Lenovo A369i Bedienungsanleitung

Quick Start Guide v1.0

Lenovo A369i

English/繁體中文

Learn more

Legal notices Lenovo and the Lenovo logo are trademarks

of Lenovo in the United States, other

countries, or both.

Other company, product, or service names

may be trademarks or service marks of

others.

Read this guide carefully before using your smartphone.

To learn more information about your

Lenovo smartphone and obtain the latest

smartphone manuals, go to:

http://support.lenovo.com/.

Getting support For support on network service and billing,

contact your wireless network operator. For

instructions on how to use your device, go

to: http://support.lenovo.com/.

English

Type: CMOS

Pixels: 2 megapixels (back)

Processor: MTK MT6572W

Lite Dual-core

1.3 GHz

Size: 4.0 inches Screen: Multi-touch display

Resolution: 800 × 480 pixels LCD type: TFT

Model: Lenovo A369i System: Android

Bluetooth 3.0; WLAN 802.11 b/g/n; WCDMA, GSM, EDGE

Battery: 1500 mAh

Height: 124.00 mm (4.88 inches) Width: 63.98 mm (2.52 inches)

Depth: 11.70 mm (0.46 inches) Weight: 120.78 g (0.26 lb)

Model and system

① Depending on the measuring method, the dimensions and weight

might vary slightly.

Display

Battery

Processor

①Dimensions and weight

Camera

Wireless Communication

Technical speciﬁcations

Volume up

Micro USB

connector

Volume down

Earphone jack Speaker

Receiver

On/Off button

Microphone Camera

First glance

7 8

You must insert the SIM card provided by your carrier to use cellular

services. Set up your smartphone as shown.

Step 1. Open the back cover.

Step 2. Insert the SIM cards and

the memory card.

Tip: Insert the (U)SIM card into

SIM1 slot and SIM card

into SIM2 slot.

Step 3. Install the battery.

a. Align the battery

connectors on the battery

with the pins in the

battery compartment.

b. Push the battery down

into place.

Step 4. Install the back cover.

Always turn off your smartphone ﬁrst before you insert or remove a

SIM card. Insert or remove a SIM card with your smartphone on may

damage your SIM card or smartphone permanently.

SIM2

SIM1

SIM2

SIM1

Preparing your smartphone

Turning on or turning off your smartphone

Turn on: Press and hold the On/Off button until

the Lenovo logo appears.

Turn off: Press and hold the On/Off button for a

few seconds, then tap Power off.

Your smartphone has a rechargeable battery. For more information

about battery safety, see the “Rechargeable battery notice” in the

Important Product Information Guide shipped with your smartphone.

Low battery power Fully charged Charging

Charge the battery as shown.

Method 1.

Method 2.

Connect your smartphone to a power outlet using the

cable and USB power adapter that come with your

smartphone.

Connect your smartphone to a computer using the cable

that comes with your smartphone.

Charging the battery

更多資訊

法律注意事項 Lenovo 及Lenovo 標誌為美國、其他國家或美

國及其他國家的 Lenovo 商標。

其他公司、產品或服務名稱可能是其他公司的商

標或服務商標。

使用智能手機前，請仔細閱讀本手冊。

如需 Lenovo 智能手機的更多相關資訊，以及

獲取最新的智能手機使用手冊，請瀏覽：

http://support.lenovo.com/。

取得支援如需關於網絡服務和收費的支援，請聯絡您的

無線網絡營運商。如需關於使用裝置的指示，

請瀏覽：http://support.lenovo.com/。

繁體中文

類型：CMOS

像素：200 萬像素（背面）

處理器：MTK MT6572W，Lite Dual-core，1.3 GHz

大小：4.0 吋螢幕：多點觸控

解像度：800 × 480 像素 LCD 類型：TFT

型號：Lenovo A369i 系統：Android

藍牙 3.0；WLAN 802.11 b/g/n；WCDMA、GSM、EDGE

電池：1500 mAh

高度：124.00 毫米 (4.88 吋) 寬度：63.98 毫米 (2.52 吋)

厚度：11.70 毫米 (0.46 吋) 重量：120.78 g (0.26 lb)

型號與系統

① 視乎量度方法而定，尺寸及重量可能略有不同。

顯示器

電池

處理器

①尺寸及重量

相機

無線通訊

技術規格

音量增大

Micro USB 連接器

音量減少

耳機插孔揚聲器

接收器

開/關按鈕

麥克風相機

概覽

7 8

您必須插入由電訊營運商提供的 SIM 卡.如圖所示，安裝您的智能

手機。

步驟 1. 打開背蓋。

步驟 2. 插入 SIM 卡和記憶卡。

提示：

插入 (U)SIM 卡到 SIM1 插槽

和SIM 卡到 SIM2 插槽。

步驟 3. 安裝電池。

a. 將電池連接器對準電池，

確保電池連接器的針對準

電池。

b. 將電池向下退嵌入到位。

步驟 4. 安裝背蓋。

插入或移除 SIM 卡前記得先關閉智能電話。開機狀態下插入或取出

SIM 卡，可能會對 SIM 卡或智能手機造成永久性的損壞。

SIM2

SIM1

SIM2

SIM1

使用智能手機前的準備工作
