LENCO XEMIO-654 Bedienungsanleitung

XEMIO-664

User Manual

What’s in the box?

For information and support, www.lenco.eu

What’s in the box:

Operating Unit

User Manual

USB Cable

Earphone

Installation CD

Battery chargeing time, battery last time

Table of Content

Buttons location and usages

Basic Operation

Power on and off

Operation of Music Mode

Repeat Mode

Volume Control

Vedio Mode

Driver and Software Utilities Installation

Converting different video format to .AMV video

Record


Auto-off time Mode

Technical Specification

Trouble Shooting

Buttons location and usages

(1) Mode / function

(2) Next/Forward Function

(3) Previous / Backward function

(4) Play/Pause

(5) Volume button

(6) USB port

(7) On/off

(8) Mic

(9) Earphone jack

Basic Operation

Power on and off

Switch the On/Off button first and Press

for 3 seconds

to turn on the player.

Hold for 3 seconds to power off the player

Operation of Music Mode

After entering the main menu page, select the Music and

press to enter playing song mode.In Music Mode,

press once to play music. Press again to pause.

Press to jump to the next song, and to jump

back to the previous song. Hold to fast forward and

hold to rewind.

Hold to return to the main menu

Repeat Mode

In playmode, you can Press to enter the sub-menu and

select the Repeat mode from Normal/Repeat

one/Folder/Repeat Folder/Repeat All/Random or intro

and press to confirm

Volume Control

While enjoying your music you can press button to

control the volume. Press to volume down the music

and Press to volume up the music

Operation of Movie Mode

After entering the Main Menu, select “Movie” and press

to enter Movie mode.

Note: Only files of the .AMV format will be played in Movie

mode.

Press / button to select your desired movie.

Press the button to start playing the selected .AMV

movie. If there are no .AMV files, “Empty Disk” will be

shown on the display.

Skip Movies

Press / button to jump to the next or previous

movie.

Fast Forward and Backward

Look for a certain passage in a movie file by pressing and

holding / while a movie is playing.

Driver and Software Utilities Installation

If you are using Windows® 98/98SE, you must

install the driver before downloading any files to

your player.

Note: If you are using Windows® Me/2000/XP, you

may skip the following installation procedures.

Step 1. Double click on Setup.exe to start the driver

installation. Follow the onscreen-menu to complete

the installation.

Step 2: After installation is completed, please restart

your computer.

Converting different video format to .AMV video

Step 1: After installing the driver and software

utilities, click Start button, select All Programs >

MP3 Player Utilities 4.25 > AMV Convert Tool

Step 2: Click on the Input File button to select

the .ASF video file you want to convert to an .AMV

video file.. Also click on the Output File button to

select the destination path for the AMV video

file.

Step 3: Click Convert button to start converting

process. You will see .AMV video file was

converted.

Note : The software can convert .DAT, .WMV, .AVI

video format into .AMV video also.But if the

resolution for the your desired files less than

160x120,you may not convert it correctly.

Record

In the main menu page, Press / to selet the

Record mode and Press to enter the recording voice

mode

Press to start recording and Press again to stop

or continute recording

Press mode till “Saving…..” appear on the display to

save the recorded voice when you finished the recording.


After entering the Main Menu, select Photo and press

button to enter the Photo Browse function.

Press the / button to select your desired photo.

Note: Only files of the .JPG, .BMP and GIF format will be

displayed in the View PHOTO function.

Setup

After entering the main menu page and Press /

to select Setup and press to enter the setup page

Language Setting

After entering the setting page, press then to

enter the language option. Press / to choose

your preferred language and press to confirm

Auto-off Time

In the setup Mode, press to enter the power-off

setting, then press / to select which minutes you

want the player to automatically shut down and Press

again to confirm the setting, and hold to return to

previous menu.

Technical Specification

Flash Memory 8GB

MP3 compressed rate supported

MP3(8 – 320 kbps)

WMA(5-384kbps)

Video format supported AMV

Photo format supported JPEG / BMP / GIF

Battery Li-Polymer battery

Interface USB2.0 full speed

Display 1.8” Color TFT Display

Frequency Response 20Hz – 22KHz

Distortion <0.5%

Rate of Signal-to-noise >85dB

Earphones Output Power 10mW

Weight 30g

Dimensions

40(W) * 7.5(D) * 82(H) mm

Trouble Shooting

What should I do if there’s no sound when playing?

You should check the volume first. If the volume has been

turned up, maybe the memory format of the device is

incorrect..
