more tracks. A maximum of 20 tracks for CD and 99

tracks for MP3 disc/USB can be programmed in memory in a preferred order. If the

memory is full, the screen will show “FUL” for indicating.

4. Press the PLAY/PAUSE/CH+ button to begin programmed play in the preferred order

after you are done with programming. The player stops automatically after all

programmed tracks are played.

5. You may press the STOP/CH- button to terminate programmed playback. In program

stop mode, press the PLAY/PAUSE/CH+ button to begin the programmed playback with

the programming order identical with the previous one done; press the STOP/CH- button

again to clear the programming.

AUX IN

1. Connect the AUX IN jack on the unit to an audio source, for example, MP3 player with an

audio cable.

2. Power on the unit following the corresponding instructions.

3. Press the SOURCE button repeatedly to switch to AUX mode.

EN-7

4. Use the native controls on the connected audio device to begin playing music through the

connected unit.

STEREO PHONE JACK

A stereo phone jack has been provided on the back side of the player so that you can listen

without disturbing others. To use this jack, plug in the headphones/earphones (NOT

INCLUDED) and adjust the volume level to a preferred level.

NOTE: When external headphones/earphones are connected, the speakers will be muted.

CAUTION: Listening at high power for a long moment could damage users' ears.

SPECIFICATION

Power requirement ..............AC power adaptor:

Input: AC 100-240V, 50/60Hz

Output: DC 9V, 1A

DC 9V UM-2/"C" x 6pcs (batteries) – not included

Power consumption.............9W

Dimensions..........................Approx. 232(L) X 227(W) X 112.5(H) mm

Operation temperature ........+5°C ~ + 35°C

Receiving band....................FM

Tuning range .......................FM 87.5 - 108 MHz

Playback system .................Compact Disc Digital Audio System

Output power.......................1.2W x 2 @10% THD

Speaker impedance.............8 ohms

USB.....................................USB 2.0 version

Specifications are subject to change without notice.

EN-8

SERVICE AND SUPPORT

For information: www.lenco.com

For support: http://lencosupport.zendesk.com

Lenco helpdesk:

Germany 0900-1520530 (Local charges)

The Netherlands 0900-23553626 (Local charges + 1ct p/min)

Belgium 02-6200115 (Local charges)

France 03-81484280 (Local charges)

The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM.

When contacting Lenco, you will always be asked for the model and serial number of your

product. The serial number can be found on the back of the device. Please write down the

serial number below:

Model: SCD-39 USB

Serial number:_________________________________

Lenco offers service and warranty in accordance to European law, which means that in

case of repairs (both during and after the warranty period) you should contact your local

dealer.

Important note: It is not possible to send products that need repairs to Lenco directly.

Important note: If this unit is opened or accessed by a non-official service center in any

way, the warranty expires.

This device is not suitable for professional use. In case of professional use, all warranty

obligations of the manufacturer will be voided.

This symbol indicates that the relevant electrical product or battery should not

be disposed of as general household waste in Europe. To ensure the correct

waste treatment of the product and battery, please dispose them in accordance

to any applicable local laws of requirement for disposal of electrical equipment

or batteries. In so doing, you will help to conserve natural resources and

improve standards of environmental protection in treatment and disposal of

electrical waste (Waste Electrical and Electronic Equipment Directive).

Products with the CE marking comply with the EMC Directive (2004/108/EC)

and the Low Voltage Directive (2006/95/EC) issued by the Commission of the

European Community.

www.lenco.com

REPRODUCTOR DE CD/MP3

CON RADIO FM PLL FM Y LECTOR DE USB

SCD-39 USB

Guía del usuario

Por favor, lea y siga estas instrucciones antes de usar la unidad.

Para información y asistencia: www.lenco.com

Andere Handbücher für SCD-39 USB

Inhaltsverzeichnis

Sprachen:

Andere LENCO MP3-Player Handbücher

LENCO

LENCO SCD-39 USB Bedienungsanleitung

LENCO

LENCO Xemio-560 Bedienungsanleitung

LENCO

LENCO Xemio-154PK Bedienungsanleitung

LENCO

LENCO CD-3772 MP3 Bedienungsanleitung

LENCO

LENCO SCD-50 BT Bedienungsanleitung

LENCO

LENCO XEMIO-857 Bedienungsanleitung

LENCO

LENCO Xemio-767 BT Bedienungsanleitung

LENCO

LENCO BTX-860 Bedienungsanleitung

LENCO

LENCO XEMIO-250 Bedienungsanleitung

LENCO

LENCO Xemio-668 Bedienungsanleitung

LENCO

LENCO HELLO KITTY MP3 Bedienungsanleitung

LENCO

LENCO Xemio-645 Bedienungsanleitung

LENCO

LENCO XEMIO-127 Bedienungsanleitung

LENCO

LENCO XEMIO-115 Bedienungsanleitung

LENCO

LENCO XEMIO-125 Bedienungsanleitung

LENCO

LENCO XEMIO-119 Bedienungsanleitung

LENCO

LENCO XEMIO-654 Bedienungsanleitung

LENCO

LENCO Xemio-653 Bedienungsanleitung

LENCO

LENCO CD-202 Bedienungsanleitung

LENCO

LENCO XEMIO-145 Bedienungsanleitung

LENCO

LENCO SCD-38 USB Bedienungsanleitung

LENCO

LENCO Xemio-241 Bedienungsanleitung

LENCO

LENCO XEMIO-107 Bedienungsanleitung

LENCO

LENCO Xemio-658 UK Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Philips

Philips PSA250 Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung
